Grizzly G0766 Variable-Speed Wood Lathe, 22 x 42in.
Item # 229400499
Add this item to unlock free delivery!
Get everything you need
Neighbor’s Club Members earn points with purchases.
Add this item to unlock free delivery!
This item is available online only
Delivery to
For delivery, this item requires a Big & Bulky handling fee.Learn more
Get everything you need
Neighbor’s Club Members earn points with purchases.
A perfect wood lathe for serious woodturners. The G0766 22" x 42" Variable-Speed Wood Lathe is for serious those who want to turn large bowls, furniture pieces, and other large-diameter projects. With 22" of swing, a heavy-duty 1-1/4" x 8 TPI RH spindle, electronic variable speed control and a 3 HP, 3-phase motor that runs off single-phase power using a variable-frequency drive, this lathe has plenty of clearance and torque to easily rough out big projects at low speeds.
The VFD saves you money by increasing the efficiency of the motor and decreasing electricity use. It reduces wear and tear on the motor which extends the life of the sander.
The heavy-duty cast-iron bed and stand make this lathe extremely stable and the headstock can be positioned anywhere along the bed, giving you a wide range of control and flexibility with your projects.
The G0766 manual was written by our U.S.-based Technical Documentation Department and is packed with useful information. The complete and easy-to- read manual makes it easier to assemble and maintain your lathe.
Made in an ISO 9001 factory
ETL certified
SPECIFICATIONS:FEATURES:
Looking for more information on tools? Check out our guide on essential woodworking power tools in the product documents section.
- Motor: 3 HP, 240V, 3-phase (with inverter for single-phase power), 8A
- Required power supply: 240V, single-phase, min. 20A circuit
- Swing over bed: 22"
- Swing over tool rest base: 18"
- Distance between centers: 42"
- Spindle speed: Variable, 100-3200 RPM
- Spindle threads: 1-1/4" x 8 TPI RH
- Spindle taper: MT#2
- Tailstock taper: MT#2
- Tool rest width: 14"
- Tool rest post diameter: 1"
- Overall dimensions: 81" x W 23" D x 49-1/2" H
- Approximate shipping weight: 584 lbs.
- 100-1200 RPM low-speed range
- 330-3200 RPM high-speed range
- Digital readout for spindle RPM
- Headstock positions anywhere along the bed
- Single-phase frequency drive provides 3-phase variable-speed control
- Additional torque without requiring a 3-phase power supply
- 10° spindle indexing
- Tailstock, headstock, and tool rest support have lever-action cam locks for quick positioning
- Forward/reverse spindle control
- 4-1/4" tailstock barrel travel
- Includes spur center, cupped live center, knock-out tool, tool rest, 6" faceplate and indexing pin
| Brand | Grizzly |
|---|---|
| Country of Origin | Imported |
| Amperage | 8A |
| Bed Length | 42 in. |
| Chuck Capacity | 0 in. |
| Chuck Size | 0 in. |
| Cord Length | 6 ft. |
| Decibel Rating | 0 - Not rated |
| Features | No Additional Features |
| Horsepower | 3 hp |
| Material Compatibility | Wood |
| Maximum Speed | 3200 RPM |
| Minimum Speed | 100 RPM |
| Power Type | Electric |
| Product Height | 49.5 in. |
| Product Length | 23 in. |
| Product Weight | 490 lb. |
| Product Width | 81 in. |
| Table Length | 2.25 in. |
| Table Width | 14 in. |
| Variable Speed | Variable Speed |
| Voltage | 240V |
| Warranty | 1 |
| Manufacturer Part Number | G0766 |
