CountyLine 1 HP 115/230V Electric 1-1/4 in. Convertible Cast Iron Jet Pump, 17 GPM
$479.99
CountyLine 1 HP 115/230V Electric 1-1/4 in. Convertible Cast Iron Jet Pump, 17 GPM
Online Only
CountyLine 1 HP 115/230V Electric 1-1/4 in. Convertible Cast Iron Jet Pump, 17 GPM
Item # 1028145
$479.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
Online Only
CountyLine 1 HP 115/230V Electric 1-1/4 in. Convertible Cast Iron Jet Pump, 17 GPM
Item # 1028145
$479.99
or
or
$40/mo.† suggested payments with 12 Months Financing or earn $23 in Rewards+ on this purchase.
This item is available online only
Out of stock delivering to
37027
Pickup Nearby at FRANKLIN TN(6.7) miles FREE
Get everything you need
Neighbor’s Club Members earn points with purchases.
The CountyLine 1 HP 1-1/4 in. Convertible Cast Iron Jet Pump delivers water from 70 ft. or less. Featuring heavy-duty, rugged cast iron construction, this pump includes a pressure regulator, pressure gauge and ejector kit for 4 in. wells or larger. The jet pump comes backed by a 1 year limited warranty for purchasing assurance. It is a powerful 17 GPM, 115V/230V and 1 HP jet pump.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 1 HP
- Maximum depth to water: 70 ft.
- 115V/230V
- Maximum GPM: 17 GPM
- Suction port size: 1-1/4 in. NPT
- Outlet port size: 1 in. NPT
- Dimensions: 17-1/3 in. x 13-1/3 in. x 10-4/9 in.
- Weighs 53 lb.
- Cast iron body offers enhanced durability
- CSA-approved
| Brand | CountyLine |
|---|---|
| Country of Origin | Imported |
| Amperage | 11 115V 5.5 230V |
| Body Material | Cast iron |
| Compatible Pipe Material | Other |
| Compatible Well Diameter | 1-1/4 in. NPT |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1 in. |
| Discharge Rate at 0 ft. | 17 GPM |
| Discharge Rate at 25 ft. | 10 GPM |
| Discharge Rate at 50 ft. | 6 GPM |
| Features | CSA Approved |
| Head Pressure | 65 PSI |
| Horsepower | 1 HP |
| Impeller Material | Glass-filled polycarbonate |
| Inlet Connection | Threaded Female |
| Inlet Diameter | 1.25 in. |
| Maximum Flow Rate | 17 GPM |
| Maximum Head Lift | 70 ft. |
| Maximum Operating Depth | 70 ft. |
| Maximum Operating Temperature | 77 degrees F |
| Minimum Operating Temperature | 32 degrees F |
| Power Type | Electric |
| Product Height | 11 in. |
| Product Length | 18 in. |
| Product Weight | 53 lb. |
| Product Width | 14 in. |
| Motor Type | TEFC |
| Voltage | 115V230V |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | CL100 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 63 Questions
Newest questions
Q: Can it be set at 40-60 psi?
3 months ago1 Answer
- A: No, the Pressure Switch that is on this Unit is a 30/50. Reason Being is that this Unit can Only get up to 65psi. There will be some Wear on the Unit over many Years, before the Unit is Not able to get up the 50 Pound Shut Off Pressure.3 months agoHelpful?
Q: what is the on / off pressures?
4 months ago1 Answer
- A: The Pressure Switch that is on this Unit is a 30/50.4 months agoHelpful?
Q: I want to buy the pump parts, the impeller
9 months ago1 Answer
- A: Contact your local TSC store for assistance8 months agoHelpful?
Q: Is there a drain plug to allow water to be drained out of the pump when it is off? Is there a 1 hp shallow well (50-70 feet) pump that does have a drain plug?
a year ago1 Answer
- A: There is a Drain Plug on the Bottom of the Pump Housing. See the drain plug on page #12 in the manual.a year agoHelpful?
Q: Can a replacement capacitor be purchased for these and if so what is the part #.
a year ago1 Answer
- A: Please contact Pentair at 1-800-535-4950 to better assist you.a year agoHelpful?
Q: Do I need to put oil in this pump? My fan is having some trouble turning
a year ago1 Answer
- A: No need any for any OIL. Contact Customer Service at 1-800-535-4950 to better assist you.a year agoHelpful?
Q: I’ve used the 1/2HP pumps in the past. Wanna up grade to the 1 HP pump for more power. I’m pumping 1 hundred horizontal yards. Only have 110 volts to work with. Will the 1HP work with out any issues
2 years ago1 Answer
- A: Contact technical support at 1-800-535-4950 to better assist you2 years agoHelpful?
Q: What is the manufacturer warranty on this product?
2 years ago1 Answer
- A: Contact Customer Service Pentair at 1-800-535-49502 years agoHelpful?
Q: Max pressure production
2 years ago1 Answer
- A: Maximum Pressure Shut off 70 PSI up to 20 ft. 65 PSI from 30 ft. to 70 ft.2 years agoHelpful?
Q: If water input line breaks losing all water supply causing the pump to begin continuous cycling the manual says it will cause the overload to kick off. Assuming this causes the motor to shut down without damage (correct?) what are the recovery steps?
2 years ago1 Answer
- A: Please contact Technical support for Pentair at 262-728-5551.2 years agoHelpful?
1 - 10 of 63 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 63 Questions
Newest questions
Q: Can it be set at 40-60 psi?
3 months ago1 Answer
- A: No, the Pressure Switch that is on this Unit is a 30/50. Reason Being is that this Unit can Only get up to 65psi. There will be some Wear on the Unit over many Years, before the Unit is Not able to get up the 50 Pound Shut Off Pressure.3 months agoHelpful?
Q: what is the on / off pressures?
4 months ago1 Answer
- A: The Pressure Switch that is on this Unit is a 30/50.4 months agoHelpful?
Q: I want to buy the pump parts, the impeller
9 months ago1 Answer
- A: Contact your local TSC store for assistance8 months agoHelpful?
Q: Is there a drain plug to allow water to be drained out of the pump when it is off? Is there a 1 hp shallow well (50-70 feet) pump that does have a drain plug?
a year ago1 Answer
- A: There is a Drain Plug on the Bottom of the Pump Housing. See the drain plug on page #12 in the manual.a year agoHelpful?
Q: Can a replacement capacitor be purchased for these and if so what is the part #.
a year ago1 Answer
- A: Please contact Pentair at 1-800-535-4950 to better assist you.a year agoHelpful?
Q: Do I need to put oil in this pump? My fan is having some trouble turning
a year ago1 Answer
- A: No need any for any OIL. Contact Customer Service at 1-800-535-4950 to better assist you.a year agoHelpful?
Q: I’ve used the 1/2HP pumps in the past. Wanna up grade to the 1 HP pump for more power. I’m pumping 1 hundred horizontal yards. Only have 110 volts to work with. Will the 1HP work with out any issues
2 years ago1 Answer
- A: Contact technical support at 1-800-535-4950 to better assist you2 years agoHelpful?
Q: What is the manufacturer warranty on this product?
2 years ago1 Answer
- A: Contact Customer Service Pentair at 1-800-535-49502 years agoHelpful?
Q: Max pressure production
2 years ago1 Answer
- A: Maximum Pressure Shut off 70 PSI up to 20 ft. 65 PSI from 30 ft. to 70 ft.2 years agoHelpful?
Q: If water input line breaks losing all water supply causing the pump to begin continuous cycling the manual says it will cause the overload to kick off. Assuming this causes the motor to shut down without damage (correct?) what are the recovery steps?
2 years ago1 Answer
- A: Please contact Technical support for Pentair at 262-728-5551.2 years agoHelpful?
1 - 10 of 63 Questions
Similar Items
-
-
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
Items You May Like
-
-
-
Top Rated
-
-
-
-
-
Top Rated
-
-
-
-
Customers Also Bought
-
-
-
Top Rated
-
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
Reviews
- purchase
- installation
- satisfaction
- price
- quality
- noise level
- performance
- volume
1 to 4 of 264 Reviews .
1 – 4 of 264 Reviews
Most Recent
Review 1
5 out of 5 stars.
Good sturdy pump
8 months ago
Good reliable pump. Heavy duty. Easy to set up. Works like a champ. Second one I’ve had. First one didn’t quit, got washed away in a flash flood. I went back to the same pump because the first one worked perfectly for the many years I had it.
Review 1
5 out of 5 stars.
Water pump
a year ago
The pump is running fine
SweepstakesYes
Yes, I recommend this product.
Ohio
Review 1
1 out of 5 stars.
customer NO service
a year ago
would like to give a better review, but I can't. When it worked it worked good. But when I needed a overhaul kit TSC said they can't order it. I called countyline and they sent me back to TSC. I call a differnt TSC and get the same crap. I call countyline and explain what TSC stated. I would have to be desperate to even consider buying another countyline pump.
No, I do not recommend this product.
Kansas
Review 1
3 out of 5 stars.
Faulty but great customer service.
a year ago
Prefer not to write a review on this product as I purchased a faulty pump. It did not provide the pressure it was supposed to. I believe it had a manufacturer defect. Tractor supply had no issue returning the part and refunding me the cost of it. Generally are good pumps, I just happened to purchase a bad one. Tractor Supply provides good home town service and does not have issues correcting situations like this one.
SweepstakesYes
