CountyLine Stainless Steel Transfer Utility Pump, 1 HP

SKU # 102813699
Product price

Save Up To
See price at checkout Why?
Product Rating is 4.0

Financing Available! Click here for more details...



Delivery Options:

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it. Learn More

power plus

Item Information

CountyLine Stainless Steel Transfer Utility Pump is ideal for boosting pressure up to 80 PSI to wash cars, boats, tractors; as well as a sprinkler. It supports multiple lawn sprinklers pumping from lakes, streams or ponds.

  • 1 HP
  • 6 ft. power cord
  • Maximum Suction Lift: 20 ft.
  • Outlet Port Size: MNPT
  • 15-1/2 in. x 9 in. x 11 in.
  • 22-1/3 lb.
  • Stainless Steel
  • CSA Approved
  • 1 year limited warranty
Tractor Supply is proud to introduce CountyLine, our brand of high quality, competitively priced agricultural products. With a full line of 3-point equipment for your tractor, as well an assortment of sub-compact pieces, our goal is to provide you with the implements you need to get the job done. Designed for durability and superior performance, all CountyLine products come with satisfaction guaranteed.

Specification Description
Agency Approvals: CSA
Body Material: Stainless Steel
GPH @ 0 ft. head: 534 GPH
GPH @ 10 ft. of Head: 426 GPH
GPH @ 15 ft. of Head: 354 GPH
GPH @ 20 ft. of Head: 270 GPH
GPH @ 5 ft. of Head: 498 GPH
Horsepower: 1 HP
Maximum Suction Lift: 20 ft.
Oil Filled Motor: Yes
Outlet Port Size: MNPT
Power Cord Length: 6 ft.
Product Height: 11 in.
Product Length: 9 in.
Product Type: Utility Pumps
Product Weight: 22.5 lb.
Product Width: 15-1/2 in.
Volts: 115 V
Warranty: 1-Year Limited
Brand: CountyLine
Power Type: Electric
Manufacturer Part Number CLSS5
CountyLine Stainless Steel Transfer Utility Pump, 1 HP is rated 4.0 out of 5 by 8.
Rated 1 out of 5 by from Motor burned up Pump lasted 2hrs and the motor burned up, got replacement insurance but haven't decided to replace or return yet. Not recommended for extended use
Date published: 2018-01-09
Rated 5 out of 5 by from Works great! So far I've used it twice, one of them was for over two hours straight with no problem. I would definitely recommend it.
Date published: 2017-09-05
Rated 5 out of 5 by from Great Little Pump I needed a pump to water my lawn using water from my lake. It is powerful enough to run multiple sprinklers at the same time. Also use it to provide water to my pressure washer to clean my white vinyl fence. I mounted it to a Tractor Supply utility cart along with a generator.
Date published: 2016-08-15
Rated 4 out of 5 by from Works good but beware of non-U.S. pipe threads I bought this to put in-line to boost the pressure and flow in a garden hose to supply a single yard sprinkler, so this review reflects how it worked for my application. It comes with two plastic 1” NPT to male garden hose thread adapters. This means you’ll need to use either a washing machine (double female) supply hose, or a double female adapter to connect the supply hose to the pump. Here’s the real issue; The pump inlet and outlet ports have 1” BSP (British Standard Pipe) treads, which is similar to our U.S. standard 1” NPT, except BSP uses a 55 degree thread angle with 11 threads per inch, whereas NPT uses 60 degree threads and 11 ½ threads per inch. This means even though they will go together, they will leak, even when using copious amounts Teflon tape. You’re not going to find BSP fittings at your local plumbing supply house either. I ended up using 1” NPT brass fittings with male and female garden hose threads instead and lots of Teflon tape. It still leaks a little, a few drips a second, but is not a problem in my outdoor application. Performance wise, it increases the pressure by 35 psi at the sprinkler head with water flowing, so it does what I expected it to very nicely.
Date published: 2015-05-16
  • y_2018, m_8, d_19, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_7
  • loc_en_US, sid_102813699, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 2ms

what type of impeller does this unit have? or is it a gear pump? thanks Don

Asked by: dfanklin58
The impeller in this pump is made from thermoplastic material.
Answered by: ErlindaC
Date published: 2018-03-07

Can a garden hose be hooked to outlet with a nozzle that will be turned on and off?

Asked by: New Orleans
On model CLSS5 you cannot block the output of the pump with a nozzle. The pump cannot turn itself off.
Answered by: Valery
Date published: 2017-08-18

Is there a pressure switch?

Asked by: Wash Ashore
This does not have a pressure switch.
Answered by: Valery
Date published: 2017-04-03

Are all your water pumps made in China?

Asked by: Whitney123
The country of origin for this pump is Italy. Our pumps come from various manufacturing sites worldwide.
Answered by: Astroer
Date published: 2016-09-19

Does the pump have run-dry protection?

Asked by: Andy47
This Model does NOT have run dry protection.
Answered by: KirwinH
Date published: 2017-10-18

What is the max lift of this pump?

Asked by: Karl513
The maximum suction lift on CLSS is 20 feet.
Answered by: Valery
Date published: 2017-04-24

Does this pump have an on/off switch?

Asked by: Coventry
Yes this have a on and off switch. Please contact customer service at 800-535-4950 for technical assistance.
Answered by: ErlindaC
Date published: 2018-06-18

Will this pump waste oil? If not what would you recommend?

Asked by: DTFire
The CountyLine pumps we manufacture are only meant to pump clear water, so no. It will not pump oil.
Answered by: ErlindaC
Date published: 2018-04-19
