CountyLine Shallow Well Cast Iron Jet Pump, 1 HP

SKU: 102814399
CountyLine Shallow Well Cast Iron Jet Pump, 1 HP
Enter Zip Code for price More Info
Product price

Save Up To
See price at checkout More Info
Product Rating is 4.2
4.2
 (156)

Quantity

Check Availability at Other Stores
Standard Delivery Not Available to
Notice: This item will ship within 0 days.
This product may require up to 0 additional days for order processing prior to shipping.
Change Delivery Location
Protect your purchase with Power Plus
Protect Your Purchase Click here for more details...

We'll fix it, replace it, or reimburse you for it.

Item Information

CountyLine Shallow Well Cast Iron Jet Pump delivers water from 25 ft. or less. Rugged cast iron construction for long life.

  • 1 HP
  • Maximum Depth to Water: 25 ft.
  • Maximum GPM: 21 GPM
  • Suction Port Size: 1-1/4 in. NPT
  • Outlet Port Size: 1 in. NPT
  • 19 in. x 10-5/6 in. x 10-1/2 in.
  • 53 lb.
  • Cast Iron
  • CSA Approved
  • 1 year limited warranty
Tractor Supply is proud to introduce CountyLine, our brand of high quality, competitively priced agricultural products. With a full line of 3-point equipment for your tractor, as well an assortment of sub-compact pieces, our goal is to provide you with the implements you need to get the job done. Designed for durability and superior performance, all CountyLine products come with satisfaction guaranteed.

Specification Description
Power Type: Electric
GPH @ 10 ft. of Head: 18 GPM
Product Width: 19 in.
GPH @ 20 ft. of Head: 13 GPM
Agency Approvals: CSA
Outlet Port Size: 1 in. NPT
GPH @ 25 ft. Head: 9 GPM
Maximum GPM: 21 GPM
Product Weight: 53 lb.
Suction Port Size: 1-1/4 in. NPT
Product Length: 10-4/5 in.
GPH @ 5 ft. of Head: 20 GPM
Horsepower: 1 HP
Maximum Depth To Water: 25 ft.
GPH @ 0 ft.: 21 GPM
Dual Voltage Motor: Yes
Maximum Pressure Shutoff: 70 PSI
Replicable Pressure Switch 30/50: Yes
Brand: CountyLine
Warranty: 1-Year Limited
GPH @ 15 ft. of Head: 16 GPM
Body Material: Cast Iron
Self-Priming After Pump Housing Is Filled: Yes
Product Height: 10-1/2 in.
Manufacturer Part Number CLTS10
CountyLine Shallow Well Cast Iron Jet Pump, 1 HP is rated 4.2 out of 5 by 156.
Rated 5 out of 5 by from Great value This is a cast iron shell that is ideal for water conditions. I looked at other manufacturers and the cost /value were much below the quality of this pump. I DID have an issue, the fan housing is too close to the fan that inhibits it running. I found this out after I returned one and had same issue (motor humming) when I installed again. I loosened the fan housing and it works GREAT. I am running at 50psi and shuts off at 60PSI as designed. This is a replacement of an identical unit that failed when I failed to adjust pressure sensor and it ran until the motor seized.
Date published: 2020-08-04
Rated 5 out of 5 by from Worth the money Great pump. My well is a swallow well and have a craftsman pump but it did not put out the amount of water to even water a small lawn. This new pump puts out so much press tans water I can finish watering in 2.5 hours a large yard. Best money spent.
Date published: 2020-06-30
Rated 1 out of 5 by from Worked great for a little while Bought and installed this pump 15 months ago. Pumped has worked great until recently. Pump currently will not start up and run, just buzzing. I am going to try and replace the capacitor but definitely should have gotten more life from this pump before repair.
Date published: 2020-06-20
Rated 5 out of 5 by from Grreat Pump I used this pump to pump to pump water from a storage tank. Great pressure, perfect solution!
Date published: 2020-05-15
  • y_2020, m_8, d_12, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.10
  • cp_1, bvpage1
  • co_hasreviews, tv_60, tr_96
  • loc_en_US, sid_102814399, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 1ms
  • REVIEWS, PRODUCT

Can I reduce the suction to 3/4 of a inch and the outlet size to 3/4 to use as a booster pump for rural water?

Asked by: Billy jack1968
No, this is not recommended the pump is asking for a 1-1/4” pipe full of water and is only getting ¾” of water. The pump is going to destroy it self.
Answered by: jessicasm
Date published: 2019-06-27

where can you buy replacement parts?

Asked by: suzito
Your local Tractor Supply can order any replacement parts needed for CountyLine pumps.
Answered by: Valery
Date published: 2017-03-22

What amp breaker should be used for this pump for 220volts

Asked by: MT220
The Manual on Page #4 says, 15amp Breaker.
Answered by: jessicasm
Date published: 2020-07-01

How many amps does the 1 hp motor need?

Asked by: Water baron
On 115 volts, the pump’s nameplate amps are 12. A 20-amp breaker is recommended for 115 volts. On 230 volts, the pump’s nameplate amps are 6. A 15-amp breaker is recommended in that case.
Answered by: Tbeacher
Date published: 2018-10-03

i need to know the contact number to get replacement parts for a cl100 pump.

Asked by: terryvison
Your local Tractor Supply can order any replacement parts needed for CountyLine pumps.
Answered by: KirwinH
Date published: 2017-09-27

Will this pump pull water from a stream 100 linear feet and 5 feet below pressure tank ?

Asked by: Rob418
The stream must be 4’ to 5’ deep of water, so that the foot valve is under that much water. The tank has to be within 5’ or less to the pressure switch. With the 1-1/4” inlet pipe at a 5’ rise from the top of the water in the stream, the pump will do about 16gpm. If they use a 2” inlet pipe, the pump will do about 20gpm.
Answered by: ErlindaC
Date published: 2019-05-17

Is the motor continuous duty?

Asked by: motor question
Model CLTS10 is rated for continuous duty.
Answered by: ErlindaC
Date published: 2018-07-10

Can it bet set to pump 45-60 when used as a booster pump? It will be supplied with 40# pressure.r

Asked by: Rich742d
The pump could be configured to operate at 40/60 by adjusting the pressure switch. The switch has a built in differential of 20 PSI so 45/60 is not possible.
Answered by: ErlindaC
Date published: 2019-05-14
