VIAIR Medium-Duty Onboard Air System, 150PSI, 12V 2.5 gal. tank
Item # 1383851
Neighbor’s Club Members earn points with purchases.
VIAIR Medium-Duty Onboard Air System, 150PSI, 12V 2.5 gal. tank
Item # 1383851
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Viair Medium Duty Onboard Air System is a pre-packaged compressed onboard air system that provides a 33% duty cycle 325C compressor, 2.5 gal. air tank, and all components needed to install basic vehicle-based pneumatics. The max working pressure of the medium duty onboard air system is 150 PSI. The dash panel gauge included with the onboard air system has an On/Off switch.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Max working pressure of onboard air system: 150 PSI / 1.59 cfm
- 12 volt medium duty onboard air system
- Duty Cycle of medium duty onboard air system: 33% @ 100 PSI
- Onboard air system includes a 325C VIAIR Compressor
- 2.5 gal. VIAIR Air Tank
- Dash Panel Gauge with On/Off Switch
- Pressure Switch with Relay (110 PSI on, 145 PSI off)
- Please Note: Pressure Switch w/Relay (PNs 90110, 90111, 90113, 90118) is not a sealed unit and should be installed in an area protected from the elements to prevent damage and/or failure. Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8 is 10 ~ 11 ft. lb. Recommended torque for 1/4 and 3/8 is 12 ~ 15 ft. lb.
