SCHULZ 5HP 3PH 80G - 20CFM - 175PSI 230V, 932.9362-0
$3936.99
AIR COMPRESSOR 5HP THREE PHASE 80 GALLON TANK - 20CFM - 175 PSI 208/230/460v
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- The in line L-series compressors are strong, durable equipment with distinguished performance. With vertical or horizontal tank design, these single and two stage products operate with low RPMs with a high-quality cast iron block. The double-supported crankshaft design provides lower vibration and longer bearing life, as well as the modern valve system (reed type) provides extended service life and excellent product efficiency. Mounted and wired magnetic starters, provide convenience and safety in operation with a ready to use system. The ASME certified safety valve and air tank as well as high efficiency motors make Heavy Duty L-Series compressors the best choice for your company.
| Brand | SCHULZ |
|---|---|
| Country of Origin | Imported |
| Airflow Volume | 20 CFM |
| Air Outlet Size | 34 in. |
| Amperage | 21 Amp |
| Compressor Horsepower | 5 HP |
| Lubrication Type | Oil |
| Compressor Maximum PSI | 175 PSI |
| Compressor Operation | Automatic start/stop |
| Compressor Tank Capacity | 80 gal |
| Compressor Voltage | 208V/230V |
| Connection Type | Cable |
| Drain System | Drain on the bottom of the tank |
| Drive Type | N/A |
| Engine Brand | WEG MOTOR |
| Features | The in line L-series compressors are strong, durable equipment with distinguished performance. With vertical or horizontal tank design, these single and two stage products operate with low RPMs with a high-quality cast iron block. |
| Number Of Power Speeds | Single |
| Power Type | Electric |
| Primary Color | Gray |
| Primary Material | Cast Iron |
| Product Height | 79 in. |
| Product Length | 34 in. |
| Product Weight | 502 lb. |
| Product Width | 26 in. |
| Pump Life | 5,000 hours with oil change proper maintenance and |
| Pump Material | Cast iron |
| Stage Type | Two-Stage |
| Tank Fill Time | 6" minutes |
| Tank Style | Vertical |
| Warranty | 1 YEAR ON THE PRODUCT AND 2 YEARS ON THE PUMP |
| Manufacturer Part Number | 932.9362-0 |
