CountyLine 1/2 HP 115/230V Electric Shallow Well Cast Iron Jet Pump, 8.5 GPM
$299.99
CountyLine 1/2 HP 115/230V Electric Shallow Well Cast Iron Jet Pump, 8.5 GPM
Exclusive
CountyLine 1/2 HP 115/230V Electric Shallow Well Cast Iron Jet Pump, 8.5 GPM
Item # 102814299
Stocked & Ready
$299.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
Exclusive
CountyLine 1/2 HP 115/230V Electric Shallow Well Cast Iron Jet Pump, 8.5 GPM
Item # 102814299
Stocked & Ready
$299.99
or
or
$50/mo.† suggested payments with 6 Months Financing or earn $14 in Rewards+ on this purchase.
Out of stock at
Grassland (franklin) TN
Delivery to
Pickup Nearby at SMYRNA TN(20.8) miles FREE
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The CountyLine Shallow Well Cast Iron Jet Pump delivers water from 25 ft. or less. Featuring a rugged cast-iron construction, this pump is built for a long life. The maximum GPM rating is 8.5. CSA approved.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 1/2 HP
- Maximum Depth to Water: 25 ft.
- 115V/230V
- Maximum GPM: 8.5 GPM
- Suction Port Size: 1-1/4 in. NPT
- Outlet Port Size: 1 in. NPT
- 19 in. x 10-5/6 in. x 10-1/2 in.
- 38 lb.
- Cast Iron Body
- CSA Approved
| Brand | CountyLine |
|---|---|
| Country of Origin | Imported |
| Amperage | 8.5 115V 4.2 230V |
| Body Material | Cast iron |
| Compatible Pipe Material | Other |
| Compatible Well Diameter | 1-1/4 in. NPT |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1 in. |
| Discharge Rate at 0 ft. | 8.5 GPM |
| Discharge Rate at 25 ft. | 3.5 GPM |
| Discharge Rate at 50 ft. | 0 N/A |
| Features | CSA Approved |
| Head Pressure | 65 PSI |
| Horsepower | 1/2 HP |
| Impeller Material | Glass-filled polycarbonate |
| Inlet Connection | Threaded Female |
| Inlet Diameter | 1.25 in. |
| Maximum Flow Rate | 8.5 GPM |
| Maximum Head Lift | 25 ft. |
| Maximum Operating Depth | 25 ft. |
| Maximum Operating Temperature | 77 degrees F |
| Minimum Operating Temperature | 32 degrees F |
| Power Type | Electric |
| Product Height | 11 in. |
| Product Length | 19 in. |
| Product Weight | 38 lb. |
| Product Width | 11 in. |
| Motor Type | TEFC |
| Voltage | 115V230V |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | CLTS5 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 65 Questions
Newest questions
Q: Replacement connectors for hose
2 months ago1 Answer
- A: No replacement parts available from vendor. Contact your local TSC store for assistance.2 months agoHelpful?
Q: Is the pressure switch adjustable
3 months ago1 Answer
- A: The Pressure Switch is Set at 30/50. The Switch can be set to a 20/40, by Adjusting ONLY the Tallest Spring in the Middle from Side to Side of the Switch.3 months agoHelpful?
Q: Warranty, guarantee, time
9 months ago1 Answer
- A: 1 Year Limited9 months agoHelpful?
Q: Warranty length
a year ago1 Answer
- A: 1 Year Limited warrantya year agoHelpful?
Q: does this pump have thermal protection? It is currently 100+ degrees here and it stopped working.
2 years ago1 Answer
- A: Please contact Pentair Customer Service at 1-800-535-4950 (pool or pump related) to better assist you.2 years agoHelpful?
Q: Repair Kit For CLTS5 pump
2 years ago1 Answer
- A: For Parts contact Pentair Customer Service at 1-800-535-4950.2 years agoHelpful?
Q: does this pump need a one way valve or a back flow preventer on the intake side? The built up pressure won't hold and pump turns on every few seconds- I think the water is going back into the tank...
2 years ago1 Answer
- A: For Technical Support Please contact Pentair 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: I installed this brand new pump but can't get it to cut on is there anything I need to take off for safety or what
3 years ago1 Answer
- A: Please contact Customer Service at 800-535-4950 to better assist you.3 years agoHelpful?
Q: Purchased and installed the pump. Pump cycles on for 3 seconds and immediately turns off for about 1 1/2 minutes then does it again. Suggestions?
3 years ago1 Answer
- A: Please contact Customer Service at 800-535-4950 to better assist.3 years agoHelpful?
Q: Where are these pumps made?
4 years ago1 Answer
- A: Contact vendor Pentair at 262-728-55514 years agoHelpful?
1 - 10 of 65 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 65 Questions
Newest questions
Q: Replacement connectors for hose
2 months ago1 Answer
- A: No replacement parts available from vendor. Contact your local TSC store for assistance.2 months agoHelpful?
Q: Is the pressure switch adjustable
3 months ago1 Answer
- A: The Pressure Switch is Set at 30/50. The Switch can be set to a 20/40, by Adjusting ONLY the Tallest Spring in the Middle from Side to Side of the Switch.3 months agoHelpful?
Q: Warranty, guarantee, time
9 months ago1 Answer
- A: 1 Year Limited9 months agoHelpful?
Q: Warranty length
a year ago1 Answer
- A: 1 Year Limited warrantya year agoHelpful?
Q: does this pump have thermal protection? It is currently 100+ degrees here and it stopped working.
2 years ago1 Answer
- A: Please contact Pentair Customer Service at 1-800-535-4950 (pool or pump related) to better assist you.2 years agoHelpful?
Q: Repair Kit For CLTS5 pump
2 years ago1 Answer
- A: For Parts contact Pentair Customer Service at 1-800-535-4950.2 years agoHelpful?
Q: does this pump need a one way valve or a back flow preventer on the intake side? The built up pressure won't hold and pump turns on every few seconds- I think the water is going back into the tank...
2 years ago1 Answer
- A: For Technical Support Please contact Pentair 1-800-535-4950 to better assist you.2 years agoHelpful?
Q: I installed this brand new pump but can't get it to cut on is there anything I need to take off for safety or what
3 years ago1 Answer
- A: Please contact Customer Service at 800-535-4950 to better assist you.3 years agoHelpful?
Q: Purchased and installed the pump. Pump cycles on for 3 seconds and immediately turns off for about 1 1/2 minutes then does it again. Suggestions?
3 years ago1 Answer
- A: Please contact Customer Service at 800-535-4950 to better assist.3 years agoHelpful?
Q: Where are these pumps made?
4 years ago1 Answer
- A: Contact vendor Pentair at 262-728-55514 years agoHelpful?
1 - 10 of 65 Questions
Similar Items
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
Top Rated
Items You May Like
-
-
Top Rated
-
-
-
-
-
-
-
-
-
-
Customers Also Bought
-
-
-
-
-
Top Rated
-
-
-
-
-
-
-
Reviews
Summary of Reviews
The water pump appears to be a reliable and effective product for residential and agricultural use. Most customers report the pump is easy to install, provides good water pressure and volume, and operates quietly. Many praise its durability, with some noting it has lasted for years. However, a few c...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
5 out of 5 stars.
Tough as nails
8 years ago
This pump is about 4 years old it has been in a hurricane, flooded, and frozen about five times. The thing still works!
The shed blew down and it floated off in Hurricane Harvey. Tracked it down hooked it up and the thing worked again. It has snowed down here three times since hurricane Harvey and it froze all three times and the thing still works. Going to buy new one and build a new shed over when I get time we have a lot of stuff to fix due to the flooding but this pump still works.
8 people found this helpful
Show Reviews:
Most Helpful Critical Review
1 out of 5 stars.
junk
10 years ago
I bought this product less then a yr ago and it blew apart yesterday now I'm stuck with no water for a week till I get paid again
13 people found this helpful
Show Reviews:
- purchase
- price
- installation
- quality
- noise level
- satisfaction
- water pressure
- reliable
1 to 4 of 394 Reviews .
1 – 4 of 394 Reviews
Most Recent
Reviews 5
2 out of 5 stars.
Parts not available for repair, only 1 year old.
4 months ago
I bought this pump Nov 2024 and recently the hose to the pressure switch came off and it drained the storage tank and burned up the pump end (melted some parts). There is no clamp on this hose on either end. My complaint is the repair kit RPK-205SW doesn't seem to be available anymore thus have to purchase a new pump. The pump worked well until the hose came off. Seems there should be clamps on that hose. I'd still rate it 4 or 5 stars if repair parts were available. I'd expect parts availability for a pump that is just over one year old.
Review 1
1 out of 5 stars.
Junk
a year ago
Pump ran for about 10 months. These things are junk don’t waste your money
Columbus IN
Review 1
1 out of 5 stars.
Poor quality
a year ago
Worked for a couple months and the gasket went out.
No, I do not recommend this product.
Anonymous
Livonia NY
Review 1
5 out of 5 stars.
Affordable and in stock.
a year ago
Great price was easy to order and pick up. glad it was in stock.
SweepstakesYes
Yes, I recommend this product.
