CountyLine 25-Ton Log Splitter

SKU # 126151799
Product price

Save Up To
See Price at Check Out
Why?
Product Rating is 4.5
4.5
(96)

Financing Available! Click here for more details...

Quantity

Autoship

Delivery Options:

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it. Learn More

power plus

Item Information

A Mean Splitting Machine

If you regularly split wood, this high performance hydraulic log splitter is a fast and affordable way to save time and wear-and-tear on your body. With this impressive piece of equipment, you can easily break up logs with 25 tons of force. It also tilts vertical which is handy when you want to split bigger sized logs.

Easy Maintenance and Mobility

Taking care of your equipment shouldn't be a pain. The Countyline 25-Ton Log Splitter was designed for easy maintenance so you can efficiently clean it on your own. It also comes with durable pneumatic tires that allow you to conveniently haul it down the road or out into the field.

High Quality Kohler Engine

CountyLine 25-Ton Log Splitter uses a model 265 Kohler SH Series engine which is known for having both industry-leading power and a user-friendly design. The Kohler is extremely easy to maintain with an accessible air filter and sparkplug. On top of that, it has dual ball bearing crankshaft design that makes starting up easy and ensure your engine will last longer.

Farm Tested. Out Here Approved

As land owners, we understand that cultivation is a way of life and requires the best possible equipment. Countyline offers an impressive range of farm and ranch products that includes everything from quality tractor parts to affordable sprayers, pumps, tillers, fans, log splitters, and anything else you might need for taking care of life out here. Let's get working.

Specs:
196 cc* Kohler Engine (* as rated by engine manufacturer)
25-ton splitting force**
11.5 second cycle time**
Vertical and horizontal operation
Auto-return valve
Two-stage 14 Gallon Per Minute pump
DOT-approved 4.8 in. x 8 in. wheels
Built-in log cradle holds logs up to 24-1/2 in. length
20 qt. hydraulic reservoir capacity
Warranty: 5-year residential/3-year commercial warranty on beam; 3-year material and workmanship; 2-year engine; 1-year hydraulics

Specification Description
Cycle Time: 11.5 sec.
Engine Displacement: 196 cc
Product Length: 47-5/8 in.
Splitting Force: 25 Ton
Fuel Capacity: 0.16 gal.
Hydraulic Capacity: 16 qt.
Warranty: 5 year warranty on workmanship, 2 year warranty on the engine, 3 year warranty on hydraulics
Positioning: Horizontal/Vertical
Tire Size: 16 in. x 4.80-8
Pump GPM: 14 GPM
Product Width: 39-3/8 in.
CARB Compliant: Yes
Brand: CountyLine
Type: Hydraulic
Maximum Log Length: 26 in.
Power Type: Gas
Horsepower: 6.5 HP
Product Type: Log Splitters
Product Height: 96-5/8 in.
Product Weight: 490 lb.
Engine Make: Kohler
Maximum PSI: 3800 PSI
Manufacturer Part Number YTL016919
CountyLine 25-Ton Log Splitter is rated 4.4 out of 5 by 99.
Rated 5 out of 5 by from Excellent log splitter! I bought this great log splitter today. 25 ton.Took it home at 40 mph. Started 2nd pull first time. First pull second time. Spilt a load of ash. Big rounds. Split wyes. Ripped through it all. very happy with this purchase.
Date published: 2018-07-06
Rated 5 out of 5 by from Great little machine We've used this several times now. Starts right up! Easy to switch from horizontal to vertical. Very stable and sturdy. We have a lot of oak and hickory trees, and we lose one every few years. This was a very good investment.
Date published: 2018-06-29
Rated 5 out of 5 by from Great machine! I bought this log splitter back around the first of March. I have cut and split seven full truck loads of wood with it and it is still going strong. A very good investment!
Date published: 2018-06-28
Rated 3 out of 5 by from Works hard I have owned this machine for 14 months now and it has split some large hard logs including the crotch of a tree with a little hesitation but it split that sucker when I didn't think it could do it. Only reason for 3 stars is it would not start after leaving it sit over the winter and had to replace the carburetor even though I removed all the fuel including gas from the carb. Some research I found that the Kohler SH series engines will have carb failure if left sitting. Hopefully a fuel additive such as Marvel Mystery Oil and starting it once a week will prevent future carb failure.
Date published: 2018-06-19
  • y_2018, m_7, d_18, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_4, tr_95
  • loc_en_US, sid_126151799, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 4ms
  • REVIEWS, PRODUCT

So is the red bracket under the engine for?Is it needed to stay on?

Asked by: Shotgun Shell
The bracket under the engine is for shipping and should be removed prior to sale.
Answered by: ErlindaC
Date published: 2018-04-10

What is the max length for the wood ?

Asked by: josh086
Max log length is 26 inches.
Answered by: KirwinH
Date published: 2017-10-02

What 4 way wedge is compatible with the 25-Ton 2018 Log Splitter?

Asked by: John sumo
We do not have a four way wedge available at this time. We do not have compatibility available from other manufacturers.
Answered by: KirwinH
Date published: 2018-03-28

Does this come fully assembled

Asked by: Dave 701
Please contact your local store for additional information concerning assembly of this product.
Answered by: ErlindaC
Date published: 2018-05-30

Does it come with hydraulic fluid?

Asked by: Bkwlf
The log splitter was prefilled with 9.8 gallons of AW32 hydraulic oil.
Answered by: ErlindaC
Date published: 2018-03-31

What thread pitch/size bolts are the welded nuts on the beam for attaching a log cradle? It did not come with the bolts and the manual does not mention it.

Asked by: Hungaria
The bolt size is M12x1.75x30mm.
Answered by: Valery
Date published: 2018-01-29

Where is it made?

Asked by: Chris300
The log splitters are manufactured in China.
Answered by: KirwinH
Date published: 2018-03-14

What is a built in log cradle? Is that the same as a log catcher?

Asked by: tenn
The Log Cradle is the design of the channel on the beam that centers the log. It is separate from a Log Catcher.
Answered by: ErlindaC
Date published: 2018-07-09
