Evolution 1.44 in. Swing 1-Speed 1-1/8 in. Magnetic Drill Press
Item # 2029815
The Evolution S28MAG 1-1/8 in. Magnetic Drill Press effortlessly bores through steel - ideal for steel framework, I-beams, and bridges. Equipped with a powerful 10-amp motor and a magnet with 2860 lbs. force, this drill makes light work of steel drilling up to 1-1/8 inch wide and 2 inch deep. Use Evolution Cyclone cutters for the best results. Its powerful 10Amp motor, high torque gearbox and durable double dovetail slides have earned the heavy-duty badge. This machine is made for the most demanding jobs both in and away from the workshop. Rear & top mounted controls make this tool easy to use in any orientation and the 8 ft power cord minimizes the need for extension cords. Versatile in cutting/ drilling holes up to 1-1/8 inch wide and 2 inch deep with Evolution annular cutters. Includes a 3-jaw chuck for use with traditional twist drills up to 1/2 inch. The S28MAG features a detachable, integrated coolant system that will help significantly increase the life expectancy of your drill bits as well as your cutters. Fluid is sold separately. It's robust & heavy duty all the while being easily transportable with supplied carrying case. Having a strong magnetic adhesion enables you to drill with precision and peace of mind on site.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Simple to use coolant system ensures that the workpiece stays cool while drilling
- Textured, Tri-spoke spindle handle gives you ultimate control when lowering the drill
- Ultra-smooth dovetail slides offer smooth and precise operation
- Coolant bottle with quick push fit tube connection included for long cutter life and smooth drilling
- With 2860 lbs of holding force, this machine isnt moving an inch
- Quick and easy to fit annular cutters attach directly to the arbor or insert the supplied 3-jaw chuck to use traditional twist drills
- 2 stage magnet allows you to precisely configure the machine, producing perfect results every time
- Compatible with a range of Evolution premium annular cutters and accessories
- Backed by a 3-year warranty and friendly US-based customer service team
| Brand | Evolution |
|---|---|
| Country of Origin | Imported |
| Amperage | 10 Amps |
| Chuck Type | Keyed |
| Cord Length | 8 ft. 2 in. |
| Decibel Rating | 8 ft. 2 in. |
| Drilling Capacity | 0.5 in. |
| Drills Through | Metal |
| Features | Industrial Quality, Integrated Coolant System, Includes Carry Case |
| Horsepower | 0 hp |
| Maximum Chuck Size | 0.75 in. |
| Maximum Speed | 450 rpm |
| Minimum Speed | 450 rpm |
| Mounting Location | Bench Top |
| Number of Speeds | 1 |
| Portable or Stationary | Portable |
| Product Height | 23 in. |
| Product Length | 8 in. |
| Product Weight | 26 lb. |
| Product Width | 19 in. |
| Spindle Travel Distance | 2 in. |
| Swing | 1.44 in. |
| Table Material | Other |
| Variable Speed | Single Speed |
| Voltage | 120 V |
| Warranty | 3 year limited |
| Work Table Length | 0 in. |
| Work Table Width | 0 in. |
| Manufacturer Part Number | S28MAG |
