Chief 2 in. Bore x 10 in. Stroke WTG Welded Tang Cylinder, 1.125 in. Rod Diameter
Chief 2 in. Bore x 10 in. Stroke WTG Welded Tang Cylinder, 1.125 in. Rod Diameter
Item # 1307830
$261.69
Chief 2 in. Bore x 10 in. Stroke WTG Welded Tang Cylinder, 1.125 in. Rod Diameter
Item # 1307830
$261.69
The Chief 2 in. Bore x 10 in. Stroke WTG Welded Tang Cylinder is an incredibly durable cylinder. It is sometimes referred to as a lug end cylinder, due to a 1-piece lug mount welded to both the rod and base ends of the hydraulic cylinder. This welded hydraulic cylinder can utilize a spherical ball or steel bushing insert to improve wear life and is most commonly used in heavy-duty construction equipment.Note: This product may require up to 2 additional days for order processing prior to shipping
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Intended use: double acting applications
- Piston: ductile iron, thread-on with wear ring
- Gland: keyed joint, ductile iron
- Tube: precision-honed steel
- Rod: induction-hardened, hard chrome-plated
- Rod end mount: cast 1045 steel, welded-on
- Spherical bearing with retaining ring
- 1/8 NPT grease zerk
- Base end mount: cast 1045 steel, hardened spring steel bushing, 1/8 NPT grease zerk
- Tube seal: Buna O-ring with polytemp hytrel backup
- Rod seal: deep polypak with B-lip design
- Rod wiper: urethane, snap-in
- Piston seals: Hallite 755 for prolonged wear resistance, with wear ring
- All seals are manufactured to U.S. specifications
- Ports: SAE O-ring
- Measures 14.25 in. retracted and 18.25 in. extended
- 3,600 PSI pressure rating
- Forged steel tang mountings with integral heavy-duty bushings
- 360 degree rotating gland for a versatile welded hydraulic cylinder
- Functionally tested and pressurized to 5,000 PSI to ensure performance reliability
- 3-year limited warranty on the hydraulic cylinder
- Measures 14.25 in. retracted and 18.25 in. extended
- Pin diameter of 1 in. and rod diameter of 1.125 in.
| Brand | Chief |
|---|---|
| Country of Origin | Made in USA |
| Bore Diameter | 2 in. |
| Brand Compatibility | Universal |
| Compatibility | Varies |
| Extended Length | 30 in. |
| Hydraulic Cylinder Type | Welded |
| Maximum Operating Pressure | 3,600 PSI |
| Maximum Weight Capacity | 11,300 lb. |
| Model Compatibility | Universal |
| Package Quantity | 1 |
| Pin Diameter | 1 in. |
| Primary Material | Steel |
| Product Height | 1.2 in. |
| Product Length | 10 in. |
| Product Weight | 17 lb. |
| Product Width | 1.3 in. |
| Retracted Length | 20 in. |
| Rod Diameter | 1-1/8 in. |
| Single/Double Acting | Double acting |
| Stroke Distance | 10 in. |
| Warranty | 3 Year |
| Manufacturer Part Number | 400614 |
