VIAIR 480C Chrome Single Air Compressor Kit, 200 PSI, 12V
Item # 138382999
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Viair - 480C 200 PSI Chrome Compressor Kit with 3/8 in. Port includes a 200 PSI-rated compressor. The chrome compressor kit features horizontal cooling fins and a trapezoidal head design. A standard 3/8 in. stainless steel braided leader hose with 3/8 in. NPT inline check valve and insulated wiring are included in the compressor kit. The maximum working pressure of the compressor kit is 200 PSI.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- 200 PSI / 1.86 CFM rating
- 12-volt chrome compressor kit
- Duty Cycle: 50% @ 200 PSI
- Max. Working Pressure: 200 PSI
- Max. Air Tank Size: 5.0 gal.
- Max. 12V Amp Draw: 23 Amps
- Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque is 12 to 15 ft. lb.
- Thermal Overload Protector
- Check Valve
- Vibration Isolators
- Mounting hardware included in chrome compressor kit for easy installation
- Stainless Steel Braided Leader Hose
- Air Line for Remote Mount Air Filter
- Remote Mount Air Filter Assembly
- Two Replacement Air Filter Elements
- Installation Instructions
- Permanent Magnetic Motor
- Ingress Protection Rating: IP67
- Dimensions of compressor kit: 10.87 in. L x 4.2 in. W x 6.75 in. H
- Net Weight: 11.05 lb.
- Compressor kit has horizontal cooling fins and a trapezoidal head design
