GPI M-150S-EM Fuel Pump, 110000-107TSC

SKU: 395810599
GPI M-150S-EM Fuel Pump, 110000-107TSC
Enter Zip Code for price More Info
Product price

Save Up To
See price at checkout More Info
Product Rating is 4.6
4.6
 (232)

Quantity

TSC of  #

,
TSC of  #

,
TSC of  #

,
TSC of  #

,
Check Availability at Other Stores
Standard Delivery Not Available to
Notice: This item will ship within 0 days.
This product may require up to 0 additional days for order processing prior to shipping.
Change Delivery Location
Protect your purchase with Power Plus
Protect Your Purchase Click here for more details...

We'll fix it, replace it, or reimburse you for it.

Item Information

The GPI M-150S-EM Fuel Pump comes with a standard nozzle hanger and 10 feet of 3/4 inch hose.

  • Material: Heavy Duty Cast Aluminum
  • Voltage Rating: 12-volt DC
  • Flow Rate: Up to 15 gpm/57 lpm
  • For use with Gasoline (up to 15% alcohol blends such as E15), diesel fuel (up to 20% bio-diesel blends such as B20) and kerosene
  • Direct tank mount
  • U.L. Listed motor and CSA certified
  • Two-piece PVC suction pipe
  • Maximum pressure: 15 PSI
  • Inlet port size: 1 in.
  • Outlet port size: 3/4 in.
  • 16 in. W x 19 in. L x 9 in. H
  • Aluminum housing
  • 2 year limited warranty

Specification Description
Horsepower: 1/5 HP
Inlet Diameter: 1 in.
Product Weight: 23.75 lb.
CountryofOrigin: Made in USA
Part Number: 110000-107TSC
Nozzle Type: Manual
Maximum Discharge Pressure: 15 PSI
Intended Use Grade: Commercial, Industrial, Residential, Standard
Maximum Flow Rate: 15 GPM
Housing Material: Heavy Duty Cast Aluminum
Brand: GPI
Maximum Lift: 5.5 ft.
Amperage: 18 Amp
Self-Priming: Yes
Maximum Speed: 1,900 rpm
Inlet Connection: Threaded Male
AC or DC Powered: DC
Power Type: 12 Volt
Product Width: 16 in.
Hose Length: 10 ft.
Special Feature(s): Independent lab tested, the GPI M-150S received a Gold Medal Performance award for delivering three times more operating hours than our leading competitor's comparable pump.
Compatible Fluids: Gasoline (up to 15% alcohol blends such as E15), diesel fuel (up to 20% bio-diesel blends such as B20) and kerosene
Discharge Diameter: 3/4 in.
Product Height: 9 in.
Voltage: 12 V
Outlet Size: 3/4 in.
Maximum Total Head: 5.5 ft.
Discharge Connection: Threaded Female
Seal Type: NBR
Type: Fuel Pumps
Inlet Size: 1 in.
Product Length: 19 in.
Manufacturer Part Number 110000-107TSC
GPI M-150S-EM Fuel Pump, 1/5 HP, 1 in. Inlet, 110000-107TSC is rated 4.7 out of 5 by 187.
Rated 5 out of 5 by from Very Good Pump This is a very good pump . Rigged up with a filter on 100 gallon tank and it works very well
Date published: 2019-08-02
Rated 5 out of 5 by from Actually works great. Works as designed, easy to install. The pump is strong and makes filling up our farm equipment easy.
Date published: 2019-07-27
Rated 1 out of 5 by from M&R farms I bought 1 of these in the spring of 2016 and another one in the fall of 2016 the one I bought in the spring worked great till it was one mounth out of warranty now it will pump 5 gallons and quit like you turned the switch off and you can turn it off let it sit for 10 minutes and it will pump another 5 gallons very unsatisfactory takes me a hour or longer to fill the tractor up. The other one has worked great but is starting to do the same thing the other one is doing after about 25 gallons. I think I’m going to go back to the fill rite. The last one we had lasted over 15 years with no problems at all !!
Date published: 2019-06-08
Rated 5 out of 5 by from Fuel pump Great pump. Just wish it came with clamps to hook up to battery.
Date published: 2019-05-26
  • y_2019, m_8, d_5, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_90, tr_97
  • loc_en_US, sid_395810599, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 4ms
  • REVIEWS, PRODUCT

I use a small solar panel to charge my battery to run this pump. Please describe what battery to buy for this use; cranking amps,reg or deep cycle (preferred) etc.

Asked by: TCMCN1
The 12VDC pumps are designed to be ran off a car battery. You can find amp draw, psi ratings etc. from the back of the owner's manual under specifications. The current draw is 18 amps. I'm honestly not sure how well a solar panel would work in charging a car battery for this to operate... Any other questions please give us a call at 316-686-7361. Thank you, GPI sales team.
Answered by: GPI Inside Sales
Date published: 2019-04-02

How much wire does it come with? Is there battery clamps for battery hook up?

Asked by: jay2
Hello, These pumps come with an 18 foot power cord that is pre installed. the battery clamps are sold separate. Thanks, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-06-22

Need to remove auto fuel tank . looking for a pump to remove fuel from an automobile tank thru where it is filled. into a barrel. Which pump would be best ?

Asked by: Hal F
Hello, Well none of our pump are designed to pump fuel out of a car and into a drum. Our pumps are designed to do the opposite. The reason is you need a ridged suction pipe, but if your drawing out of a car you would need some sort of flexible tubing or hose to snake down into the tank, and there is no way to mount our pump safely. Sorry we couldn't be more help. Thank You, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-07-31

can this pump be used to transfer used motor oil

Asked by: harley two
Hello, the M-150S-EM is made for Gas, Diesel or Kerosene. it will not transfer used motor oil. Used oil is to thick and the pump will struggle to keep a good suction with oil, clean or dirty. Thanks, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-07-17

What is a good fuel water separator to add to this unit?

Asked by: Unberlievable
Hello, You would want to use p/n# 133527-01 3/4" filter kit, then a water/particulate filter. Thank you, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-10-19

does it come with everything needed for installation and electrical hookup?

Asked by: Charles2018
Hello, Yes this pump will come with everything you need for installation on to your tank. This includes hose, nozzle, pump, wiring, pipe tape. It is all included. Thank you, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-06-20

Can this be converted to fit on a tank with a 2" NPT inlet?

Asked by: EnixFF
Hello, This pump is already setup to go on a 2" NPT inlet. It's ready to go straight out of the box. Thanks, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-06-22

Does up have an on/off switch in case it is hardwired 12v?

Asked by: ScottyO
Hello, We do not offer a remote on / off switch, with any fuel pump the switch is located right on the pump for safety. Thank you, GPI Sales Team.
Answered by: GPI Inside Sales
Date published: 2018-09-19
