$649.99
DEWALT 1.6 HP 30 gal. Air Compressor, 155 PSI
DEWALT 1.6 HP 30 gal. Air Compressor, 155 PSI
Item # 131332599
$649.99
or
or
Buy Air Compressor Get 20% Off Air Compressor accessorie
Add a protection plan
Powersport plans are not available in CA.
Neighbor’s Club Members earn points with purchases.
DEWALT 1.6 HP 30 gal. Air Compressor, 155 PSI
Item # 131332599
Buy Air Compressor Get 20% Off Air Compressor accessorie
$649.99
or
or
$55/mo.† suggested payments with 12 Months Financing or earn $32 in Rewards+ on this purchase.
Out of stock at or near
Grassland (franklin) TN
Out of stock delivering to
37027
This is a Big & Bulky item.
This item is not available
Search Stores
Temporarily unavailable
Add a protection plan
Powersport plans are not available in CA.
Neighbor’s Club Members earn points with purchases.
The DEWALT 1.6 HP 30 gal. Air Compressor is proudly made in the USA with global materials and features a 1.6 HP 120 volt heavy-duty induction motor with an oil lubricated, belt driven, cast iron, V-twin pump that delivers 155 Max PSI, 6.2 SCFM at 40 PSI and 5.3 SCFM at 90 PSI all while operating at a quiet 75 decibels bringing less noise to your environment. The 10-in. wheels make the air compressor portable, while the vertical configuration takes up less floor space making it easy to store in the corner of a garage or workshop. This DEWALT air compressor will operate a wide variety of pneumatic tools for automotive and agricultural applications as well as your DIY projects around the home (All pneumatic tools operate at various SCFM. Consult the operator's manual for your tool for the required SCFM for the tool to operate.). The air compressor is shipped with synthetic oil for optimum performance and long life.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Built with a high flow regulator-which supplies more torque for the projects like removing old rusted bolts-get more air to the tool
- Dual voltage motor is wired for standard 120V outlet, and may also be converted for 240V applications
- Heavy duty 1.6 HP induction motor in the air compressor for long life
- 155 PSI max pressure for optimum tool performance
- 2 year limited pump warranty; 1 year warranty on all other components
- Made in USA
- Shipped with synthetic oil for optimum performance and long life
| Brand | DEWALT |
|---|---|
| Country of Origin | Made in USA |
| Airflow Volume | 6.2 CFM |
| Air Outlet Size | 3/8 in. |
| Compressor Horsepower | 1.6 HP |
| Lubrication Type | Oil |
| Compressor Maximum PSI | 155 PSI |
| Compressor Tank Capacity | 30 gal |
| Compressor Voltage | 120V |
| Cord Length | 6 ft. |
| Decibel Rating | 75 dBA |
| Drain System | Multi-turn manual drain valve |
| Drive Type | Induction motor with belt drive pump |
| Engine Brand | N/A |
| Features | Regulator Included |
| Fuel Tank Capacity | N/A |
| Maximum RPM | 1,200 RPM |
| Phase | Single |
| Number Of Power Speeds | Single |
| Number Of Wheels | 2 |
| Power Type | Electric |
| Primary Color | Yellow |
| Product Height | 49 in. |
| Product Length | 26 in. |
| Product Weight | 152 lb. |
| Product Width | 25 in. |
| Pump Life | 1,000 hours |
| Pump Material | Cast iron |
| Pump Oil Capacity | 11.35 oz. |
| Stage Type | Single-Stage |
| Tank Fill Time | 7.5 minutes |
| Tank Style | Vertical |
| Warranty | DeWALT Industrial Tools are warranted from date of purchase. 2 Year - Limited warranty on oil-lubricated air compressor pumps. 1 Year - Limited warranty on all other air compressor components. This warranty is not transferable to subsequent owners |
| Manufacturer Part Number | DXCM301 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 110 Questions
Newest questions
Q: what CB amps required for 220vt
10 months ago1 Answer
- A: For the DEWALT Air Compressor (models such as DXCMLA1683066 or DXCM301) wired for 220V/240V, you should use a 30-amp dedicated circuit breaker.10 months agoHelpful?
Q: How many amps does this draw under load?
11 months ago1 Answer
- A: The DEWALT 1.6 HP 30 gal. Air Compressor (models such as DXCMLA1683066 or DXCM301) draws 15 amps under load when operated at 120 volts.10 months agoHelpful?
Q: How long to get this at the Bossier city store.
a year ago1 Answer
- A: Hello, thank you for your question. Unfortunately, this item is currently out of stock. If it is still showing on our website, that is an indicator that we are attempting to restock. However, we do not have inventory restock information readily available at this time. Make sure you're signed up to receive our emails (sign up link is located at the bottom of our website), follow us on social media and continue to check the website for restock updates.a year agoHelpful?
Q: What is the manufacture warranty
a year ago1 Answer
- A: Hello, thank you for your question. Here is the warranty information from the manufacturer: Warranty: DeWALT Industrial Tools are warranted from date of purchase. 2 Year - Limited warranty on oil-lubricated air compressor pumps. 1 Year - Limited warranty on all other air compressor components. This warranty is not transferable to subsequent ownersa year agoHelpful?
Q: Is the pressure switch set to 155 psi? Otherwise does it operate at 155 psi?
a year ago1 Answer
- A: Hi, Yesa year agoHelpful?
Q: Can this motor be wired 230v?
a year ago1 Answer
- A: Hi, Yes, the motor on your DEWALT 1.6 HP 30-gallon air compressor (155 PSI) is designed as a dual-voltage motor, meaning it can be wired for both 120V and 240Va year agoHelpful?
Q: What does scfm stand for
a year ago1 Answer
- A: SCFM stands for Standard Cubic Feet per Minute. It's a measurement of how much air flows through an air compressor at standard conditions. SCFM is a more accurate way to measure an air compressor's air capacity than Cubic Feet per Minute (CFM).a year agoHelpful?
Q: Can I return new compressor to any tractor supply
2 years ago1 Answer
- A: Hi Breeze, Yes, you can. 30 Day Return Policy Whether you made your purchase in a Tractor Supply store or online, if you're not completely satisfied with any item you purchased from Tractor Supply, return it to us with proof of purchase within 30 days from the purchase date to exchange or return an item at its original purchase price. All returns require a proof of purchase or are subject to refund verification system approval.2 years agoHelpful?
Q: Can it run on 10 amp
2 years ago1 Answer
- A: No, the DXCM301 requires a dedicated 15AMP breaker. If you need further assistance, feel free to contact a product team member at 1-888-895-4549. Thank you for your interest in DeWalt!2 years agoHelpful?
Q: Can it run on 10 amp
2 years ago1 Answer
- A: No, the DXCM301 requires a dedicated 15AMP breaker. If you need further assistance, feel free to contact a product team member at 1-888-895-4549. Thank you for your interest in DeWalt!2 years agoHelpful?
1 - 10 of 110 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 110 Questions
Newest questions
Q: what CB amps required for 220vt
10 months ago1 Answer
- A: For the DEWALT Air Compressor (models such as DXCMLA1683066 or DXCM301) wired for 220V/240V, you should use a 30-amp dedicated circuit breaker.10 months agoHelpful?
Q: How many amps does this draw under load?
11 months ago1 Answer
- A: The DEWALT 1.6 HP 30 gal. Air Compressor (models such as DXCMLA1683066 or DXCM301) draws 15 amps under load when operated at 120 volts.10 months agoHelpful?
Q: How long to get this at the Bossier city store.
a year ago1 Answer
- A: Hello, thank you for your question. Unfortunately, this item is currently out of stock. If it is still showing on our website, that is an indicator that we are attempting to restock. However, we do not have inventory restock information readily available at this time. Make sure you're signed up to receive our emails (sign up link is located at the bottom of our website), follow us on social media and continue to check the website for restock updates.a year agoHelpful?
Q: What is the manufacture warranty
a year ago1 Answer
- A: Hello, thank you for your question. Here is the warranty information from the manufacturer: Warranty: DeWALT Industrial Tools are warranted from date of purchase. 2 Year - Limited warranty on oil-lubricated air compressor pumps. 1 Year - Limited warranty on all other air compressor components. This warranty is not transferable to subsequent ownersa year agoHelpful?
Q: Is the pressure switch set to 155 psi? Otherwise does it operate at 155 psi?
a year ago1 Answer
- A: Hi, Yesa year agoHelpful?
Q: Can this motor be wired 230v?
a year ago1 Answer
- A: Hi, Yes, the motor on your DEWALT 1.6 HP 30-gallon air compressor (155 PSI) is designed as a dual-voltage motor, meaning it can be wired for both 120V and 240Va year agoHelpful?
Q: What does scfm stand for
a year ago1 Answer
- A: SCFM stands for Standard Cubic Feet per Minute. It's a measurement of how much air flows through an air compressor at standard conditions. SCFM is a more accurate way to measure an air compressor's air capacity than Cubic Feet per Minute (CFM).a year agoHelpful?
Q: Can I return new compressor to any tractor supply
2 years ago1 Answer
- A: Hi Breeze, Yes, you can. 30 Day Return Policy Whether you made your purchase in a Tractor Supply store or online, if you're not completely satisfied with any item you purchased from Tractor Supply, return it to us with proof of purchase within 30 days from the purchase date to exchange or return an item at its original purchase price. All returns require a proof of purchase or are subject to refund verification system approval.2 years agoHelpful?
Q: Can it run on 10 amp
2 years ago1 Answer
- A: No, the DXCM301 requires a dedicated 15AMP breaker. If you need further assistance, feel free to contact a product team member at 1-888-895-4549. Thank you for your interest in DeWalt!2 years agoHelpful?
Q: Can it run on 10 amp
2 years ago1 Answer
- A: No, the DXCM301 requires a dedicated 15AMP breaker. If you need further assistance, feel free to contact a product team member at 1-888-895-4549. Thank you for your interest in DeWalt!2 years agoHelpful?
1 - 10 of 110 Questions
Similar Items
-
-
-
-
-
Top Rated
-
-
-
-
-
Top Rated
-
-
Items You May Like
-
-
-
-
-
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
Customers Also Bought
-
-
-
-
-
Top Rated
-
-
-
Top Rated
-
Top Rated
-
-
-
Reviews
- noise level
- purchase
- satisfaction
- price
- quality
- portable
- parking
- small
1 to 4 of 1359 Reviews .
1 – 4 of 1359 Reviews
Most Recent
Elk Grove, CA
Review 1
3 out of 5 stars.
30 gallon compressor
a year ago
The compressor was packaged well and arrived in good shape. TSC loaded it at the store with a forklift. I thoroughly inspected the unit before the break in run. I had to adjust the pulley on the motor by 3/8" to align with the compressor pulley. One of the filters was not properly screwed in and fell off while inspecting the filter. The threads were damaged before assembly, so I chased the threads with a thread chasing file and screwed it into the compressor properly. The drain (that is supposed to be opened daily) is almost inaccessible. The unit needs more ground clearance or route the drain to an accessible location. I build air fine and the regulator works fine. Improvements to the manufacturing process and design would have resulted in a 5-star rating.
SweepstakesYes
Yes, I recommend this product.
Ind
Reviews 3
1 out of 5 stars.
N/a
2 years ago
I have purchased several of the dewalt comperssors over the last 2 years and they don't last very long.
SweepstakesYes
No, I do not recommend this product.
Response from Dewalt Team:
2 years ago
Dewalt Team
We are sorry to hear of your issues, if you have a specific issue, please reach out to our Service Team so they can assist you with your situation. Service Team can be reached at 1-888-859-4549 or through email at service.parts@sanborn-mfg.com.
Pa
Review 1
5 out of 5 stars.
Great air compressor!
2 years ago
Works great! Very quiet.
SweepstakesYes
Yes, I recommend this product.
Review 1
5 out of 5 stars.
Great little compressor
2 years ago
Relatively quiet, compact form factor, and easy to move around. The only problem is that the bleed valve on the bottom of the tank requires that the tank be tilted to access.
