CountyLine 1 HP 230V Electric 3-Wire Series 4 in. Submersible Pump, 14.7 GPM
$719.99
CountyLine 1 HP 230V Electric 3-Wire Series 4 in. Submersible Pump, 14.7 GPM
Exclusive
CountyLine 1 HP 230V Electric 3-Wire Series 4 in. Submersible Pump, 14.7 GPM
Item # 102890199
$719.99
or
or
Add this item to unlock free delivery!
Add a protection plan
Powersport plans are not available in CA.
Get everything you need
Neighbor’s Club Members earn points with purchases.
Exclusive
CountyLine 1 HP 230V Electric 3-Wire Series 4 in. Submersible Pump, 14.7 GPM
Item # 102890199
$719.99
or
or
$55/mo.† suggested payments with 12 Months Financing or earn $32 in Rewards+ on this purchase.
Add this item to unlock free delivery!
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Add a protection plan
Powersport plans are not available in CA.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The CountyLine 3-Wire 1 HP 10 GPM Series 4 in. Submersible Pump is ideal for residential water systems and agricultural applications 300 ft. deep or less. Featuring a proven floating stack impeller design for sand resistance and reduced sand locking, this heavy-duty stainless steel pump is built to last. The pump is rated for 230V and is backed by a 3 year limited warranty.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 1 HP
- Maximum depth to water: 300 ft.
- 230V
- 6 in. x 4-5/8 in. x 40 in.
- 39 lb.
- Stainless steel body
- CSA approved
- Includes: Control Box
- Tractor Supply is proud to introduce CountyLine, our brand of high quality, competitively priced agricultural products; with a full line of 3-point equipment for your tractor, as well an assortment of sub-compact pieces
- 3 year limited warranty
| Brand | CountyLine |
|---|---|
| Country of Origin | Made in USA |
| Amperage | 10.8 Amps |
| Body Material | Stainless steel |
| Compatible Pipe Material | Other |
| Compatible Well Diameter | 4 in. |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1.25 in. |
| Discharge Rate at 0 ft. | 14.7 GPM |
| Discharge Rate at 25 ft. | N/A |
| Discharge Rate at 50 ft. | 15 GPM |
| Features | Control Box Included |
| Head Pressure | 130 PSI |
| Horsepower | 1 HP |
| Impeller Material | Engineered thermoplastic |
| Inlet Connection | None |
| Inlet Diameter | N/A |
| Maximum Flow Rate | 14.7 GPM |
| Maximum Head Lift | N/A |
| Maximum Operating Depth | 300 ft. |
| Maximum Operating Temperature | 86 degrees F |
| Minimum Operating Temperature | 32 degrees F |
| Power Type | Electric |
| Product Height | 40 in. |
| Product Length | 6 in. |
| Product Weight | 37 lb. |
| Product Width | 5 in. |
| Motor Type | Submersible |
| Voltage | 230V |
| Warranty | 3 Year Limited |
| Manufacturer Part Number | CL30610 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 22 Questions
Newest questions
Q: warranty i am wanting to know what the limited warranty is .
10 days ago1 Answer
- A: Refer to the Product Documents, page 12 for the warranty on the product.10 days agoHelpful?
Q: Why does it come with a 4th wire when it says it's a 3 wire
11 days ago1 Answer
- AI-generated, Human-approvedA: This pump is classified as a 3-wire model because it requires three power wires (typically red, yellow, and black) to connect to the included control box. The fourth wire is a green ground wire, which is standard for safety but not counted in the "3-wire" designation.10 days agoHelpful?
Q: Does the pump have a built-in check valve?
2 months ago1 Answer
- A: Yes, the CountyLine 1 HP Submersible Pump has a built-in check valve integrated directly inside the top discharge end of the pump2 months agoHelpful?
Q: set 300 foot deep can a 40-60 pressur switch be used
9 months ago1 Answer
- A: For questions contact Pentair 888-782-7483.9 months agoHelpful?
Q: How much does it pump per hour?
a year ago1 Answer
- A: Please contact Customer Service at 888-782-7483. to better assist you.a year agoHelpful?
Q: Do you need to use control box with this pump
2 years ago1 Answer
- A: A 3-wire pump will not operate without a control box and will burn out a 3-wire motor.2 years agoHelpful?
Q: Is this pump a single phase!
3 years ago1 Answer
- A: Please Contact Customer Service at 888-782-7483.3 years agoHelpful?
Q: For this particular pump what does the control box include? If for instance it contains a start capacitor and a run capacitor could you possibly give me the specs or microfarads for each and the model or part number for start relay
3 years ago1 Answer
- A: Please contact Pentair Customer Service 888-782-7483 to better assist you.3 years agoHelpful?
Q: What size is the discharge?
3 years ago1 Answer
- A: Please contact Pentair 888-782-7483 to better assist you.3 years agoHelpful?
Q: Do you have to use the control box for this pump? I currently have a 1hp 3 wire pump but it doesn't have a control box, just a pressure switch.
4 years ago1 Answer
- A: A 3-wire pump will not operate without a control box and will burn out a 3-wire motor.4 years agoHelpful?
1 - 10 of 22 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 22 Questions
Newest questions
Q: warranty i am wanting to know what the limited warranty is .
10 days ago1 Answer
- A: Refer to the Product Documents, page 12 for the warranty on the product.10 days agoHelpful?
Q: Why does it come with a 4th wire when it says it's a 3 wire
11 days ago1 Answer
- AI-generated, Human-approvedA: This pump is classified as a 3-wire model because it requires three power wires (typically red, yellow, and black) to connect to the included control box. The fourth wire is a green ground wire, which is standard for safety but not counted in the "3-wire" designation.10 days agoHelpful?
Q: Does the pump have a built-in check valve?
2 months ago1 Answer
- A: Yes, the CountyLine 1 HP Submersible Pump has a built-in check valve integrated directly inside the top discharge end of the pump2 months agoHelpful?
Q: set 300 foot deep can a 40-60 pressur switch be used
9 months ago1 Answer
- A: For questions contact Pentair 888-782-7483.9 months agoHelpful?
Q: How much does it pump per hour?
a year ago1 Answer
- A: Please contact Customer Service at 888-782-7483. to better assist you.a year agoHelpful?
Q: Do you need to use control box with this pump
2 years ago1 Answer
- A: A 3-wire pump will not operate without a control box and will burn out a 3-wire motor.2 years agoHelpful?
Q: Is this pump a single phase!
3 years ago1 Answer
- A: Please Contact Customer Service at 888-782-7483.3 years agoHelpful?
Q: For this particular pump what does the control box include? If for instance it contains a start capacitor and a run capacitor could you possibly give me the specs or microfarads for each and the model or part number for start relay
3 years ago1 Answer
- A: Please contact Pentair Customer Service 888-782-7483 to better assist you.3 years agoHelpful?
Q: What size is the discharge?
3 years ago1 Answer
- A: Please contact Pentair 888-782-7483 to better assist you.3 years agoHelpful?
Q: Do you have to use the control box for this pump? I currently have a 1hp 3 wire pump but it doesn't have a control box, just a pressure switch.
4 years ago1 Answer
- A: A 3-wire pump will not operate without a control box and will burn out a 3-wire motor.4 years agoHelpful?
1 - 10 of 22 Questions
Similar Items
-
-
-
-
-
-
Top Rated
-
-
-
Top Rated
-
-
-
Frequently Bought Together
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
-
-
-
Top Rated
-
Top Rated
-
Top Rated
-
Reviews
- purchase
- installation
- satisfaction
- warranty
- exchanges
- performance
- price
- design
1 to 4 of 76 Reviews .
1 – 4 of 76 Reviews
Most Recent
Fort Stockton, TX
Review 1
1 out of 5 stars.
Bad quality
4 months ago
Durability is just bad. Ive replaced it twice in less than three years. Im going to have to order a better quality one some where else.
No, I do not recommend this product.
Seminole
Reviews 2
5 out of 5 stars.
Easy to install
2 years ago
Very efficient easy to install
SweepstakesYes
Yes, I recommend this product.
Review 1
4 out of 5 stars.
Submersible Pump
2 years ago
It was replacing one purchased in February that went out. Also had to drive to a TSC store far from home to find one in stock to get immediately.
Harrison Valley, Pa
Review 1
1 out of 5 stars.
Works great, if you like changing every 3 months.
3 years ago
Every 3 months we have to replace the pump. We used to keep buying from tractor supply BUT this is a huge inconvenience and now will go somewhere else. Not to mention the fact tractor supply wants to gice us an issue about returning the bad pumps. Never had to do anything with it for over 10 years. Then it went ro 3 years now it's gone to every 3 months step up your game tractor supply!
Sweepstakes EntryNo
No, I do not recommend this product.
