VIAIR 200 PSI Ultra Duty Onboard Air System,12V, 20001
Item # 138385699
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Viair 200 PSI Ultra Duty Onboard Air System is a pre-packaged compressed onboard air system that provides an industry-leading, 200 PSI rated, 100% duty cycle 480C compressor, 2.5 gal. air tank, and all components needed to install a working system capable of inflating tires of virtually any size. The ultra duty onboard air system includes a tire inflation gun with a 200 PSI gauge. The dash panel gauge in the onboard air system has an ON/OFF switch for easy operation.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Ultra duty onboard air system has a 200 PSI/1.86 cfm rating
- 480C Chrome VIAIR Air Compressor
- 2.5 gal. 200 PSI VIAIR Air Tank
- Duty cycle of onboard air system: 100% @ 100 PSI, 50% @ 200PSI
- Tire inflation gun with 200 PSI gauge included in the onboard air system
- Dash panel gauge in the ultra duty onboard air system with ON/OFF switch
- Please Note: Pressure Switch w/Relay is not a sealed unit and should be installed in an area protected from the elements to prevent damage and/or failure. Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8 is 10 ~ 11 ft. lb. Recommended torque for 1/4 and 3/8 is 12 ~ 15 ft. lb.
