DuraVent DuraPlus 6 in. Triple Wall Pipe Through-the-Roof Stove Chimney Kit, 6DP-KBSC

SKU # 319400299
Product price

Save Up To
See price at checkout Why?
Product Rating is 4.6

Financing Available! Click here for more details...



Pickup In Store

Delivery Options

Item Information

DuraPlus is designed to stay cool on the outside, to provide a hot draft on the inside, to boost stove efficiency, and to provide for a fire-safe design that protects both the chimney and the building. All-in-one kit has everything you need except the necessary lengths of chimney pipe and connector pipe to save time and guesswork. Kit includes DVL and DuraBlack chimney adapter, snap-lock adapter with trim, 11 in. square ceiling support box with trim, adjustable flashing 0/12-6/12 pitch (larger pitch sizes are available and sold separately), chimney cap, storm collar and attic insulation shield.

Specification Description
Product Type: Chimney Pipes
Application/Use: DuraPlus Chimney is a triple-wall, all-fuel chimney for use with wood stoves, fireplaces, furnaces, boilers, stoves, ranges, water heaters, or other appliances fueled by wood, oil, coal, or gas
Brand: DuraVent
Compatibility: DuraPlus
CountryofOrigin: Made in USA
Finish: Stainless Steel or Galvanized
Indoor and/or Outdoor: Indoor and Outdoor
Installation Orientation: Vertical
Inner Diameter: 6 in.
Material: Staineless steel inner and outer with an aluminized steel intermediate liner
Maximum Diameter: 10 in. outer dia
Minimum Product Length: N/A
Maximum Temperature: 2,100 deg.
Minimum Diameter: 6 inner dia
Number of Pieces: 7
Outer Diameter: 10 in.
Part Number: 6DP-KBSC
Product Height: N/A
Product Length: N/A
Product Weight: 31.8 lb.
Product Width: N/A
Special Feature(s): N/A
Thickness: N/A
Type: DuraPlus
Wall Type: Triple-Wall
Manufacturer Part Number 6DP-KBSC
DuraVent DuraPlus 6 in. Triple Wall Pipe Through-the-Roof Stove Chimney Kit, 6DP-KBSC is rated 4.6 out of 5 by 21.
Rated 5 out of 5 by from Straight foward install Bought this as a chimney for my garage shop, haven't got furnace hooked up yet but the kit and install went well and was very straight forward. Looked at other brands and liked the way this installed better and everything seems to be good quality.
Date published: 2018-10-17
Rated 4 out of 5 by from easy to install I bought this kit because i needed a few pieces,I had an old chimney that we replaced i used pretty much everything but the flashing in it, it was very simple to put up and i especially like how the pipe twists and locks in place the only issue i had was the storm collar didnt fit around the pipe as tight as i wanted it to but did a couple adjustments myself and it works fine
Date published: 2018-10-17
Rated 5 out of 5 by from Is what it is Happy with purchase, works as intended with a good look.
Date published: 2018-10-15
Rated 5 out of 5 by from Exactly what I needed to install wood stove Kit had everything I needed to put in a chimney for a new wood stove. Only had to purchase the triple-wall insulated pipe. Install was easy and looks great.
Date published: 2018-10-05
  • y_2018, m_10, d_18, h_14
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_10, tr_11
  • loc_en_US, sid_319400299, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 1ms

Can this kit be used with a metal roof?

Asked by: abe27
Yes, it can be used with metal roofs.
Answered by: DanielB
Date published: 2017-01-08

dimensions of support box please height and width as a square----and can i use 6 inch double wall from stove to the ceiling support box with the triple wall from attic to roof or would double wall all the way be sufficient?

Asked by: Murdock1
Must be triple wall from ceiling support box to cap, no exceptions.
Answered by: Duravent
Date published: 2018-10-04

my roof is 8:12 pitch. Can I substitute an alternate flashing for this steeper roof?

Asked by: Mr Garrison
Only if manufactured by DuraVent.
Answered by: Duravent
Date published: 2018-03-20

I have a cathedral ceiling in my house where I plan to install my stove.Is this the chimney kit I need?

Asked by: AppyDawg
Answered by: Duravent
Date published: 2018-03-20

does it have to be installed in roof or can it be installed in a wall

Asked by: bobf
This must be used for through-the-roof. If you need to go through the wall, we suggest the DuraVent DuraPlus Through the Wall Kit, SKU 3194206.
Answered by: DanielB
Date published: 2018-01-28

can this be used on vaulted ceilings

Asked by: brewskie
The 6DP-KBSC has a shallow 11 inch deep support box, which may work if they have less than a 3/12 ceiling pitch. Model 6DP-KMFG is better for a vaulted celling as it has a deeper 24" support box.
Answered by: BrittanyH
Date published: 2017-09-28

Can this kit be used for catherdral ceilings?

Asked by: mgobes2000
This cannot be used for a cathedral ceiling.
Answered by: Samantha C
Date published: 2017-10-14

What the pipe size opening?

Asked by: MRBi
The chimney pipe's diameter is 6 inches.
Answered by: NRoberts
Date published: 2017-09-27
