Torin Big Red Manual Geared Hand Winch, Zinc-Plated, Single Speed, 1,500 lb. Capacity
Item # 189341
Item # 189341
The Torin Big Red TRT1151 1,500 lb. Single-Speed Manual Geared Hand Winch is a great tool that offers quality lifting and towing aid up to 1,500 pounds. This winch is a must have utility to make short pulling distances easier and lifting large or heavy items. Designed for easy mounting on pickup trucks, ATV's, boats, trailers, lifting grain augers, and general use for multipurpose hauling or lifting/pulling of light loads such as volleyball nets. A manual-automatic locking brake system gives you security for load transport and stability. This winch also features a comfortable nylon handle for turning the Single-speed planetary gear for efficient, easy cranking for rotating fast or slow on heavy loads. Zinc-plated finish for superior corrosion resistance is applied to ensure a long-lasting finish and to help prevent rust, helping resistant bad weather and outdoor elements. Tested for reliability and safety.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Single-speed planetary gear for efficient, easy cranking for rotating fast or slow for those heavy loads
- Comfort grip nylon handle allows for a positive hold while cranking and reversible gearing changes
- Manual/Automatic brake
- Heat-treated high carbon steel gears to resist wear and last longer
- Free spooling clutch
- Fairlead roller guide
- Gear Ratio 4:1:1
- Handle Length: 9 in.
- Drum capacity: 26 ft. strap
- Drum capacity: 32 ft. of 3/16 in. rope
- Permitted strap width: 2 in.
- Maximum working load 1,500 lb.
- Easy-to-use one-way ratchet Base plates fit BIA Standard mounting bolt pattern for easy installation.
- Constructed of high-grade steel and built to exacting standards for quality and durability
- Zinc-plated finish for superior corrosion resistance is applied to ensure a long-lasting finish and to help prevent rust, helping resistant bad weather and outdoor elements
- Built-in ISO certified facilities and engineered using the same systems as Aerospace Technologies and the Automotive OEM sector
- Designed for use with cable, rope or strap (not included)
- 1 year limited warranty
- What's Included:
- (1) Hand Winch
- (1) Handle
- Choosing the Winch for you:
- Minimum winch pulling capacity = maximum weight of vehicle including motor, fuel, and gear divided by 2
- For example, ATV, fuel, gear = 800 pounds; 800 pounds/2 = 400 pounds; select the winch rated at least 500 lb.
| Brand | Torin |
|---|---|
| Country of Origin | Imported |
| Braking Mechanism | Manual |
| Capacity | 26 ft. strap drum capacity |
| Clutch Type | Manual Geared Hand Winch |
| Compatibility | 1,500 lb. |
| Engine Brand | N/A |
| Engine Displacement | 0 L |
| Engine Type | None |
| Fairlead Included | Yes |
| Fairlead Type | Roller |
| Features | Ideal use on pickup trucks, trailers and other mobile applications. |
| Gear Ratios | 4:1:1 |
| Handle Length | 9 in. |
| Horsepower | 0 H |
| Line Diameter | 2 in. |
| Line Length | 7.5 in. |
| Line Pull Capacity | 1,500 lb. |
| Line Speed | 1-speed |
| Mounting Bolt Length | 4 in. |
| Mounting Bolt Width | 2.5 in. |
| Number of Speeds | 1 |
| Power Type | Manual |
| Primary Material | Steel |
| Product Height | 6-1/2 in. |
| Product Length | 7-1/4 in. |
| Product Weight | 8.25 lb. |
| Product Width | 5-1/4 in. |
| Line Type | Rope |
| Voltage | 0V |
| Warranty | 1 Year Limited |
| Motor Type | None |
| Manufacturer Part Number | TRT1151 |
