Kohler-Rehlko Command Pro Commercial Series 9.5 hp Lawn Mower Engine, Recoil Start
Kohler-Rehlko Command Pro Commercial Series 9.5 hp Lawn Mower Engine, Recoil Start
Item # 124549199
$729.99
or
or
Notice:
This Item cannot be shipped to CA.
Neighbor’s Club Members earn points with purchases.
Kohler-Rehlko Command Pro Commercial Series 9.5 hp Lawn Mower Engine, Recoil Start
Item # 124549199
$729.99
or
or
$61/mo.† suggested payments with 12 Months Financing or earn $36 in Rewards+ on this purchase.
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Notice:
This Item cannot be shipped to CA.Neighbor’s Club Members earn points with purchases.
Experience true power when you try this lawn mower engine. The Kohler-Rehlko Command PRO Commercial Series 9.5 HP Engine is equipped with a 1.0 in. (25.4mm) dia. x 3.49 in. PTO length crankshaft. with a satellite exhaust valve and dual ball bearings, this Kohler-Rehlko lawn mower engine has an electronic ignition feature. Complete with a cast-iron cylinder liner, this riding mower engine is the ultimate in durability.3 years
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on lawn mower maintenance? Check out our guide on lawn mower maintenance in the product documents section.
- Fuel secure auto-fuel shut off
- Overhead valve design
- Kohler-Rehlko lawn mower engine features electronic ignition
- Quad-Clean 4-stage all-season heavy-duty cyclonic air cleaner
- Lawn mower engine has variable speed options
- Dual oil fill locations and oil drains
- Cast iron cylinder liner
- 7-liter metal tank with strainer
- Fuel shut-off valve (unless otherwise mentioned)
- Satellite exhaust valve
- Engine-mounted throttle and choke controls, remote throttle ready
- Oil Sentry switch installed (no light)
- Dual ball bearings, PTO and flywheel balance shaft
- Metal blower housing
- Index-able recoil starter
- PTO face included with riding mower engine
- For engines with SAE crankshaft: 6.5 in. dia. bolt circle (4 holes) 3/8-16 UNC thread x 0.71 in. D and 5 in. dia. bolt circle (4 + 2 holes) 5/16-24 UNF threads x 0.71 in. D
- Large capacity muffler with heat shield and spark arrestor
- Multi-language owner's manual
- Color: black with cast aluminum
- Compliance Information: CARB Tier III, EPA Phase 3, RFI compliant
- 3 year commercial and consumer limited warranty
- Engine includes keyway for ease
| Brand | Kohler-Rehlko |
|---|---|
| Country of Origin | Imported |
| Brand Compatibility | Universal |
| Engine Displacement | 429cc |
| Engine Make | Kohler |
| Engine Type | 4-cycle |
| Features | CARB Compliant |
| Fuel Capacity | 7.4 L |
| Fuel Type | Gasoline |
| Horsepower | 9.5 HP |
| Model Compatibility | Universal |
| Oil Capacity | 1.16 qt. |
| Orientation | Horizontal |
| Product Type | Mower Engines |
| Primary Material | Aluminum |
| Product Height | 16.8 in. |
| Product Length | 12.4 in. |
| Product Weight | 61.5 lb. |
| Product Width | 17.8 in. |
| Recommended Oil Type | Kohler 10W-30 |
| Warranty | 3 Year |
| Manufacturer Part Number | PA-CH395-3149 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 2 of 2 Questions
Newest questions
Q: Does this model allow for electric start?
2 years ago1 Answer
- A: No, electric start can not be added. There is no provision on the block to mount the starter and no ring gear on the flywheel. The only option is to purchase an engine in that size with electric start.2 years agoHelpful?
Q: I need a lawn tractor motor in the 8 to 14 hp range that has a clockwise shaft rotation. what is the shaft rotation on this engine, do you make engines that rotate clockwise?
7 years ago1 Answer
- A: What engine do you have on the mower now? Brand, Model and spec numbers ect. Is it a vertical shaft engine or a Horizontal shaft engine.7 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 2 of 2 Questions
Newest questions
Q: Does this model allow for electric start?
2 years ago1 Answer
- A: No, electric start can not be added. There is no provision on the block to mount the starter and no ring gear on the flywheel. The only option is to purchase an engine in that size with electric start.2 years agoHelpful?
Q: I need a lawn tractor motor in the 8 to 14 hp range that has a clockwise shaft rotation. what is the shaft rotation on this engine, do you make engines that rotate clockwise?
7 years ago1 Answer
- A: What engine do you have on the mower now? Brand, Model and spec numbers ect. Is it a vertical shaft engine or a Horizontal shaft engine.7 years agoHelpful?
Similar Items
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
-
-
-
Top Rated
Items You May Like
-
Top Rated
-
-
-
Top Rated
-
-
-
-
Top Rated
-
-
-
-
Customers Also Bought
-
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
-
-
-
Reviews
- oil
1 to 1 of 1 Review .
1 – 1 of 1 Review
Most Recent
Red Oak, Virginia
Reviews 3
5 out of 5 stars.
Hope this one lasts longer!
2 years ago
Very nice engine, at at least for now since the old engine blew up after only 3 years. Also manual needs more information, like oil requirements and type.
No, I do not recommend this product.
