CountyLine 1 HP 230V Electric 2-Wire Series 4 in. Submersible Pump, 14.7 GPM
$619.99
CountyLine 1 HP 230V Electric 2-Wire Series 4 in. Submersible Pump, 14.7 GPM
Exclusive
CountyLine 1 HP 230V Electric 2-Wire Series 4 in. Submersible Pump, 14.7 GPM
Item # 1028149
Stocked & Ready
$619.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
Exclusive
CountyLine 1 HP 230V Electric 2-Wire Series 4 in. Submersible Pump, 14.7 GPM
Item # 1028149
Stocked & Ready
$619.99
or
or
$52/mo.† suggested payments with 12 Months Financing or earn $30 in Rewards+ on this purchase.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The CountyLine 2-Wire 1 HP 10 GPM Series 4 in. Submersible Pump is ideal for residential water systems and agricultural applications 300 ft. deep or less. Featuring a proven floating stack impeller design for sand resistance and reduced sand locking, this heavy-duty stainless steel pump is built to last. The pump is rated for 230V and is backed by a 3 year limited warranty.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 1 HP
- Maximum depth to water: 300 ft.
- 230V
- 4-5/8 in. x 5 in. x 29 in.
- 37 lb.
- Stainless steel body
- CSA approved
- Includes: Control Box
- Tractor Supply is proud to introduce CountyLine, our brand of high quality, competitively priced agricultural products; with a full line of 3-point equipment for your tractor, as well an assortment of sub-compact pieces
- 3 year limited warranty
| Brand | CountyLine |
|---|---|
| Country of Origin | Made in USA |
| Amperage | 7.2 Amp |
| Body Material | Stainless steel |
| Compatible Pipe Material | Other |
| Compatible Well Diameter | 4 in. |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1.25 in. |
| Discharge Rate at 0 ft. | 14.7 GPM |
| Discharge Rate at 25 ft. | N/A |
| Discharge Rate at 50 ft. | 15 GPM |
| Features | N/A |
| Head Pressure | 130 PSI |
| Horsepower | 1 HP |
| Impeller Material | Engineered thermoplastic |
| Inlet Connection | None |
| Inlet Diameter | N/A |
| Maximum Flow Rate | 14.7 GPM |
| Maximum Head Lift | N/A |
| Maximum Operating Depth | 300 ft. |
| Maximum Operating Temperature | 86 degrees F |
| Minimum Operating Temperature | 32 degrees F |
| Power Type | Electric |
| Product Height | 29 in. |
| Product Length | 5 in. |
| Product Weight | 37 lb. |
| Product Width | 5 in. |
| Motor Type | Submersible |
| Voltage | 230V |
| Warranty | 3 Year Limited |
| Manufacturer Part Number | CLA203 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 28 Questions
Newest questions
Q: How can it be 5” wide and fit in a 4” well?
3 months ago1 Answer
- A: This pump is specifically designed to be compatible with 4-inch diameter wells. While the listed product dimensions are 5 inches by 5 inches, it is a standard 4-inch series submersible pump intended for use in 4-inch or larger well casings.3 months agoHelpful?
Q: Does it come with a built-in check valve?
8 months ago1 Answer
- A: Yes, the CNL 1 HP 2-Wire 230 Volt 4-inch submersible pump includes a built-in check valve at the discharge. This feature is designed to prevent water from flowing back into the well when the pump turns off, which helps maintain system pressure and prevents damage to the pump motor from backspin or water hammer8 months agoHelpful?
Q: Does the pump include the electric wires
a year ago1 Answer
- A: Please contact Customer Service 1-800-535-4950 to better assist you.a year agoHelpful?
Q: what type of capacitor does this pump use
2 years ago1 Answer
- A: Contact Vendor Pentair at 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: What is the MOCP for this pump?
2 years ago1 Answer
- A: For Technical support contact 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: After the this pump has pumped water to the pressure tank how far will it push it up hill after the pressure tank? I have the main house less than 20ft from the well but I also got a yard barn/cabin 900ft up hill from the well thought about running too
2 years ago1 Answer
- A: Please contact Customer Service 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: Is the pump NSF approved?
3 years ago1 Answer
- A: Please contact Customer Service at 262-728-5551.3 years agoHelpful?
Q: Do these pumps have foot valves
3 years ago1 Answer
- A: Contact Customer Service at 262-728-5551. to better assist you.3 years agoHelpful?
Q: What is the minimum run time of this pump?
3 years ago1 Answer
- A: This pump once set up, is designed to run at intervals with a pressure switch for start up and cut off. If you need further assistance please Contact vendor Pentair at 800-535-4950.3 years agoHelpful?
Q: Does this pump have a check Valve already
3 years ago1 Answer
- A: Contact vendor Pentair at 800-535-49503 years agoHelpful?
1 - 10 of 28 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 28 Questions
Newest questions
Q: How can it be 5” wide and fit in a 4” well?
3 months ago1 Answer
- A: This pump is specifically designed to be compatible with 4-inch diameter wells. While the listed product dimensions are 5 inches by 5 inches, it is a standard 4-inch series submersible pump intended for use in 4-inch or larger well casings.3 months agoHelpful?
Q: Does it come with a built-in check valve?
8 months ago1 Answer
- A: Yes, the CNL 1 HP 2-Wire 230 Volt 4-inch submersible pump includes a built-in check valve at the discharge. This feature is designed to prevent water from flowing back into the well when the pump turns off, which helps maintain system pressure and prevents damage to the pump motor from backspin or water hammer8 months agoHelpful?
Q: Does the pump include the electric wires
a year ago1 Answer
- A: Please contact Customer Service 1-800-535-4950 to better assist you.a year agoHelpful?
Q: what type of capacitor does this pump use
2 years ago1 Answer
- A: Contact Vendor Pentair at 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: What is the MOCP for this pump?
2 years ago1 Answer
- A: For Technical support contact 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: After the this pump has pumped water to the pressure tank how far will it push it up hill after the pressure tank? I have the main house less than 20ft from the well but I also got a yard barn/cabin 900ft up hill from the well thought about running too
2 years ago1 Answer
- A: Please contact Customer Service 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: Is the pump NSF approved?
3 years ago1 Answer
- A: Please contact Customer Service at 262-728-5551.3 years agoHelpful?
Q: Do these pumps have foot valves
3 years ago1 Answer
- A: Contact Customer Service at 262-728-5551. to better assist you.3 years agoHelpful?
Q: What is the minimum run time of this pump?
3 years ago1 Answer
- A: This pump once set up, is designed to run at intervals with a pressure switch for start up and cut off. If you need further assistance please Contact vendor Pentair at 800-535-4950.3 years agoHelpful?
Q: Does this pump have a check Valve already
3 years ago1 Answer
- A: Contact vendor Pentair at 800-535-49503 years agoHelpful?
1 - 10 of 28 Questions
Similar Items
-
-
-
-
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
-
Top Rated
Items You May Like
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
-
-
Reviews
- purchase
- installation
- satisfaction
- price
- quality
- water pressure
- warranty
- packaging
1 to 4 of 196 Reviews .
1 – 4 of 196 Reviews
Most Recent
Review 1
1 out of 5 stars.
Sold as clearance. Did not work
2 months ago
Defective product sold as clearance
Anonymous
Review 1
2 out of 5 stars.
Mislabeled GPM on website
6 months ago
It is listed as 13.7 GPM but the box says 10gpm. FedEx damaged the box and had it at their location for 3 days before delivery.
North Carolina
Review 1
5 out of 5 stars.
Reasonably Priced.
a year ago
Despite being disabled my husband was able to put it together and replace our submersible well pump and it is working great!
SweepstakesYes
Yes, I recommend this product.
Stewartstown, PA
Review 1
5 out of 5 stars.
Still works great
a year ago
This is an update of the review I wrote 10 years ago. I wrote the "Most Helpful Favorable Review" 10 years ago. The pump is still going great. Because my well is 316 feet deep I put extra check valves in the line coming up to the house. I don't work for Tractor Supply or the pump company. Just an honest review.
Yes, I recommend this product.
