Kohler SH265 6.5 HP Engine, (Horizontal Shaft) Single Cylinder 3/4 in. Crankshaft with Electric Start with Recoil

SKU # 120768199
Product price

Save Up To
See price at checkout Why?
No ratings found

Financing Available! Click here for more details...



Delivery Options:

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it. Learn More

power plus

Item Information

This Kohler SH265 6.5 HP Engine, (Horizontal Shaft) Single Cylinder 3/4 in. Crankshaft with Electric Start with Recoil has a crankshaft that is 0.75 in. diameter and 2.42 in. PTO length and tapped 5/16-24 UNF. It has recoil and electric start with key box and 10 A charging.

  • Overhead valve design
  • Variable speed
  • Electronic ignition
  • Dual element air cleaner (unless otherwise mentioned)
  • Dual oil fill locations
  • Dual oil drains
  • Cast iron cylinder liner
  • 3.3 L metal fuel tank with strainer
  • Fuel shut-off valve (unless otherwise mentioned)
  • Engine mounted throttle and choke controls, remote throttle ready
  • Oil sentry switch installed (no light)
  • Dual ball bearings, PTO and flywheel
  • Metal blower housing
  • Indexable recoil starter
  • PTO face
  • For engines with SAE crankshaft with 3.625 in. (92.08 mm) diameter (4 and 1 holes) 5/16-24 UNF-2B thread
  • Large capacity muffler with heat shield
  • Multi-lingual owner's manual
  • Black with cast aluminum
  • Carb Tier III, EPA phase 3 and RFI compliant

Note: This product may require up to 2 additional days for order processing prior to shipping

Specification Description
Brand: Kohler
CARB Compliant: Yes
Displacement: 196 cc
Engine Type: Horizontal Shaft
Product Height: 16 in.
Product Length: 16 in.
Product Type: Replacement Engines
Product Weight: 40 lb.
Product Width: 15 in.
Warranty: 2-Year Limited
Manufacturer Part Number PA-SH265-3031

Replacement engine for a Tecumsch 6 HP. Will the mounting bolt be the same spacing for a Kohler SH265 6.5 HP engine.

Asked by: GCB01
They should be. If the Tecumseh is really old you might have to drill a couple of new holes.
Answered by: Kohler Product Expert
Date published: 2017-08-03

Can this engine be used as a direct replacement for a Briggs and Stratton model number: 35202 type: 1259E1

Asked by: Mr E
This has the same foot print and crankshaft height as a standard Briggs. This one has electric start as an option. There also is a standard recoil start. It will replace most standard Briggs engines less than 6.5hp.
Answered by: Kohler Product Expert
Date published: 2016-11-07
