Carry-On Trailer 3,500 lb. Idler Axle, 88 in. Hub Face
$249.99
Sale
Was$329.99
Save $80.00
Carry-On Trailer 3,500 lb. Idler Axle, 88 in. Hub Face
Limited Time Deal
Carry-On Trailer 3,500 lb. Idler Axle, 88 in. Hub Face
Item # 17542399
$249.99
Sale
Was$329.99
Save $80.00
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
Limited Time Deal
Carry-On Trailer 3,500 lb. Idler Axle, 88 in. Hub Face
Item # 17542399
$249.99
Sale
Was$329.99
Save $80.00
or
or
$42/mo.† suggested payments with 6 Months Financing or earn $12 in Rewards+ on this purchase.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Carry-On Trailer Idler Axle has a 88 in. hub face and 74.5 in. spring seat spacing. The idler axle fits 5-lug wheels with 4.5 in. bolt pattern. The round steel tube design of the Carry-On Trailer idle axle offers long-term strength and reliability. The idler axle has a 3,500 lb. maximum weight capacity.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Round steel tube design for durability
- 3,500 lb. capacity for each Carry-On Trailer idler axle
- Hub face spacing on the idler axle: 88 in.
- Spring seat spacing on the idler axle: 74.5 in.
- Carry-On Trailer idler axle fits 5-lug wheels with a 4.5 in. bolt pattern
| Brand | Carry-On Trailer |
|---|---|
| Country of Origin | Imported |
| Compatibility | 5-lug wheels with a 4.5 in. bolt pattern |
| Maximum Weight Capacity | 3,500 lb. |
| Mounting Type | Other |
| Package Quantity | 1 |
| Primary Material | Steel |
| Product Height | 8 in. |
| Product Length | 92 in. |
| Product Weight | 46 lb. |
| Product Width | 8 in. |
| Manufacturer Part Number | 8874T |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 58 Questions
Newest questions
Q: I have a carry on trailer 7x12gwatv need a axle
4 months ago1 Answer
- A: The axle part number is 3K9380EZ. You will have your TSC store order it for you.4 months agoHelpful?
Q: is this a straight or cambered axle?
4 months ago1 Answer
- A: This is a cambered axle.4 months agoHelpful?
Q: What is the thread size and pitch of lug bolt?
8 months ago1 Answer
- A: The knurl diameter is .62 flute OD. The threads are 1/2" x 20 threads per inch.8 months agoHelpful?
Q: Whats the measurements from spring to spring on 3500 lb idler axle 88 in. Face?
9 months ago1 Answer
- A: Center to center on the leaf springs is 74 1/2".9 months agoHelpful?
Q: I just assume that these are pre Lubed ? But i only replaced one on my trailer and this one get significantly warmer than the one I already had installed. I looked in the hub and I can visually see some grease should I put a pump or two ?
9 months ago1 Answer
- A: Go ahead and pump one shot of grease in. If it still gets significantly warmer then back off the castle nut one notch.9 months agoHelpful?
Q: What’s the shaft diameter?
a year ago2 Answers
- A: The spindle diameter that the hub rides on is tapered. The inside bearing will be a 1 3/8" diameter and the outside bearing will be a 1 1/16" diameter.a year agoHelpful?
Q: What measurements are important besides the width and the mounting plates? How can I tell if the bolt patterns on the wheels will match the wheels I have? Can I use the mounting clamps that are there or should I replace them?
a year ago2 Answers
- A: After the width and spring centers the bolt pattern on the hubs, 5 Bolts on 4 1/2" centers. Usually the spring mounts (mounting clamps are OK.a year agoHelpful?
Q: how do you measure hub face dimensions?
a year ago1 Answer
- A: On the axle you have the wheel studs for mounting the tires. At the base of the wheel studs you have the hub face. So measure from face of hub to face of hub for your hub face dimension.a year agoHelpful?
Q: My old axel is square, will this axel still work
a year ago2 Answers
- A: Sir your old axle being square sounds to be a Torsion Axle. The torsion axle is rubber-cushioned for a smooth, quiet independent ride. The rubber-cushion is inside the square tube. The round axle would have to have leaf spring mounts added to your trailer. I would suggest you get a replacement torsion axle.a year agoHelpful?
Q: What is center to cener measure on the springs
a year ago1 Answer
- A: Center to center on the spring mounts is 74 1/2".a year agoHelpful?
1 - 10 of 58 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 58 Questions
Newest questions
Q: I have a carry on trailer 7x12gwatv need a axle
4 months ago1 Answer
- A: The axle part number is 3K9380EZ. You will have your TSC store order it for you.4 months agoHelpful?
Q: is this a straight or cambered axle?
4 months ago1 Answer
- A: This is a cambered axle.4 months agoHelpful?
Q: What is the thread size and pitch of lug bolt?
8 months ago1 Answer
- A: The knurl diameter is .62 flute OD. The threads are 1/2" x 20 threads per inch.8 months agoHelpful?
Q: Whats the measurements from spring to spring on 3500 lb idler axle 88 in. Face?
9 months ago1 Answer
- A: Center to center on the leaf springs is 74 1/2".9 months agoHelpful?
Q: I just assume that these are pre Lubed ? But i only replaced one on my trailer and this one get significantly warmer than the one I already had installed. I looked in the hub and I can visually see some grease should I put a pump or two ?
9 months ago1 Answer
- A: Go ahead and pump one shot of grease in. If it still gets significantly warmer then back off the castle nut one notch.9 months agoHelpful?
Q: What’s the shaft diameter?
a year ago2 Answers
- A: The spindle diameter that the hub rides on is tapered. The inside bearing will be a 1 3/8" diameter and the outside bearing will be a 1 1/16" diameter.a year agoHelpful?
Q: What measurements are important besides the width and the mounting plates? How can I tell if the bolt patterns on the wheels will match the wheels I have? Can I use the mounting clamps that are there or should I replace them?
a year ago2 Answers
- A: After the width and spring centers the bolt pattern on the hubs, 5 Bolts on 4 1/2" centers. Usually the spring mounts (mounting clamps are OK.a year agoHelpful?
Q: how do you measure hub face dimensions?
a year ago1 Answer
- A: On the axle you have the wheel studs for mounting the tires. At the base of the wheel studs you have the hub face. So measure from face of hub to face of hub for your hub face dimension.a year agoHelpful?
Q: My old axel is square, will this axel still work
a year ago2 Answers
- A: Sir your old axle being square sounds to be a Torsion Axle. The torsion axle is rubber-cushioned for a smooth, quiet independent ride. The rubber-cushion is inside the square tube. The round axle would have to have leaf spring mounts added to your trailer. I would suggest you get a replacement torsion axle.a year agoHelpful?
Q: What is center to cener measure on the springs
a year ago1 Answer
- A: Center to center on the spring mounts is 74 1/2".a year agoHelpful?
1 - 10 of 58 Questions
Similar Items
-
-
-
-
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
-
-
Items You May Like
-
-
-
-
Top Rated
-
-
-
-
-
-
-
-
Top Rated
Reviews
- purchase
- installation
- quality
- price
- staff
- product availability
- large
- keys
1 to 4 of 125 Reviews .
1 – 4 of 125 Reviews
Most Recent
Anonymous
Knoxville, Tennessee
Review 1
1 out of 5 stars.
Didn't fit
8 months ago
I measured my current axle as described in the how to order guide and the axle i recieved, though labeled by the manufacturer as the correct axle, did not match the dimensions I measured. There could have been a misunderstanding in the directions (although "hub face" seems to have only one possible meaning to me) but a simple diagram showing the dimensions at different points on the axle I wished to buy would have prevented any confusion.
SweepstakesYes
No, I do not recommend this product.
Response from Carry-On Trailer Customer Service:
8 months ago
Carry-On Trailer Customer Service
The 3K8874EZ axle for example has a hub face to hub face dimension of 88". The center to center of the spring mounts is 74 1/2". The EZ is for easy lube access for the grease.
Anonymous
Hanson, Ma
Review 1
5 out of 5 stars.
perfect fit
a year ago
perfect fit direct replacement
Fl
Review 1
1 out of 5 stars.
Didn’t fit
a year ago
Didn’t fit as required
No, I do not recommend this product.
Response from Carry-On Trailer Customer Service:
a year ago
Carry-On Trailer Customer Service
Call Carry-On Trailer Customer Service (800) 240-3121 Ext. 1915.
Ponca City, Oklahoma
Review 1
5 out of 5 stars.
3500 lb axle
a year ago
Great price and good quality!
SweepstakesYes
Yes, I recommend this product.
