GPI G20 20 GPM 12V DC fuel transfer pump with automatic shut-off diesel nozzle. TRUE 20 GPM flow that's Quick-Fit ready! Not only can the GPI G20 deliver true 20 GPM flow, but it's designed for GPI's exclusive Quick-Fit modular accessories. What this means to you: 20 GPM you can count on and the ability to customize your personal fuel station. The powder-coated motor can and diecast aluminum body makes it extremely dependable and lightweight at only 19 lbs. The pump is corrosion-resistant and ready to withstand years of work in any application. Factory-Installed power cord saves installation time. Spin collar mount makes installation and pump orientation easy! Combo includes 1" NPT automatic diesel shut-off nozzle designed to attach to a 1-inch fuel hose for safe, reliable dispensing of gasoline, diesel fuel, and kerosene. One-finger design with hold-open clips lets you quickly set the desired flow rate while reducing spillage.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on truck accessories? Check out our guide on truck accessories in the product documents section.
- Quick-fit modular design with simple four-bolt connection points allows you to attach a filter, meter or both easily and build a custom system to fit your needs
- Manufactured from high-quality die-cast aluminum, our 12V fuel pump with automatic nozzle is extremely dependable and lightweight
- Rotary gear pump is engineered with fewer moving parts, which means less friction and wear on its components; thus this rotary gear pump will have fewer needed repairs and longer life than a rotary vane pump
- 12VDC motor of our fuel transfer pump is highly efficient as it delivers gasoline, diesel fuel, ethanol blends, and kerosene at flow rates up to 20 GPM
- Fuel transfer pump has an integrated circuit breaker to prevent overheating, extending the overall pump life
- Innovative spin collar design of our fuel transfer pump 12V makes installation fast and easy
- Will put minimal stress on your tank bung
- Aluminum housing is rugged and corrosion-resistant to withstand years of work in any application
- Factory-Installed power cord saves installation time
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Weight: 19 lb. (8.6 kg)
| Brand | GPI |
|---|---|
| Country of Origin | Made in USA |
| AC or DC Powered | DC |
| Amperage | 40A |
| Body Materials | Aluminum |
| Compatible Fluids | Diesel, Gasoline, Gasoline/Ethanol, Kerosene |
| Discharge Connection | None |
| Discharge Diameter | 1 in. |
| Duty Cycle | 30 min. on/off |
| Features | Self-Priming |
| Horsepower | 0.4 HP |
| Hose Diameter | 1 in. |
| Inlet Connection | Threaded Female |
| Inlet Diameter | 1 in. |
| Intended Use Grade | Standard |
| Maximum Flow Rate | 20 GPM |
| Maximum Head Lift | 9 ft. |
| Maximum Operating Pressure | 15 PSI |
| Maximum Operating Temperature | 125 deg. F |
| Minimum Operating Pressure | 1 PSI |
| Minimum Operating Temperature | -20 deg. F |
| Power Cord Length | 18 ft. |
| Power Type | Electric, 12 Volt |
| Product Height | 9.24 in. |
| Product Length | 11.62 in. |
| Product Weight | 35 lb. |
| Product Width | 9.2 in. |
| Voltage | 12V |
| Warranty | Limited Lifetime |
| Manufacturer Part Number | 162000-03TSC |
Q: Does it come with the hose or tube to go in the tank?
9 months ago- A: Yes, the GPI Fuel Transfer Pump comes with both a dispensing hose and a telescoping suction pipe.9 months agoHelpful?
