CountyLine Convertible Cast Iron Jet Pump, 1/2 HP

SKU # 102814499
Product price

Save Up To
See price at checkout Why?
Product Rating is 3.8
3.8
(5)

Financing Available! Click here for more details...

Quantity

Autoship

Delivery Options:

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it. Learn More

power plus

Item Information

CountyLine Convertible Cast Iron Jet Pump delivers water from 70 ft. or less. Rugged cast iron construction for long life. Includes pressure regulator, pressure gauge and ejector kit for 4 in. wells or larger.

  • 1/2 HP
  • Maximum Depth to Water: 70 ft.
  • Maximum GPM: 10 GPM
  • Suction Port Size: 1-1/4 in. NPT
  • Outlet Port Size: 1 in. NPT
  • 17-1/3 in. x 13-1/3 in. x 10-4/9 in.
  • 21 lb.
  • Cast Iron
  • CSA Approved
  • 1 year limited warranty
Tractor Supply is proud to introduce CountyLine, our brand of high quality, competitively priced agricultural products. With a full line of 3-point equipment for your tractor, as well an assortment of sub-compact pieces, our goal is to provide you with the implements you need to get the job done. Designed for durability and superior performance, all CountyLine products come with satisfaction guaranteed.

Specification Description
Agency Approvals: CSA
Body Material: Cast Iron
Dual Voltage Motor: Yes
GPH @ 0 ft.: 10 GPM
GPH @ 10 ft. of Head: 9 GPM
GPH @ 15 ft. of Head: 8 GPM
GPH @ 20 ft. of Head: 6.5 GPM
GPH @ 30 ft. of Head: 5 GPM
GPH @ 40 ft. of Head: 4 GPM
GPH @ 50 ft. of Head: 3 GPM
GPH @ 5 ft. of Head: 9.5 GPM
GPH @ 60 ft. of Head: 2.5 GPM
GPH @ 70 ft. of Head: 2 GPM
Horsepower: 1/2 HP
Maximum Depth To Water: 70 ft.
Maximum GPM: 10 GPM
Maximum Pressure Shutoff: 70 PSI up to 20 ft., 65 PSI from 30 ft. to 70 ft.
Outlet Port Size: 1 in. NPT
Product Height: 10-1/2 in.
Product Length: 13-3/8 in.
Product Type: Well Pumps
Product Weight: 21 lb.
Product Width: 17-3/8 in.
Replicable Pressure Switch 30/50: Yes
Self-Priming After Pump Housing Is Filled: Yes
Suction Port Size: 1-1/4 in. NPT
Warranty: 1-Year Limited
Brand: CountyLine
Power Type: Electric
Manufacturer Part Number CL520
CountyLine Convertible Cast Iron Jet Pump, 1/2 HP is rated 3.8 out of 5 by 5.
Rated 3 out of 5 by from I dont really know what went wrong . I dont really know what went wrong ,but my CL520 works great for one year and 3 months after that it burns up gor no reason. Good thing that i purchase an extended warranty and get my mony back.
Date published: 2017-08-18
Rated 5 out of 5 by from Works great I bought this to replace a 3/4 horse pump that went out after 10 years. Took two of us about 2 hours to install. ( no previous experience) pump has been working great on a 60' well.
Date published: 2017-08-17
Rated 5 out of 5 by from great pump works great took several attempts to get it going because the instructions were really vague. Written for someone that already knows how to set it up not for someone that needs instructions!!!!
Date published: 2016-08-24
Rated 1 out of 5 by from worthless I purchased this pump and attempted to use it - it flat out will not pump ! I primed the well until water was running out the suction side line as well as the pressure side , turned on the pump and nothing pressure zero . I found that the pump was actually pushing pressure out both the suction and pressure sides !? this is the second county line pump I have purchased , I also bought a septic pump and had troubles with it as well , upon replacing that one with a red lion pump all my troubles went away . I thought that possibly I just got a bad one in that instance and decided to give them a second chance due to price - bad mistake on my part , I will never purchase anything county line makes again !
Date published: 2015-11-21
  • y_2018, m_8, d_13, h_19
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_5
  • loc_en_US, sid_102814499, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 0ms
  • REVIEWS, PRODUCT

Can this be used for a well deeper than 70 feet

Asked by: Snake
The CL520 cannot be used where the depth of the water is greater than 70 feet. The well can be deeper that 70 feet but suction lift is based on the depth to static (standing) water level in the well.
Answered by: PHailey
Date published: 2017-02-03

i have the 520 pump but need the jet and foot that goes in the well, can i get it from TSC or do i need to order it from some place else. If you carry the parts may i get the part numbers.

Asked by: williamliner
Please contact customer service for this product at 763-545-1730.
Answered by: PHailey
Date published: 2017-07-22

I need a pump for pumping pond water.  Does the CL520 have drain plugs for winter storage?

Asked by: wolf man
The CL520 does have drain plugs for winter storage. They are located near the bottom of the pump head.
Answered by: KirwinH
Date published: 2017-09-29

Everytime this pump goes to cycle I have to help it get started, using a flathead in hole cut into the fan guard. This is the second one I have put in within 24 hours. Both have the same problem. I have tried both 110 and 220

Asked by: PK Rat
Please contact customer service at (888)-376-9601 M-F 8-8 EST. for assistance
Answered by: ErlindaC
Date published: 2018-07-16

can you use float switch with this pump

Asked by: midnite063
No a float switch is not compatible with this pump.
Answered by: Astroer
Date published: 2016-10-03

Can I use a single suction line on a shallow well and what effect would it have?

Asked by: Texans for Trump
It can be set up with the ejector kit attached to the face of the pump so that there is a single line from the pump to the well.
Answered by: ErlindaC
Date published: 2017-11-07

I’m using the cl520 to pump from a pond but can only get 20-25 psi no matter what I do with the pressure screw. What do I need to do to get 35+ psi? I’m only pumping about 10 vertical feet.

Asked by: Ag2342
Please ensure you have the proper voltage selected in the flat box on the top of the pump. Also ensure that the proper nozzle and venture were selected for the jet kit. The jet kit must be used whether it’s a shallow or deep well. If one of the ports on the front of the pump is simply plugged, it will not build pressure. If that is not it, check for suction leaks by putting foaming shaving cream over any joints and fittings on the suction side. Run the pump and if the shaving cream dimples, that indicates air is getting sucked in from that point. Re-seal the connection and see if that fixes the problem. If you’re still having problems, please call us at 1-800-535-4950.
Answered by: ErlindaC
Date published: 2018-04-17

What is the size of the drain port on the bottom of the pump

Asked by: Tth 616
This port is tapped ¼ inch female pipe thread.
Answered by: ErlindaC
Date published: 2017-11-15
