Red Lion 6.5 HP Gas-Powered Cast Iron Engine Driven Fertilizer Pump, 170 GPM
$849.99
Red Lion 6.5 HP Gas-Powered Cast Iron Engine Driven Fertilizer Pump, 170 GPM
Red Lion 6.5 HP Gas-Powered Cast Iron Engine Driven Fertilizer Pump, 170 GPM
Item # 2196019
$849.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
Red Lion 6.5 HP Gas-Powered Cast Iron Engine Driven Fertilizer Pump, 170 GPM
Item # 2196019
$849.99
or
or
$36/mo.† suggested payments with 24 Months Financing or earn $42 in Rewards+ on this purchase.
Valid 5/15/2026 - 7/5/2026
Valid 5/15/2026 - 7/5/2026
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Red Lion 5RLGF-8KRF Cast-Iron Multipurpose Fertilizer Pump is ideal for liquid transfer, including most agricultural chemicals and general dewatering where rugged portability is important. The utility transfer pump is designed with a strong, stainless-steel shaft sleeve and an EDPM elastomer seal. This engine driven cast iron pump includes a steel roll cage for easy portability to and from job sites.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Cast-iron water and Ag chemical utility transfer pump
- Heavy-duty cast-iron pump casing
- Durable cast-iron semi-open type impeller
- Fertilizer pump offers a stainless-steel shaft sleeve and EDPM elastomer seal
- Self priming down to 25 ft.
- Handles most liquid agricultural chemicals
- Handles up to 5/8 in. solid debris
- 2 ft. NPT suction and discharge for convenient hookup
- Powered by a Kohler 3000 series engine
- Includes heavy-duty roll frame
| Brand | Red Lion |
|---|---|
| Country of Origin | Imported |
| Amperage | 0 Amp |
| Body Material | Cast iron |
| Compatible Pipe Material | None |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 2 in. |
| Discharge Rate at 0 ft. | 170 GPM |
| Discharge Rate at 10 ft. | 170 GPM |
| Engine Brand | Kohler |
| Engine Displacement | 196cc |
| Features | HD cast iron pump casing; durable cast iron semi-open type impeller; stainless steel shaft sleeve; EDPM elastomer seal; handles up to 5/8 in. solid debris, handles most liquid agricultural chemicals; easy to prime to 25 ft. |
| Fuel Capacity | 0.95 US gal. |
| Horsepower | 6.5 HP |
| Hose Diameter | 2 in. |
| Impeller Material | Cast Iron |
| Inlet Connection | Threaded Female |
| Inlet Diameter | 2 in. |
| Maximum Flow Rate | 170 GPM |
| Maximum Head Lift | 95 ft. |
| Maximum Operating Pressure | 41 PSI |
| Maximum Operating Temperature | 140 deg. F |
| Maximum Solids Diameter | 5/8 in. |
| Maximum Suction Lift | 25 ft. |
| Minimum Operating Pressure | 40 deg. F |
| Minimum Operating Temperature | 40 deg. F |
| Oil Capacity | 1 us quart |
| Power Cord Length | 0 ft. |
| Power Type | Gas |
| Product Height | 18 in. |
| Product Length | 21 in. |
| Product Weight | 74 lb. |
| Product Width | 17.5 in. |
| Motor Type | Kohler, Air Cooled, 4 Stroke; OHV (196cc) |
| Utility Pump Type | Transfer utility |
| Voltage | 0 V |
| Warranty | 2 Year |
| Manufacturer Part Number | 617032 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 9 of 9 Questions
Newest questions
Q: Can you pump flammable chemicals with this pump?
a year ago1 Answer
- A: Hi, No, we do not recommend pumping flammable chemicals in this fertilizer pump.a year agoHelpful?
Q: Can you use this pump to pump gas out of tanks that is contaminated?
2 years ago1 Answer
- A: Hi, Thanks for reaching out. Here is the information we received back from our vendor- "No, none of our pumps are designed for moving fuel."2 years agoHelpful?
Q: Can it be used as a hydrostatic test pump? Or is it basically centrifugal?
3 years ago1 Answer
- A: Hi! No. Our gas driven pumps are designed for the application that we market them under (transfer pumps), and none of them have been tested for, or certified for use as hydrostatic test pumps.3 years agoHelpful?
Q: I want to use this pump to transfer light sewage from porta potty into a dump barrel. Will it work for this?
4 years ago1 Answer
- A: For additional product support, please contact 888-885-9254.4 years agoHelpful?
Q: Can I pump asphalt sealer with a 3 lb per gallon sand load mixed in for about 6 hours a day in summer weather?
6 years ago1 Answer
- A: Unfortunately, you would need to contact Red Lion for more information.5 years agoHelpful?
Q: I have a weird that is around 32 ft deep. Would this draw water up that high? I was planning on watering a garden with it. The garden sits downhill approx 60 ft away.
6 years ago1 Answer
- A: Thanks for choosing Red Lion. Is the surface of the water at 32 feet? I ask because the water would need to be less than 20 feet horizontally from the pump intake. The distance from the pump to the garden is fine as it is a downhill run. Please call me at 888-885-9254 if you want to discuss this application further.6 years agoHelpful?
Q: I want to use this pump for flooding in my basement. we have had up to 3 feet of water down there . We also get some debris as well. Would this pump work for me?
7 years ago1 Answer
- A: Thanks for choosing Red Lion Engine Drive pumps. This Cast Iron Engine Powered pump would work great in this application.7 years agoHelpful?
Q: What is the psi (pressure) on this pump on the outlet? Looking to use it for grass fires. Thanks
8 years ago1 Answer
- A: Thank you for your question regarding Red Lion Engine powered transfer pumps. These pumps are designed as water transfer pumps. They should not be used in firefighting applications. The max flow is 150GPM and 39 PSI. Please contact our tech support team at 888-956-0000 if you have additional questions.8 years agoHelpful?
Q: What height will this pump lift to and how far. Looking at drawing lake water 1500-2000 feet uphill an additional 20 foot elevation?
9 years ago1 Answer
- A: Thank you for your question regarding the Red Lion Engine Drive pump. Unfortunately the simple answer to your question is no. This pump will not draw water that distance due to friction loss in the pipe. Anytime your suction pipe is longer than 100’ you should compare the effort of increased pipe size to moving the pump closer to the water source. Having a suction pipe that exceeds 300’ just isn’t practical. The benefit of having a gas engine pump is you are bringing your power source with you making it easier to move the pump closer to water and let the pump push the water up 20’ through 2000’ of pipe. These pumps have a much easier time pushing water rather than pulling. I hope this has answered your question. Please call our product support team at 888-956-0000 if you have any additional questions or need help with your set up.9 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 9 of 9 Questions
Newest questions
Q: Can you pump flammable chemicals with this pump?
a year ago1 Answer
- A: Hi, No, we do not recommend pumping flammable chemicals in this fertilizer pump.a year agoHelpful?
Q: Can you use this pump to pump gas out of tanks that is contaminated?
2 years ago1 Answer
- A: Hi, Thanks for reaching out. Here is the information we received back from our vendor- "No, none of our pumps are designed for moving fuel."2 years agoHelpful?
Q: Can it be used as a hydrostatic test pump? Or is it basically centrifugal?
3 years ago1 Answer
- A: Hi! No. Our gas driven pumps are designed for the application that we market them under (transfer pumps), and none of them have been tested for, or certified for use as hydrostatic test pumps.3 years agoHelpful?
Q: I want to use this pump to transfer light sewage from porta potty into a dump barrel. Will it work for this?
4 years ago1 Answer
- A: For additional product support, please contact 888-885-9254.4 years agoHelpful?
Q: Can I pump asphalt sealer with a 3 lb per gallon sand load mixed in for about 6 hours a day in summer weather?
6 years ago1 Answer
- A: Unfortunately, you would need to contact Red Lion for more information.5 years agoHelpful?
Q: I have a weird that is around 32 ft deep. Would this draw water up that high? I was planning on watering a garden with it. The garden sits downhill approx 60 ft away.
6 years ago1 Answer
- A: Thanks for choosing Red Lion. Is the surface of the water at 32 feet? I ask because the water would need to be less than 20 feet horizontally from the pump intake. The distance from the pump to the garden is fine as it is a downhill run. Please call me at 888-885-9254 if you want to discuss this application further.6 years agoHelpful?
Q: I want to use this pump for flooding in my basement. we have had up to 3 feet of water down there . We also get some debris as well. Would this pump work for me?
7 years ago1 Answer
- A: Thanks for choosing Red Lion Engine Drive pumps. This Cast Iron Engine Powered pump would work great in this application.7 years agoHelpful?
Q: What is the psi (pressure) on this pump on the outlet? Looking to use it for grass fires. Thanks
8 years ago1 Answer
- A: Thank you for your question regarding Red Lion Engine powered transfer pumps. These pumps are designed as water transfer pumps. They should not be used in firefighting applications. The max flow is 150GPM and 39 PSI. Please contact our tech support team at 888-956-0000 if you have additional questions.8 years agoHelpful?
Q: What height will this pump lift to and how far. Looking at drawing lake water 1500-2000 feet uphill an additional 20 foot elevation?
9 years ago1 Answer
- A: Thank you for your question regarding the Red Lion Engine Drive pump. Unfortunately the simple answer to your question is no. This pump will not draw water that distance due to friction loss in the pipe. Anytime your suction pipe is longer than 100’ you should compare the effort of increased pipe size to moving the pump closer to the water source. Having a suction pipe that exceeds 300’ just isn’t practical. The benefit of having a gas engine pump is you are bringing your power source with you making it easier to move the pump closer to water and let the pump push the water up 20’ through 2000’ of pipe. These pumps have a much easier time pushing water rather than pulling. I hope this has answered your question. Please call our product support team at 888-956-0000 if you have any additional questions or need help with your set up.9 years agoHelpful?
Similar Items
Items You May Like
-
-
-
-
-
-
-
-
-
-
-
-
Top Rated
Customers Also Bought
-
Top Rated
-
-
Top Rated
-
-
-
-
-
-
-
-
-
Reviews
- small
- price
- purchase
- satisfaction
- material
- metal
- packaging
- durability
1 to 4 of 61 Reviews .
1 – 4 of 61 Reviews
Most Recent
MI
Reviews 5
2 out of 5 stars.
Pump needs proper fittings
a year ago
When buying this product be sure to buy an additional hose kit it has no fittings to run pump straight from box spent over 1000$ to get pump to do what was need. Over all pump works fine. Just be prepared to spend the money.
SweepstakesYes
No, I do not recommend this product.
Anonymous
Olive Branch Ms.
Reviews 5
5 out of 5 stars.
Standed-up Standed-in of a Pump
2 years ago
We purchased this to temporarily replace a drilling mix water pump for directional drilling so we could get adequate water supply to our drill for underground drilling/boring . It worked so well that we bolted it to our flatbed 1 ton truck that transports a 500 gallon tank and the ,for now original pump /motor that needs new seals installed . It has. certainly kept the water and chemical mix flowing allowing us to continue achieving our production . It’s a very good little workhorse of a pump.
SweepstakesYes
Yes, I recommend this product.
Anonymous
Lousiana
Review 1
5 out of 5 stars.
Good pump
2 years ago
Works great pumps fast
SweepstakesYes
Martinsville, VA
Reviews 2
5 out of 5 stars.
Excellent value and great reliability!
2 years ago
Ive purchased 5 of these units and they all work great. Ive changed the oil and spark plugs regularly and they are all still in operation. Very reliable and affordable
SweepstakesYes
Yes, I recommend this product.
