VIAIR Ultra-Light Duty Onboard Air System, 105 PSI
Item # 138384999
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Viair Ultra-Light Duty Onboard Air System can be used to pressurize the included 1.0 gal. air tank for air horn use, air lockers, and a host of other light duty pneumatic needs. While not intended for tire inflation, this onboard air system provides a reliable air source in a smaller volume, and a cost effective package. The Omega Bracket with mounting hardware allows for easy installation of the ultra-light duty onboard air system. The maximum working pressure of the onboard air system is 105 PSI.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Max working pressure of onboard air system: 105 psi / 1.53 cfm
- 12 volt ultra-light duty onboard air system
- Duty Cycle: 10% @ 100 PSI
- 98C VIAIR Air Compressor
- 1.0 gal. VIAIR Air Tank
- Omega Bracket with mounting hardware
- Pressure switch (85 PSI on, 105 PSI off)
- 40 amp relay
- 145 PSI Safety Valve
- 1/4 in. Compression Fitting
- 1/4 in. Plug (M)
- 20 ft. 16-gauge wire with inline fuse holder
- Ultra-light duty onboard air system has a permanent magnetic motor
- Max amp draw of onboard air system: 12 amps
- Ingress protection rating: IP54
- Please Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8 is 10 ~ 11 ft. lb. Recommended torque for 1/4 and 3/8 is 12 ~ 15 ft. lb.
