VIAIR 2 gal. Heavy-Duty Onboard Air System, 150 PSI, 12V
Item # 138385299
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
The Viair Heavy Duty Onboard Air System is a pre-packaged compressed onboard air system that provides a faster 33% duty cycle 400C compressor, 2.5 gal. air tank, and all components needed to install a working system capable of inflating tires right out of the box. The heavy duty onboard air system has a maximum working pressure of 150 PSI. The onboard air system operates on 12 volts of power.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Max working pressure of onboard air system: 150 PSI / 2.62 cfm
- 12 volt heavy duty onboard air system
- Duty cycle of onboard air system: 33% @ 100 PSI
- Heavy duty onboard air system includes 400C VIAIR Compressor
- 2.5 gal. VIAIR Air Tank
- 35 ft. Nylon Coil Hose with Tire Chuck
- Dash Panel Gauge with ON/OFF Switch
- Pressure Switch with Relay (110 PSI on, 145 PSI off)
- Please Note: The included pressure Switch w/Relay is not a sealed unit and should be installed in an area protected from the elements to prevent damage and/or failure. Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8 is 10 ~ 11 ft. lb. Recommended torque for 1/4 and 3/8 is 12 ~ 15 ft. lb.
| Brand | VIAIR |
|---|---|
| Country of Origin | Imported |
| Airflow Volume | 2.62 CFM |
| Air Outlet Size | 1/4 in. NPT |
| Amperage | 28A |
| Compressor Horsepower | 0.25 HP |
| Compressor Maximum PSI | 150 PSI |
| Compressor Tank Capacity | 2.5 gal |
| Compressor Voltage | 12V |
| Cord Length | 1 ft. |
| Drain System | Manual |
| Drive Type | DC |
| Features | Air tank, fittings and Hose Included |
| Number Of Power Speeds | Single |
| Number Of Wheels | 0 |
| Power Type | 12 Volt |
| Primary Color | No Color |
| Primary Material | Steel |
| Product Height | 10.0 in. |
| Product Length | 27.0 in. |
| Product Weight | 30.0 lb. |
| Product Width | 15.0 in. |
| Pump Material | Aluminum |
| Tank Fill Time | 2 min. 20 sec. |
| Tank Style | Horizontal |
| Warranty | Https://www.viaircorp.com/warranty |
| Manufacturer Part Number | 10005 |
