Red Lion 4 in. Submersible Deep Well Pump 12 GPM, 1/2 HP, 2 Wire, 115V
Red Lion 4 in. Submersible Deep Well Pump 12 GPM, 1/2 HP, 2 Wire, 115V
Item # 2494617
$529.99
Red Lion 4 in. Submersible Deep Well Pump 12 GPM, 1/2 HP, 2 Wire, 115V
Item # 2494617
$529.99
This Red Lion 4" Submersible Deep Well Pump is ideal for the supply of fresh water to rural homes, farms, and cabins that have 4" and greater diameter drilled wells to depths of 212'. Meets NSF/ANSI standards.
- Powered by an industry standard 1/2 HP, 115 Volt - 2 wire motor
- Thermoplastic discharge and motor bracket
- Stainless Steel pump shell
- Built-in Check Valve and Suction Screen
- 12 Gallons Per Minute
- 1-1/4" FNPT Discharge
- Shut-off - 212'
- 3 Year Manufacturer's Warranty
- cCSAus Listed
- NSF/ANSI 61 Certified
| Brand | Red Lion |
|---|---|
| Country of Origin | Imported |
| Amperage | 12 Amps |
| Body Material | Stainless steel |
| Compatible Pipe Material | Polypropylene, Galvanized steel, Stainless Steel, PVC |
| Compatible Well Diameter | 4 in. |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1.25 in. |
| Discharge Rate at 0 ft. | 12 gpm |
| Discharge Rate at 25 ft. | 12 gpm |
| Discharge Rate at 50 ft. | 12 gpm |
| Features | Built in Check Valve and Suction Screen; Thermoplastic Discharge and Motor Brackey |
| Horsepower | 0.5 HP |
| Inlet Connection | None |
| Inlet Diameter | 4 in. |
| Maximum Flow Rate | 12 GPM |
| Maximum Head Lift | 212 ft. |
| Maximum Operating Depth | 212 ft. |
| Maximum Operating Temperature | 120 deg. F |
| Minimum Operating Temperature | 40 deg. F |
| Power Type | Electric |
| Product Height | 34.5 in. |
| Product Length | 4.375 in. |
| Product Weight | 25 lb. |
| Product Width | 4.6 in. |
| Motor Type | Electric |
| Voltage | 115V |
| Warranty | 3 year |
| Manufacturer Part Number | 14942401 |
