Green Leaf Inc. 2 in. Polypropylene Bulkhead Fitting, NSF61 and NSF372 Certified
Green Leaf Inc. 2 in. Polypropylene Bulkhead Fitting, NSF61 and NSF372 Certified
Item # 108269799
Neighbor’s Club Members earn points with purchases.
Green Leaf Inc. 2 in. Polypropylene Bulkhead Fitting, NSF61 and NSF372 Certified
Item # 108269799
The Green Leaf Inc. 2 in. Polypropylene Bulkhead Fitting helps to permit the free flow of liquids for tank or drum drainage or filling. Made from polypropylene for long-lasting use and resistance to chemicals, these bulkhead fittings are utilized for a variety of agricultural, plumbing and industrial liquid-handling solutions. Highly durable and chemical-resistant, the poly bulkhead fitting is designed to hold up for heavy-duty agricultural applications.
- Includes an EPDM washer for convenience
- Comes as a 2 in. bulkhead fitting
- Polypropylene construction is resistant to chemicals for durability
- Helps permit the free flow of liquids for tank or drum drainage or filling
- NSF61 and NSF372 certified bulkhead fitting
- Manufactured in a variety of sizes ranging from 1/2 in. to 4 in.
- Utilized for a variety of agricultural, plumbing and industrial liquid-handling solutions
- Bulkhead fitting is made in the U.S.A.
- External thread and nut are left-hand threads; internal thread is FPT
- For use with tanks having a wall thickness of 1/16 in. to 1/2 in.
- Materials are FDA approved grade for safe use
| Brand | Green Leaf Inc. |
|---|---|
| Country of Origin | Imported |
| Compatibility | Universal |
| Connection Type | Female |
| End Type | Female-female |
| Features | Chemical Resistant |
| Inlet Diameter | 2 in. |
| Maximum Operating Pressure | 75 PSI |
| Outlet Diameter | 3 in. |
| Package Quantity | 1 |
| Primary Material | Polypropylene |
| Product Height | 4.25 in. |
| Product Length | 4.25 in. |
| Product Weight | 0.55 lb. |
| Product Width | 4.38 in. |
| Manufacturer Part Number | TF 200 P-E |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 12 Questions
Newest questions
Q: is this material schedule 80?
a month ago1 Answer
- A: Howdy neighbor! No, the Green Leaf Inc. 2 in. Polypropylene Bulkhead Fitting is not a Schedule 80 rated component.a month agoHelpful?
Q: What size hole do i drill to install the fitting
9 months ago1 Answer
- A: Hello, thank you for your question. Per the vendor, "The hole size to drill on the TF200PE bulkhead is 3” in diameter."9 months agoHelpful?
Q: Will this bulkhead fitting work on the side of a cone tank?
2 years ago1 Answer
- A: Hello, Thank you for your question. I would need more specifications of your tank to confirm compatibility. This bulkhead fitting is designed for use with tanks having a wall thickness of 1/16” to 1/2". It has a female connection with 2" inlet diameter, 3" outlet diameter and max. operating pressure of 75 PSI. For further assistance, please reach out to the manufacturer. ***GREEN LEAF INC.*** 1 (800) 654-9808 Mon-Fri 8am – 4:30pm (EST) support@green-leaf.us https://green-leaf.us/help-support/2 years agoHelpful?
Q: Does the 2 inch drain have a cap? Would it work for a concrete fountain?
4 years ago1 Answer
- A: The TF200PE does not come with a drain cap. The you would have to purchase a 2” Male NPT plug to cap this part off. It will work in a concrete fountain.4 years agoHelpful?
Q: if i wanted to attach 2 inch pvc pipe after i installed this bulkhead fitting, do i need to use threaded pvc pipe or unthreaded pvc pipe with the pvc cement?
4 years ago1 Answer
- A: For technical assistance, please contact 1-800-654-9808.4 years agoHelpful?
Q: Is it safe for a fuel cell
4 years ago1 Answer
- A: The TF200PE would be safe for use with fuel oil and diesel. High exposures could shorten the life of the rubber sealing gaskets.4 years agoHelpful?
Q: What is the maximum temperature this can withstand
4 years ago1 Answer
- A: Maximum Working Temperature - 140 degrees Fahrenheit4 years agoHelpful?
Q: Is silicone needed to keep a water barrel from leaking?
Anonymous5 years ago1 Answer
- A: No silicon is needed for sealing. During installation the flange and gasket go on the inside of the barrel The nut and friction washer go on the outside. When tightened the gasket will provide the water tight seal.5 years agoHelpful?
Q: Are these slip on the inside or threaded?
5 years ago1 Answer
- A: This product has female threads that are 2" NPT.5 years agoHelpful?
Q: What size hole is needed to install this in a tank?
7 years ago1 Answer
- A: The hole size is 3”.7 years agoHelpful?
1 - 10 of 12 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 12 Questions
Newest questions
Q: is this material schedule 80?
a month ago1 Answer
- A: Howdy neighbor! No, the Green Leaf Inc. 2 in. Polypropylene Bulkhead Fitting is not a Schedule 80 rated component.a month agoHelpful?
Q: What size hole do i drill to install the fitting
9 months ago1 Answer
- A: Hello, thank you for your question. Per the vendor, "The hole size to drill on the TF200PE bulkhead is 3” in diameter."9 months agoHelpful?
Q: Will this bulkhead fitting work on the side of a cone tank?
2 years ago1 Answer
- A: Hello, Thank you for your question. I would need more specifications of your tank to confirm compatibility. This bulkhead fitting is designed for use with tanks having a wall thickness of 1/16” to 1/2". It has a female connection with 2" inlet diameter, 3" outlet diameter and max. operating pressure of 75 PSI. For further assistance, please reach out to the manufacturer. ***GREEN LEAF INC.*** 1 (800) 654-9808 Mon-Fri 8am – 4:30pm (EST) support@green-leaf.us https://green-leaf.us/help-support/2 years agoHelpful?
Q: Does the 2 inch drain have a cap? Would it work for a concrete fountain?
4 years ago1 Answer
- A: The TF200PE does not come with a drain cap. The you would have to purchase a 2” Male NPT plug to cap this part off. It will work in a concrete fountain.4 years agoHelpful?
Q: if i wanted to attach 2 inch pvc pipe after i installed this bulkhead fitting, do i need to use threaded pvc pipe or unthreaded pvc pipe with the pvc cement?
4 years ago1 Answer
- A: For technical assistance, please contact 1-800-654-9808.4 years agoHelpful?
Q: Is it safe for a fuel cell
4 years ago1 Answer
- A: The TF200PE would be safe for use with fuel oil and diesel. High exposures could shorten the life of the rubber sealing gaskets.4 years agoHelpful?
Q: What is the maximum temperature this can withstand
4 years ago1 Answer
- A: Maximum Working Temperature - 140 degrees Fahrenheit4 years agoHelpful?
Q: Is silicone needed to keep a water barrel from leaking?
Anonymous5 years ago1 Answer
- A: No silicon is needed for sealing. During installation the flange and gasket go on the inside of the barrel The nut and friction washer go on the outside. When tightened the gasket will provide the water tight seal.5 years agoHelpful?
Q: Are these slip on the inside or threaded?
5 years ago1 Answer
- A: This product has female threads that are 2" NPT.5 years agoHelpful?
Q: What size hole is needed to install this in a tank?
7 years ago1 Answer
- A: The hole size is 3”.7 years agoHelpful?
1 - 10 of 12 Questions
Similar Items
-
-
-
-
-
-
Top Rated
-
-
-
-
Top Rated
-
Top Rated
-
Top Rated
Items You May Like
-
-
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
-
-
Reviews
1 to 4 of 11 Reviews .
1 – 4 of 11 Reviews
Most Recent
Georgia
Review 1
1 out of 5 stars.
could not disassemble
a month ago
I could not remove the outer ring of the fitting - it was stuck - so had to replace.
No, I do not recommend this product.
Review 1
4 out of 5 stars.
$$
a year ago
They worked great, just kinda pricey.
SweepstakesYes
Yes, I recommend this product.
Dunlap, Tn
Review 1
5 out of 5 stars.
Good quality and easy to install.
2 years ago
I used these to connect my rain barrels with the overflow pipe. They work great and are easy to install. I used a 3 inch hole saw to cut the hole for drainage. Thank you,
2023 Sweepstakes EntryYes
Yes, I recommend this product.
Review 1
5 out of 5 stars.
Fast service
3 years ago
Great product good quality friendly service awesome management
Yes, I recommend this product.
