Transfer petroleum fluids easily with a Traveller RP-5 Fuel Hand Pump. This fuel hand pump is made for use with most fuels and oils including diesel, kerosene and mineral spirits. Crafted from durable cast-iron this rotary action fuel pump is designed to last.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Size of the barrel adapter: 2 in.
- Color: silver/black
- Durable cast-iron rotary action barrel pump
- Pumping capacity: 22L/6 gal. per 100 rotaries
- Fuel pump includes adjustable Spout, 39 in. 3-piece suction pipe with couplers, built-in strainer
| Brand | Traveller |
|---|---|
| Country of Origin | Imported |
| Body Materials | Cast iron |
| Compatible Fluids | Diesel, Mineral Spirits |
| Discharge Connection | None |
| Discharge Diameter | 2 in. |
| Duty Cycle | 90 Pct. |
| Features | Size of the barrel adapter:2 in. Color: Silver/black. Durable cast-iron rotary action barrel pump. Pumping capacity:22L/6 gal. per 100 rotaries. Fuel pump includes adjustable Spout,39 inch. 3 piece suction pipe with couplers, built-in strainer. |
| Hose Diameter | 1.22 in. |
| Inlet Connection | No Thread |
| Inlet Diameter | 2 in. |
| Intended Use Grade | Standard |
| Maximum Head Lift | 6.56 ft. |
| Maximum Operating Pressure | 284 PSI |
| Maximum Operating Temperature | 40 C |
| Minimum Operating Pressure | 7.5PSI |
| Minimum Operating Temperature | -10 C |
| Power Type | Manual, None |
| Product Height | 8.27 in. |
| Product Length | 49.80 in. |
| Product Weight | 9.59 lb. |
| Product Width | 10.16 in. |
| Warranty | 90 Day Limited |
| Manufacturer Part Number | 17230210 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 15 Questions
Newest questions
Q: do they have a rebuild kit for this product
5 days ago1 Answer
- A: No dedicated official rebuild or overhaul kit is manufactured or sold for the economy Traveller Manual RP-5 Fuel Hand Pump. Because it is priced and built as a light-duty, budget rotary barrel pump, individual replacement internal seals, vanes, or repair kits are not offered by the manufacturer or Tractor Supply Co3 days agoHelpful?
Q: What size are the threads on the goodneck. And do you have the fittings to replace the goosneck with an adapter To connect to a 3/4 garden hose
9 months ago1 Answer
- A: The thread size is 3/4 inch BSP. No we do not have any parts.9 months agoHelpful?
Q: Can you pump methanol with this pump?
3 years ago1 Answer
- A: Do not use the pump with the following fluids:Gasoline, Water, Sulfuric acid, Naphtha, Methanol, Methyl Ethyl Ketone(MEK), Acetone, Ammonia, Benzene, Bleach, Chlorine.3 years agoHelpful?
Q: Will gasoline damage this pump? Thanks - Bill
3 years ago1 Answer
- A: Yes, our hand pump doesn’t have the certificate or protection so it is unable to use with gasoline.3 years agoHelpful?
Q: What is the size and thread pith of the pick-up tube?
4 years ago1 Answer
- A: Contact your local TSC store,4 years agoHelpful?
Q: Will this pump work in both directions discharge and suck
4 years ago1 Answer
- A: Yes, this pump is compatible with most fuels/oils including diesel, kerosene, light oils and mineral spirits4 years agoHelpful?
Q: I have bought two hoses for the pump discharge and nothing will fit. What adapter or hose can I buy to fit this pump?
4 years ago1 Answer
- A: The thread size is 3/4 inch BSP.4 years agoHelpful?
Q: Is this product suitable for pumping gasoline?
4 years ago1 Answer
- A: No, Any pump that can be used with Gasoline requires to meet explosion proof requirement and certificate, but our hand pump doesn’t have the certificate or protection so it is unable to use with gasoline.4 years agoHelpful?
Q: what is the thread size for the outlet pipe at top of pump
4 years ago1 Answer
- A: The thread size is 3/4 inch BSP.4 years agoHelpful?
Q: Can water separaters and fuel filters be used on this.
5 years ago1 Answer
- A: Yes, water separators and fuel filters can be used on this products, the inlet’s outer diameter is 32mm(1.26inch) with thread on outside, thread pitch-1.5mm. This product has come with a fuel filter with it attached to the inlet.5 years agoHelpful?
1 - 10 of 15 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 15 Questions
Newest questions
Q: do they have a rebuild kit for this product
5 days ago1 Answer
- A: No dedicated official rebuild or overhaul kit is manufactured or sold for the economy Traveller Manual RP-5 Fuel Hand Pump. Because it is priced and built as a light-duty, budget rotary barrel pump, individual replacement internal seals, vanes, or repair kits are not offered by the manufacturer or Tractor Supply Co3 days agoHelpful?
Q: What size are the threads on the goodneck. And do you have the fittings to replace the goosneck with an adapter To connect to a 3/4 garden hose
9 months ago1 Answer
- A: The thread size is 3/4 inch BSP. No we do not have any parts.9 months agoHelpful?
Q: Can you pump methanol with this pump?
3 years ago1 Answer
- A: Do not use the pump with the following fluids:Gasoline, Water, Sulfuric acid, Naphtha, Methanol, Methyl Ethyl Ketone(MEK), Acetone, Ammonia, Benzene, Bleach, Chlorine.3 years agoHelpful?
Q: Will gasoline damage this pump? Thanks - Bill
3 years ago1 Answer
- A: Yes, our hand pump doesn’t have the certificate or protection so it is unable to use with gasoline.3 years agoHelpful?
Q: What is the size and thread pith of the pick-up tube?
4 years ago1 Answer
- A: Contact your local TSC store,4 years agoHelpful?
Q: Will this pump work in both directions discharge and suck
4 years ago1 Answer
- A: Yes, this pump is compatible with most fuels/oils including diesel, kerosene, light oils and mineral spirits4 years agoHelpful?
Q: I have bought two hoses for the pump discharge and nothing will fit. What adapter or hose can I buy to fit this pump?
4 years ago1 Answer
- A: The thread size is 3/4 inch BSP.4 years agoHelpful?
Q: Is this product suitable for pumping gasoline?
4 years ago1 Answer
- A: No, Any pump that can be used with Gasoline requires to meet explosion proof requirement and certificate, but our hand pump doesn’t have the certificate or protection so it is unable to use with gasoline.4 years agoHelpful?
Q: what is the thread size for the outlet pipe at top of pump
4 years ago1 Answer
- A: The thread size is 3/4 inch BSP.4 years agoHelpful?
Q: Can water separaters and fuel filters be used on this.
5 years ago1 Answer
- A: Yes, water separators and fuel filters can be used on this products, the inlet’s outer diameter is 32mm(1.26inch) with thread on outside, thread pitch-1.5mm. This product has come with a fuel filter with it attached to the inlet.5 years agoHelpful?
1 - 10 of 15 Questions
Similar Items
-
-
-
-
-
-
-
-
-
-
-
-
Top Rated
Items You May Like
-
-
-
Top Rated
-
-
-
Top Rated
-
-
-
-
-
-
Customers Also Bought
-
-
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
-
-
-
Top Rated
-
Top Rated
Reviews
Most Helpful Favorable Review
5 out of 5 stars.
Works just fine
6 years ago
Works great! No issues. Must use a generous amount of teflon tape at each joint to create a leak free seal or else it won't create suction, therefore won't pump.
6 people found this helpful
Show Reviews:
Most Helpful Critical Review
2 out of 5 stars.
Better than no pump
13 years ago
When it's working, it moves the stated volume of fuel. The problem I have run into is that it leaks most of the time. Without taking it apart, there is no easy way to fix it. It started leaking after the first year. It's stored in the barn, so it was not subjected to the elements. I am sure others are fine, maybe I just got a lemon.
22 people found this helpful
Show Reviews:
1 to 4 of 28 Reviews .
1 – 4 of 28 Reviews
Most Recent
Review 1
1 out of 5 stars.
Bad
a year ago
The one I bought leaked at the first use!
SweepstakesYes
No, I do not recommend this product.
Review 1
4 out of 5 stars.
Pump
2 years ago
This is what I needed.
Review 1
1 out of 5 stars.
Not suitable for water
2 years ago
Box was missing outflow spout and instructions. Looked on the website pdf instructions and they expressly state not to use for water. No problem getting a refund , but could have saved time and gas if the website or the box said not to use with water.
SweepstakesYes
Review 1
1 out of 5 stars.
wouldn't purchase again!
3 years ago
This pump didn't last the summer for me. The inside mechanism rusted and the handle would not turn, no matter how much I tried to turn it. I even beat it with a hammer and still no progress to unstick it. There was no way to lubricate the inside components to keep it lubricated. It went into the trash. Very disappointed, especially for the price.
