Champion Power Equipment 7-Ton Compact Horizontal Gas Log Splitter with Auto Return

SKU # 118662499
Product price

Save Up To
See Price at Check Out
Why?
Product Rating is 4.6
4.6
(129)

Financing Available! Click here for more details...

Quantity

Autoship

Delivery Options:

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it. Learn More

power plus

Item Information

The Champion Power Equipment 90720 7-Ton Compact Portable Log Splitter is designed for quick, dependable, and portable log splitting. With a quick 20 second full cycle time and efficient auto-return control valve the log splitter is capable of up to 180 cycles per hour and can handle logs up to 19.3 inches in length and 50 lb. in weight. The log splitter is equipped with integrated log cradle, has a low profile design allowing for easy loading of heavier logs and a features a skewed wedge for improved splitting efficiency. Along with a convenient handle and never-flat tires the log splitter's compact design makes it easy to move from one job to the next and it can be stored almost anywhere.

  • Portable - convenient handle and never-flat tires
  • Efficient - quick 20 second cycle time and auto-return control valve
  • Skewed wedge for improved splitting
  • Low profile design and integrated log cradles for easy splitting of heavier logs
  • EPA certified and CARB compliant
  • Champion Support - 2 year limited warranty with FREE lifetime technical support

Specification Description
Product Width: 23-5/8 in.
Product Length: 53-1/8 in.
Warranty: 2-Year Limited
CARB Compliant: Yes
Engine Make: Champion
Product Weight: 143.3 lb.
Product Type: Log Splitters
Tire Size: 10 in.
Cycle Time: 20 sec.
Positioning: Horizontal
Maximum Log Length: 19-3/8 in.
Fuel Capacity: 0.4 gal.
Splitting Force: 7 Tons
Engine Displacement: 80 cc
Maximum Log Diameter: Any
Power Type: Gas
Product Height: 18-1/8 in.
Maximum PSI: 3,000 PSI
Pump GPM: 3
Brand: Champion Power Equipment
Manufacturer Part Number 90720
Champion Power Equipment 7-Ton Compact Horizontal Gas Log Splitter with Auto Return is rated 4.6 out of 5 by 128.
Rated 5 out of 5 by from 7-ton Champion log splitter This log splitter is AWESOME. I am a Grandma. It works as advertised, and then-some. Split my wood as if it was butter. I received it in three days. Had trouble with Tractor Supply on pick up.
Date published: 2018-05-10
Rated 5 out of 5 by from Easier than Expected After researching, I decided on the Champion 7-ton log splitter. The decision was based on my confidence in the brand, the product's features and the price, but mostly on the reviews that others had already written. Nevertheless, I remained somewhat concerned about assembly of the product, but this turned out to be unnecessary worry. A neighbor came over and helped me and we were able to assemble the splitter in a little over an hour. It was much easier than expected with his help. (It would have been quite a challenge for my wife and me to assemble without his help.) Since I have purchased it in the spring, there is no rush to split logs, but as soon as fall comes bringing cool weather again, I am really looking forward to putting it to good use. I've told my good neighbor he is welcome to use it, too.
Date published: 2018-05-10
Rated 5 out of 5 by from This is an amazing tool...why did I wait so long! This is an amazing splitter.....I've been splitting firewood for 45 years by hand.....stupid.....this 7 ton model is more than enough for 24" rounds of fir......I know fir burns faster but when you have a free source....not much better than that! If you buy the 7 ton model....be patient.....run it for a while....turn it off and check the hydraulic fluid.....that is the trick with this one....at first I was bummed....wasn't working right...be sure and open up the breather valve...it's how the air escapes.....keep observing the air going through the clear hose...no more air then you have the fluid at the right level.....and it will split whatever you've got....you will never be sorry....I was a contractor for 30 years....a tool freak.....this is the best money I've ever spent on a tool.....at 75....I'm so stoked...I just want to split all day.....worth every penny......save your back.....just get it.....you will be laughing all day long!!
Date published: 2018-05-09
Rated 5 out of 5 by from Perfect! Assembly required, but the instructions are written quite well. (Have an allen wrench handy.) It's a dream come true to have a smaller, easy to move and store splitter that can do the work of the "big guys". And you can't beat the price! Perfect for a homeowner, like myself, making it easy and enjoyable splitting wood for the winter.
Date published: 2018-04-22
  • y_2018, m_7, d_20, h_19
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_5, tr_123
  • loc_en_US, sid_118662499, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply

What types of oil and fluids needed? Hydrologic oil?

Asked by: Ac100
Yes, you will need to purchase engine oil and hydraulic oil. Hydraulic Oil System Oil capacity is 1.3 gal. (4.9 L). For year round use in warmer climates (always ABOVE 32˚ F / 0˚ C): –– SAE 10W –– ISO 32 –– SAE 32 –– ISO 46 –– ASLE H-150 –– Universal Hydraulic/Transmission Fluid For year round use in colder climates (sometimes BELOW 32 ˚F/0 ˚C): –– Automatic Transmission Fluid
Answered by: Champion Power Expert
Date published: 2017-10-23

Does this unit flip upright? Will it spit logs in a vertical position? Or do logs need to be lifted and placed on top of the unit for splitting?

Asked by: Nita84
Sorry, this is horizontal use only.
Answered by: Champion Power Expert
Date published: 2018-04-12

whats engine horsepower I don't want answeri cc and can this be pulled it hitch

Asked by: Clarence Powell
This machine is not meant to be towed by a vehicle. The engine is about 2.4HP.
Answered by: Champion Power Expert
Date published: 2017-06-21

what type of oil and how much does resivoir hold for pump   ?

Asked by: Doug Pytlik
The pump uses the hydraulic oil for lubrication. The type of oil needed is listed in the owner's manual and is based on operating temperatures. You can download the manual for free from this page. The hydraulic tank capacity is 0.87 gal. (3.3 L).
Answered by: Champion Power Expert
Date published: 2017-06-21

motor mfg?

Asked by: gee whiz
Champion Power Equipment manufacturers our own engines. Designed and engineered by our firm Champion Engine Technologies.
Answered by: Champion Power Expert
Date published: 2017-10-23

What diameter log will this unit split ?

Asked by: Hoppy50
The wedge is 5 inches tall. If you want to split a log in one stroke, the log will have to be close to 5 inches in diameter. If you have a larger diameter log, you may have to cycle the splitter a second time after rotating the log.
Answered by: Champion Power Expert
Date published: 2017-10-23

Can you pull this behind your truck

Asked by: Selfricky
Sorry, this splitter is not intended to be towed behind a vehicle on city streets or highways. It will more than likely fit in your truck bed though or on a small trailer for it. – Height 18.1 in. (46 cm) – Width 23.6 in. (60 cm) – Length 53.1 in. (135 cm)
Answered by: Champion Power Expert
Date published: 2018-06-01

how big of log will it split

Asked by: JLP HUNTER
Max Log Length 19.3 in. Max Log Weight 50.0 lb.
Answered by: Champion Power Expert
Date published: 2018-05-01
