DeWALT 60 Gal. 155 PSI Stationary Electric Air Compressor, DXCM601

SKU: 131332699
Enter Zip Code for price
Product price

Save Up To
See price at checkout
Product Rating is 4.7
4.7
 (516)

Quantity

TSC of nazareth #1302
4037 jandy blvd
nazareth, PA 18064
(610) 746-9562
TSC of nazareth #1302
4037 jandy blvd
nazareth, PA 18064
(610) 746-9562
Check Availability at Other Stores
Standard Delivery Not Available to
This item will ship within 0 days.
Change Delivery Location
Protect your purchase with Power Plus
Protect Your Purchase Click here for more details...

We'll fix it, replace it, or reimburse you for it.

Item Information

The DEWALT Stationary Belt Drive Air Compressor is proudly made in the USA and features a 3.7 HP heavy duty induction motor with an oil lubricated, belt driven, cast iron, in-line twin cylinder pump that delivers 155 Max PSI, 13.4 SCFM at 40 PSI and 11.5 SCFM at 90 PSI. The motor is wired for 240 volts and must be wired by a certified electrician (consult the National Electrical Code and local codes before wiring). This compressor is perfect for the home/farm shop and will operate a wide variety of pneumatic tools for automotive and agricultural applications as well as your DIY projects around the home (All pneumatic tools operate at various SCFM. Consult the operator's manual for your tool for the required SCFM for the tool to operate.). The compressor is shipped with synthetic oil for optimum performance and long life.

  • Solid cast iron, oil lubricated, twin cylinder pump with aluminum head to dissipate heat
  • 155 PSI max pressure allows the user optimum tool performance.
  • Heavy duty 3.7HP induction motor for long life
  • ASME (American Society of Mechanical Engineers) code tank meets all safety standards
  • 12inch balanced fly wheel with durable wire belt guard
DEWALT Industrial Tools are warranted from date of purchase. 2 Year - Limited warranty on oil-lubricated air compressor pumps. 1 Year - Limited warranty on all other air compressor components. This warranty is not transferable to subsequent owners.

Specification Description
Drain System: Multi-turn drain valve
CountryofOrigin: Made in USA
Color: Yellow
Maximum RPM: 2,000 rpm
Tank Capacity: 60 gal.
Pump Oil Capacity: 16 oz.
Tank Orientation: Vertical
Engine Brand: N/A
Product Weight: 208 lb.
Airflow Volume: 13.4 @ 40 PSI, 11.5 @ 90
Motor Phase: Single
Drive Type: Induction motor with belt drive pump
Stage Type: Single-Stage
Running Horsepower: 3.7 hp
Maximum Operating Pressure: 155
Power Type: Electric
Application/Use: Air Brushing,Blow Cleaning,Bolting/Wrenching,Brad Nailing/Stapling,Cutting,Drilling,Finish Nailing,Framing Nailing,Grinding,HVLP Painting,Hobby Nailing,Hobby Painting,Inflation,Roof Nailing,Sanding,Spraying,Surface Prep
Air Outlet Size: N/A
Start Type: On/Off Switch
Product Width: 24
Pump Material: Cast Iron
Tank Fill Time: 6.2
Portable or Stationary: Stationary
Voltage: 230 V
Product Length: 24
Pump Life: 1,000
Fuel Tank Capacity: N/A
Special Feature(s): N/A
Product Height: 66
Brand: DeWALT
Decibel Rating: 80 dBA
Part Number: DXCM601
Lubrication Type: Oil
Manufacturer Part Number DXCM601
DeWALT 60 Gal. 155 PSI Stationary Electric Air Compressor, DXCM601 is rated 4.7 out of 5 by 516.
Rated 5 out of 5 by from Quite compressor good price. I bought this air compressor last month on sale. The air compressor works great and is perfect for any homeowner or little shop that needs air. Better quality than my old craftsman's from years ago.
Date published: 2019-10-05
Rated 4 out of 5 by from Worth the money Pretty much what I expected. Good deal for the money. Just wish the drain plug was alittle easier to work with. Hard to turn and hard to get to. Don't know if it is open or not the way it is made.
Date published: 2019-10-04
Rated 1 out of 5 by from Not even a Dewalt! I just got this 60 gal compressor. Dead out of the box will not start. I contacted Dewalt by the chat feature only to be told to call someone else. Sanborn industeries. I am going to contact TSC to see if I can retrun this. I have found other reviews now that state this is an issue that they are shipped with bad motors and take weeks to fix. Not very happy here.
Date published: 2019-09-30
Rated 5 out of 5 by from Best 60 gallon compressor for the price! Love this compressor. Working as advertised, shuts down at 155psi and I have no issues with running air tools and such. It is a bit noisy at 85db but for the price it’s hard to beat. Piece of cake wiring it up after watching how-to videos online, even wired up a 240 outlet as a complete novice.
Date published: 2019-09-25
  • y_2019, m_10, d_16, h_16
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_133, tr_383
  • loc_en_US, sid_131332699, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 5ms
  • REVIEWS, PRODUCT

So, it does not have an air regulator with this unit, what part number is recommended for this unit?

Asked by: John Doe smith
There is no air regulator included with this unit as they are typically plumbed for air distribution tailored to each persons needs. There is a 1 inch threaded port in the side of the tank where you can start your plumbing for air distribution. You will need to decide on the desired regulator that you want to use and then outfit your plumbing and air distribution system to your specific needs.
Answered by: Dewalt Team
Date published: 2019-02-20

What comes with the unit?

Asked by: Peggal7
The DEWALT 60 Gallon air compressor is only an air compressor. No other air tools or accessories are included with this. Also, please note: The motor is wired for 240 volts and must be wired by a certified electrician (consult the National Electrical Code and local codes before wiring).
Answered by: Dewalt Team
Date published: 2019-04-08

Does this compressor require a break in procedure? If so, does the compressor oil need to be changed after break in?

Asked by: Troy7762
Yes there is a break in procedure. it is on pages 16 - 18 of the manual. Once the compressor is prepared, you must open the drain valve and let the unit run steady for 30 minutes. The factory oil must be changed after the first 20 hours of use and then every 100 hours after that.
Answered by: Dewalt Team
Date published: 2019-02-20

I do some auto body repair at my home.How well will this keep up with DA's' angle die grinders and HVLP paint guns?

Asked by: Anonymous
The DXCM601 provides 13.4 SCFM at 40 PSI and 11.5 SCFM at 90 PSI with a 155 max PSI in the tank. Please check the air delivery requirements for the angle die grinders and HVLP paint guns to ensure that the compressor provides enough to operate it.
Answered by: Dewalt Team
Date published: 2019-09-12

"Experts" - Be more careful with answers! In THREE places on this page, you have given the tank discharge port size as 1-inch, 3/4-inch and 3/8-inch. Certainly, there could be a 1-inch fem. fitting with a plugged 3/4 bushing. BUT, WHICH ONE IS CORRECT?

Asked by: FestusKnows
There is not a quick connect fitting installed on the DXCM601, DEWALT 60 gallon air compressor. We can confirm that this compressor has a 1 inch threaded port on the side of the tank that you can plumb into for your specific shop needs.
Answered by: Dewalt Team
Date published: 2018-11-15

Looking at one of the pneumatic auto drains. They all need a "signal" from the unloader circurt. Where is the best place to tap this signal? For example: Tsunami Moisture Minder Pneumatic Drain

Asked by: penright
The auto drain you are referring to is not our product. Our product uses 120V to operate not pressure from the tank. Please refer to the owner’s manual of the product you are looking to install.
Answered by: Dewalt Team
Date published: 2019-08-30

What is the duty cycle?

Asked by: Ironhorse1
The DEWALT DXCM601 has been developed and tested with a 50% duty cycle.
Answered by: Dewalt Team
Date published: 2018-10-11

Why is the pump only rated for 1,000 hours?

Asked by: Buck61
1000 hours is the average life tested for this compressor. This amount usually exceeds the time most users will use the compressor.
Answered by: Dewalt Team
Date published: 2019-05-13
