Hobart Handler 190 MIG Welder, 190A, 230V, 500554

SKU: 102102799
Hobart Handler 190 MIG Welder, 190A, 230V, 500554
Enter Zip Code for price More Info
Product price

Save Up To
See price at checkout More Info
Product Rating is 4.9
4.9
 (190)

Quantity

TSC of alexandria #1392
7910 alexandria pike
alexandria, KY 41001
(859) 448-0936
TSC of alexandria #1392
7910 alexandria pike
alexandria, KY 41001
(859) 448-0936
Check Availability at Other Stores
Standard Delivery Not Available to
Notice: This item will ship within 0 days.
This product may require up to 0 additional days for order processing prior to shipping.
Change Delivery Location
Protect your purchase with Power Plus
Protect Your Purchase Click here for more details...

We'll fix it, replace it, or reimburse you for it.

Item Information

Handler 190 MIG Welder - An industrial performance welder that is spool gun ready for aluminum. Runs on 230V input power, welds up to 5/16 in. mild steel and is flux-cored or MIG ready.

  • 7 voltage selections, enhanced magnetics and infinite wire feed speed control - Offers easier fine control of the output parameters for improved arc performance with less spatter for a better bead appearance and less clean up.
  • Accepts uncomplicated, easy-to-install direct plug-in SpoolRunner 100 spool gun- spool guns enhance feedability and reduce "bird-nesting" associated with soft aluminum wires.
  • Quickly reference initial settings for different wires, gases, materials and thicknesses. Provides quick starting point for novices and professionals alike.
  • Eases use and excellent safety feature which makes wire electrically "cold" until trigger is pulled.
  • Professional and durable wire feed performance.
  • Access makes it quick and easy to change polarity for solid or tubular wire. Includes convenient storage holes for spare tips.
  • Quick Select drive roll - Makes setup quicker by offering three grooves - two for different size solid wires and a third for flux-cored wire.
  • Short circuit protection - Protects unit against current overload.
Hobart 5/3/1 Industrial Warranty

Specification Description
Spool Size Capacity: 4 or 8 in. spools
Rated Output at 20% Duty Cycle: 160 A
Solid Wire and/or Flux Cored: Solid Wire and Flux Cored
Product Height: 12.375 in.
Special Feature(s): Spool gun ready
Brand: Hobart
Input Voltage: 220/230/240 V
CountryofOrigin: Made in USA
Maximum Wire Diameter: .045 in.
Part Number: 500554
Product Width: 10.625 in.
Gun Length: 10 ft.
Application/Use: Maintenance/repair, Auto body, Farm/ranch, Home repair, DIY, Metal art
Wire Feed Speed Range: 40 IPM - 740 IPM
Amperage Input at Rated Output (60 Hz) - KVA: 230 V: 25-190 Amps
Maximum Open Circuit Voltage: 31 VDC
Amperage Input at Rated Output (60 Hz) - KW: 20.5 V, 4.7 KVA, 3.88 KW
Amperage Range: 25-190 Amps
Clamp Cable Length: 10 ft.
Product Weight: 68 lb.
Product Length: 19.5 in.
Maximum Material Thickness: Mild Steel 24 ga. (0.8 mm) - 5/16 in.
Compatible Metal: Stainless Steel / Steel / Aluminum
Ground Cord Length: 10 ft.
Current Range: DC
Output Amperage Range: 130 A at 21.5 VDC, 30% duty cycle
Amperage Input at Rated Output (60 Hz) - 115V: 130 A at 21.5 VDC, 30% duty cycle
Manufacturer Part Number 500554
Hobart Handler 190 MIG Welder, 190A, 230V, 500554 is rated 4.9 out of 5 by 190.
Rated 5 out of 5 by from Nice little mig rig. Works great for the money nice even arc. I was very pleased.
Date published: 2020-03-23
Rated 5 out of 5 by from Good AMERICAN made welder. Works great and tunes well to various conditions. Good price on an American made welder.
Date published: 2020-03-20
Rated 5 out of 5 by from Great welder I have been welding for less than a year as a hobby. I have taken one class at the local votech. My welds using my flux core machine were ugly and difficult to lay down. I was a little better with my stick machine but like the flux core it created a lot of smoke. I was going to buy the Hobart 140 but decided to just go all in on a 240 volt welder. This thing is awesome. I can actually make welds like it looks like I know what I’m doing. I’m working on my old brush hog deck that requires joining parts that are not the same thickness. With the flux core I was blowing holes in 16 gage when trying to tie it to 1/8” plate. With the Hobart 190 it seems I can always find the right settings to make it work. The settings given under the spool cover seem to be pretty much spot on for joining similar thickness materials but I usually back off to the next lower setting to join plate with sheet metal and it works fine if you keep the heat focused on the thicker part. I had an electrician install a 240 volt outlet in my garage so I could stop having to run an extension cord to the dryer outlet. Very glad I went with the Hobart.
Date published: 2020-03-08
Rated 5 out of 5 by from Welder Great Welder for projects around the farm. Would recommend this welder to anybody.
Date published: 2020-03-05
  • y_2020, m_3, d_27, h_13
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.5
  • cp_1, bvpage1
  • co_hasreviews, tv_57, tr_133
  • loc_en_US, sid_102102799, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 5ms
  • REVIEWS, PRODUCT

Is 190 mig inverter or transformer

Asked by: Bobbyron
Transformer
Answered by: NRoberts
Date published: 2020-03-19

CAN THIS WELDER BE OPERATED OFF A GEERATER

Asked by: JOE L JR
Yes this unit can be powered from a generator. A 7000 watt continuous would be required to achieve max output of 190 amps and 5000 watt to achieve rated output of 130 amps.
Answered by: Hobart Specialist
Date published: 2019-02-04

I know nothing about welding but interested in it for hobby, and setting up tagets for gun range. Would you recommend this welder for a newbie?

Asked by: Johnph31
This would be a great unit for someone just starting out. It will also grow with you as you tackle larger jobs or projects.
Answered by: Hobart Specialist
Date published: 2019-02-04

What amperage extension do I need with welder

Asked by: Gojo57
Depending on length you can use 12 gauge wire and for longer lengths over 50 feet use 10 gauge.
Answered by: Hobart Specialist
Date published: 2019-02-10

This is a simple beginners welder as easy as they come. I find I have to keep the gun close to the weld when using gas outside. Are the parts for this welder made in the U.S?

Asked by: Oldackonoak
Duty cycle is 15% at 190 amps.
Answered by: Hobart Specialist
Date published: 2019-08-02

What is the circuit breaker amp requirements of this unit.

Asked by: The lil leprauchan
It runs on 230V input power. Additional information can be found at the link below. Thank You and please let us know of any additional questions. https://www.hobartwelders.com/pdf/spec_sheets/Handler_190.pdf
Answered by: Hobart Specialist
Date published: 2018-09-23

what type of power cord is supplied? My electrical contractor needs to know what type of receptacle to install for the cord

Asked by: zoey513
The unit comes with a power cord with a molded NEMA 6-50 style plug.
Answered by: Hobart Specialist
Date published: 2019-02-10

Does this come with the liner it needs to run gas or does it have to be changed?

Asked by: Jaybo91gt
Yes… it can run flux core or solid. To run solid you will need a bottle of shielding gas. Everything is there.
Answered by: BOHE
Date published: 2020-03-17
