Chief 2.5 in. Bore x 24 in. Stroke LD Loader Welded Cylinder, 1.5 in. Rod Diameter
$299.99
Chief 2.5 in. Bore x 24 in. Stroke LD Loader Welded Cylinder, 1.5 in. Rod Diameter
Chief 2.5 in. Bore x 24 in. Stroke LD Loader Welded Cylinder, 1.5 in. Rod Diameter
Item # 130779299
$299.99
or
or
Add this item to unlock free delivery!
Get everything you need
Neighbor’s Club Members earn points with purchases.
Chief 2.5 in. Bore x 24 in. Stroke LD Loader Welded Cylinder, 1.5 in. Rod Diameter
Item # 130779299
$299.99
or
or
$50/mo.† suggested payments with 6 Months Financing or earn $14 in Rewards+ on this purchase.
Add this item to unlock free delivery!
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Chief 2.5 in. Bore x 24 in. Stroke LD Loader Welded Cylinder is a small bore welded hydraulic cylinder designed for light-duty loaders. The rod and base ends are welded cross-tubes with grease zerk, giving the hydraulic cylinder a durable and easy to use design. The cylinder's ductile iron piston utilizes a wear ring to protect the seal from wear, increasing the lifespan of the product tremendously.
- Welded hydraulic cylinder is ideal for construction, agricultural and other applications
- Intended use: double-acting applications
- Piston: ductile iron
- Gland: ductile iron
- Tube: honed steel
- Rod: hard chrome-plated
- End mounts: cross-tubes
- Tube seal: Buna O-ring with polytemp hytrel back-up
- Rod seal: polyurethane U-cup
- Rod wiper: polyurethane, snap-in
- Piston seal: 755 with wear rings, (2 each) wear bearings
- All seals are manufactured to US specifications
- Ports: SAE O-rings
- Measures 37 in. retracted and 61 in. extended
- Packaging: individually poly bagged
- Column load: 13,440 lb.
- Pin diameter of 1.25 in. and rod diameter of 1.5 in.
- 3 year warranty included on the hydraulic cylinder
| Brand | Chief |
|---|---|
| Country of Origin | Imported |
| Bore Diameter | 2.5 in. |
| Brand Compatibility | Universal |
| Compatibility | Most applications |
| Extended Length | 24 in. |
| Hydraulic Cylinder Type | Welded |
| Maximum Operating Pressure | 3,000 PSI |
| Maximum Weight Capacity | 13,440 lb. |
| Model Compatibility | Most applications |
| Package Quantity | 1 |
| Pin Diameter | 1.25 in. |
| Port Size | SAE 8 |
| Primary Material | Steel |
| Product Height | 0 N/A |
| Product Length | 0 N/A |
| Product Weight | 34 lb. |
| Product Width | 0 N/A |
| Retracted Length | 37 in. |
| Rod Diameter | 3-1/2 in. |
| Single/Double Acting | Double acting |
| Stroke Distance | 24 in. |
| Warranty | 3 Year |
| Manufacturer Part Number | 288611 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 3 of 3 Questions
Newest questions
Q: @ill it fit the loader on my john deere 2630? The front bucket cylinder.
2 years ago1 Answer
- A: This part is listed as universal and should work for most applications. We recommend measuring your loader first. The inside diameter of both crosstubes is 1.27” The length of the base crosstube is 2.87” The length of the rod crosstube is 3.50” Pin diameter of 1.25 in. and rod diameter of 1.5 in. Measures 37 in. retracted and 61 in. extended2 years agoHelpful?
Q: what is the inside diameter and length of the mounting cross tubes?
5 years ago1 Answer
- A: The inside diameter of both crosstubes is 1.27” The length of the base crosstube is 2.87” The length of the rod crosstube is 3.50”5 years agoHelpful?
Q: Will this be compatible with a New Holland SML51552 for a 620 TL front end loader
5 years ago1 Answer
- A: Yes, it should. We recommend measuring your loader first.5 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 3 of 3 Questions
Newest questions
Q: @ill it fit the loader on my john deere 2630? The front bucket cylinder.
2 years ago1 Answer
- A: This part is listed as universal and should work for most applications. We recommend measuring your loader first. The inside diameter of both crosstubes is 1.27” The length of the base crosstube is 2.87” The length of the rod crosstube is 3.50” Pin diameter of 1.25 in. and rod diameter of 1.5 in. Measures 37 in. retracted and 61 in. extended2 years agoHelpful?
Q: what is the inside diameter and length of the mounting cross tubes?
5 years ago1 Answer
- A: The inside diameter of both crosstubes is 1.27” The length of the base crosstube is 2.87” The length of the rod crosstube is 3.50”5 years agoHelpful?
Q: Will this be compatible with a New Holland SML51552 for a 620 TL front end loader
5 years ago1 Answer
- A: Yes, it should. We recommend measuring your loader first.5 years agoHelpful?
Similar Items
-
-
-
-
Top Rated
-
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
Top Rated
Items You May Like
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
-
-
-
Customers Also Bought
-
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
-
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
Reviews
Customer Images and Videos
1 to 2 of 2 Reviews .
1 – 2 of 2 Reviews
Most Recent
Doug
Pickens, SC
Review 1
5 out of 5 stars.
Excellent replacement for my John Deere 40 Loader
4 years ago
Purchased the loader hydraulic cylinders for the bucket of my John Deere 40 Loader. They perform just as well and a fraction of the cost of a new John Deere cylinder. They are actually only slightly more than rebuilding the cylinders. Although the bore is slightly smaller, cannot tell a difference in performance of the bucket. The new Chief cylinders have been used more than the rebuilt ones I had on the tractor (that started leaking) and have no issues so far. Even if they did, they have a 2 year warranty. I already picked out the Chief cylinders to replace my boom cylinders when they start leaking. The boom ones have the same bore as the old.
Yes, I recommend this product.
Originally posted on baileyhydraulics.com
Review 1
5 out of 5 stars.
Great product
5 years ago
Easy to install , worked as advertised . I will definitely buy again if i need another
