SCHULZ 5HP 80G 2 STAGE (230V 3ph) VERTICAL
Online Only
SCHULZ 5HP 80G 2 STAGE (230V 3ph) VERTICAL
Item # 2592577
$1,977.99
or
or
Add this item to unlock free delivery!
Neighbor’s Club Members earn points with purchases.
$1,977.99
or
or
$59/mo.† for 36 months totaling $2124 at 3.99% APR or earn $98 in Rewards+ on this purchase.
Add this item to unlock free delivery!
This item is available online only
Delivery to
For delivery, this item requires a Big & Bulky handling fee.Learn more
Neighbor’s Club Members earn points with purchases.
DIRECT DRIVE AUDAZ 5HP 80-GALLON TWO-STAGE AIR COMPRESSOR (230V 3-PHASE) - VERTICAL TANK
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- The compressor Audaz MCSV 20/80 is the most innovating one in the market. The exclusive patented technology IC-TECH allows the integrated connection between high efficiency stages. This technology allows lubricating oil to be changed every 300 hours* (which represents a gain of 50% in the durability of the oil). The direct coupling reduces the loss of energy and ensures greater safety. From mechanical workshops to small companies, its productivity will be greater, with less maintenance expense. This compressor of 20 cfm (cubic feet/min) has an integrated 5 hp motor, a plastic cover especially designed to increase the cooling efficiency of the compressor pump and an oil sight glass which facilitates its monitoring.
| Brand | SCHULZ |
|---|---|
| Country of Origin | Imported |
| Airflow Volume | 20 CFM |
| Air Outlet Size | 34 in. |
| Amperage | 21 Amp |
| Compressor Horsepower | 5 HP |
| Lubrication Type | Oil |
| Compressor Maximum PSI | 175 PSI |
| Compressor Operation | Automatic start/stop |
| Compressor Tank Capacity | 80 gal |
| Compressor Voltage | 208V/230V |
| Connection Type | Cable |
| Drain System | Drain on the bottom of the tank |
| Drive Type | N/A |
| Engine Brand | WEG MOTOR |
| Features | The compressor Audaz MCSV 20/80 is the most innovating one in the market. The exclusive patented technology IC-TECH allows the integrated connection between high efficiency stages. This technology allows lubricating oil to be changed every 300 hours. |
| Maximum RPM | 1,750 RPM pump rpm |
| Phase | Triple |
| Number Of Power Speeds | Single |
| Power Type | Electric |
| Primary Color | Gray |
| Primary Material | Cast Iron |
| Product Height | 28 in. |
| Product Length | 24 in. |
| Product Weight | 358 lb. |
| Product Width | 28 in. |
| Pump Life | 5,000 hours with oil change proper maintenance and |
| Pump Material | Cast iron |
| Stage Type | Two-Stage |
| Tank Fill Time | 5 min. |
| Tank Style | Vertical |
| Warranty | 1 YEAR ON THE COMPRESSOR AND 2 YEARS ON THE PUMP |
| Manufacturer Part Number | 932.9363-0 |
