Stirling 4 x 8ft. Galvalume Kit Trailer, 1,000 lb. Max Capacity
$854.99
Sale
Was$949.99
Save $95.00
Stirling 4 x 8ft. Galvalume Kit Trailer, 1,000 lb. Max Capacity
Limited Time Deal
Stirling 4 x 8ft. Galvalume Kit Trailer, 1,000 lb. Max Capacity
Item # 161645799
$854.99
Sale
Was$949.99
Save $95.00
or
or
Notice:
This Item cannot be shipped to LA, MD.
Neighbor’s Club Members earn points with purchases.
Limited Time Deal
Stirling 4 x 8ft. Galvalume Kit Trailer, 1,000 lb. Max Capacity
Item # 161645799
$854.99
Sale
Was$949.99
Save $95.00
or
or
$72/mo.† suggested payments with 12 Months Financing or earn $42 in Rewards+ on this purchase.
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Notice:
This Item cannot be shipped to LA, MD.Neighbor’s Club Members earn points with purchases.
The Stirling 4'x8' kit trailer is a perfect solution for the customer who wants to build their own trailer so they can easily customize it to suit their needs. This kit comes with everything you'll need to be on the road, including an axle, frame, tires, fender, lights, wiring, and Certificate of Origin document to register. For increased bearing protection and ease of maintenance, we've included EZ Lube hubs. Our V-tongue will provide you with more stability while travelling. When combined with our Premium Galvalume finish, you can be assured that you are getting the best value and performance possible. After assembling the trailer frame, you can customize it to suit a variety of needs, whether it is as a flatbed, closed box trailer, or regular tailgate trailer (material not included). Basic tools are required for assembly.Model: 48-096-KO8
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on trailer? Check out our tips for buying a trailer in the product documents section.
- Superior scratch and corrosion-resistance for long-lasting use
- EZ Lube hubs offer ease of maintenance and added bearing protection
- Stake pockets and registration documentation included
- Assembly required; can be easily assembled using basic tools
- Axle kit trailer measures 4 ft. x 8 ft.
- 1 year warranty against manufacturing defects
- V-tongue adds stability when travelling
- Trailer can be customized to suit a variety of needs
- DOT Approved and Highway Rated
| Brand | Stirling |
|---|---|
| Country of Origin | Imported |
| Approximate Trailer Size (W x L) ft. | 4 x 8 |
| Axle Size | 1,500 lb. |
| Empty Weight | 230 lb |
| Floor Material | Galvanized steel |
| Frame Material | Galvanized Steel |
| Gate Length | No Gate |
| Gate Width | 0 in. |
| Gross Vehicle Weight Rating | 1,230 lb. |
| Hitch Type | Class I |
| Trailer Load Capacity lb. | 0 - 1999 |
| Number of Axles | 1 |
| Number Of Ramps | 0 |
| Ramp Type | None |
| Rear Door Style | None |
| Tire Size | 4.80 x 8 LRC |
| Tongue Length | 4 ft. |
| Tongue Type | V-Tongue |
| Trailer Bed Length | 8 ft |
| Trailer Bed Width | 4 ft |
| Trailer Features | DOT Approved, Highway Rated |
| Trailer Max Load Capacity lb. (Carrying Capacity) | 1000 |
| Warranty | 1 Year |
| Manufacturer Part Number | 504078 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 109 Questions
Newest questions
Q: Can this trailer be used to support a mobile coffee trailer?
16 days ago2 Answers
- A: Hi there, Without knowing the dimensions, weight and other specifications of the coffee trailer it is very difficult to determine this. You can visit the link below to see the specification of the 4x8ft Kit Trailer though. This should help you make your decision. If you have any questions reach out to us directly at support@westbrooktrailers.com. https://stirlingtrailers.com/trailer-categories/kit-trailers/ ~~ Westbrook Trailers Team14 days agoHelpful?
Q: what do you need to do to license this trailer??
5 months ago2 Answers
- A: Hi Smitty, You will need your Bill of Sale and the Certificate of Origin for the trailer to have it registered at your local DMV. If you have any other questions please feel free to reach out to us directly at support@westbrooktrailers.com. ~~ Westbrook Trailers Team5 months agoHelpful?
Q: What gauge metal is used in the frame?
6 months ago1 Answer
- A: Thanks for your question! On this model, the metal gauge varies by section rather than using a single gauge throughout. The A-frame is constructed from 14GA steel, while the main frame uses 16GA steel. The overall trailer strength comes from how these different components are structured and reinforced together, not just one gauge number alone. If you’d like more detailed information about a specific area of the trailer, please reach out to our support team at support@westbrooktrailers.com, and we’ll be happy to help. - Westbrook Trailers Team6 months agoHelpful?
Q: What is the total width? From outside tire to outside tire?
9 months ago1 Answer
- A: Hi Kaw4, Thank you for your inquiry. Our Stirling 4' x 8' Kit Trailer has a width from outside each tire of 59". If you have any other questions please reach out to us directly at support@westbrooktrailers.com. ~~ Westbrook Trailers Team9 months agoHelpful?
Q: Can the tires be upgraded to a larger size?
9 months ago1 Answer
- A: Hi there Cd3pO, Thank you for your inquiry. Yes, our 4' x 8' Kit Trailer can be upgraded to a 12" tire, noting you will need to upgrade the fender as well. If you have any further questions please reach out directly at support@westbrooktrailers.com. ~~ Westbrook Trailers Team9 months agoHelpful?
Q: what is the diameter of the axle
9 months ago1 Answer
- A: Hi there Digdug, Thank you for your inquiry. For our Kit Trailers we use Dexter Axles. Below are the specifications: Axle Capacity: 1,500 Lbs. Hub Face: 60.47" Spring Center: 47.11" Spindle Type: Straight Bolt Pattern: 5 - 4.5" If you are looking for more information please reach out to us directly at support@westbrooktrailers.com ~~ Westbrook Trailers Team9 months agoHelpful?
Q: Would this be ok to use as a kayak trailer? Can the light and wiring be submerged?
9 months ago1 Answer
- A: Hi there Jason, Thank you for your email. The Stirling Galvalume Kit trailers lighting is NOT submersible. The Kit trailer or Boat trailers have been used successfully to haul kayaks with our customers though. The Boat Trailers do come with submersible lighting options. If you have any other questions please reach out to us directly at support@westbrooktrailers.com ~~ Westbrook Trailers Team9 months agoHelpful?
Q: Speed rating of tires?
10 months ago2 Answers
- A: Hello Robinson, Our 4ft x 8ft Kit Trailers come with 8" Tires that have a rating of 62 MPH / 100 KM/H. ~~ Westbrook Trailers Team10 months agoHelpful?
Q: How many packages in this kit? How heavy are each package?
10 months ago1 Answer
- A: Hi there Bob, The 4ft x 8ft single axle Stirling Trailer is shipped in 2 Boxes. Box 1 is 84 lbs and contains the Tires, Fenders & Hardware. Box 2 is 104 lbs and contains the Frame & Axle. Please feel free to contact us directly if you have more questions at 1-866-857-1445 or support@westbrooktrailers.com. ~~ Westbrook Trailers Team10 months agoHelpful?
Q: What is the deck width in between the wheels?
11 months ago1 Answer
- A: XYZ123, The deck floor measures 49.6 inches between the tires on the 4 x 8ft Kit Trailer. If you have any other inquires about the specifics please see the below link: https://www.westbrooktrailers.com/wp-content/uploads/2022/04/48-096-K08-Measurements-1.pdf ~~ Westbrook Trailers Team11 months agoHelpful?
1 - 10 of 109 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 109 Questions
Newest questions
Q: Can this trailer be used to support a mobile coffee trailer?
16 days ago2 Answers
- A: Hi there, Without knowing the dimensions, weight and other specifications of the coffee trailer it is very difficult to determine this. You can visit the link below to see the specification of the 4x8ft Kit Trailer though. This should help you make your decision. If you have any questions reach out to us directly at support@westbrooktrailers.com. https://stirlingtrailers.com/trailer-categories/kit-trailers/ ~~ Westbrook Trailers Team14 days agoHelpful?
Q: what do you need to do to license this trailer??
5 months ago2 Answers
- A: Hi Smitty, You will need your Bill of Sale and the Certificate of Origin for the trailer to have it registered at your local DMV. If you have any other questions please feel free to reach out to us directly at support@westbrooktrailers.com. ~~ Westbrook Trailers Team5 months agoHelpful?
Q: What gauge metal is used in the frame?
6 months ago1 Answer
- A: Thanks for your question! On this model, the metal gauge varies by section rather than using a single gauge throughout. The A-frame is constructed from 14GA steel, while the main frame uses 16GA steel. The overall trailer strength comes from how these different components are structured and reinforced together, not just one gauge number alone. If you’d like more detailed information about a specific area of the trailer, please reach out to our support team at support@westbrooktrailers.com, and we’ll be happy to help. - Westbrook Trailers Team6 months agoHelpful?
Q: What is the total width? From outside tire to outside tire?
9 months ago1 Answer
- A: Hi Kaw4, Thank you for your inquiry. Our Stirling 4' x 8' Kit Trailer has a width from outside each tire of 59". If you have any other questions please reach out to us directly at support@westbrooktrailers.com. ~~ Westbrook Trailers Team9 months agoHelpful?
Q: Can the tires be upgraded to a larger size?
9 months ago1 Answer
- A: Hi there Cd3pO, Thank you for your inquiry. Yes, our 4' x 8' Kit Trailer can be upgraded to a 12" tire, noting you will need to upgrade the fender as well. If you have any further questions please reach out directly at support@westbrooktrailers.com. ~~ Westbrook Trailers Team9 months agoHelpful?
Q: what is the diameter of the axle
9 months ago1 Answer
- A: Hi there Digdug, Thank you for your inquiry. For our Kit Trailers we use Dexter Axles. Below are the specifications: Axle Capacity: 1,500 Lbs. Hub Face: 60.47" Spring Center: 47.11" Spindle Type: Straight Bolt Pattern: 5 - 4.5" If you are looking for more information please reach out to us directly at support@westbrooktrailers.com ~~ Westbrook Trailers Team9 months agoHelpful?
Q: Would this be ok to use as a kayak trailer? Can the light and wiring be submerged?
9 months ago1 Answer
- A: Hi there Jason, Thank you for your email. The Stirling Galvalume Kit trailers lighting is NOT submersible. The Kit trailer or Boat trailers have been used successfully to haul kayaks with our customers though. The Boat Trailers do come with submersible lighting options. If you have any other questions please reach out to us directly at support@westbrooktrailers.com ~~ Westbrook Trailers Team9 months agoHelpful?
Q: Speed rating of tires?
10 months ago2 Answers
- A: Hello Robinson, Our 4ft x 8ft Kit Trailers come with 8" Tires that have a rating of 62 MPH / 100 KM/H. ~~ Westbrook Trailers Team10 months agoHelpful?
Q: How many packages in this kit? How heavy are each package?
10 months ago1 Answer
- A: Hi there Bob, The 4ft x 8ft single axle Stirling Trailer is shipped in 2 Boxes. Box 1 is 84 lbs and contains the Tires, Fenders & Hardware. Box 2 is 104 lbs and contains the Frame & Axle. Please feel free to contact us directly if you have more questions at 1-866-857-1445 or support@westbrooktrailers.com. ~~ Westbrook Trailers Team10 months agoHelpful?
Q: What is the deck width in between the wheels?
11 months ago1 Answer
- A: XYZ123, The deck floor measures 49.6 inches between the tires on the 4 x 8ft Kit Trailer. If you have any other inquires about the specifics please see the below link: https://www.westbrooktrailers.com/wp-content/uploads/2022/04/48-096-K08-Measurements-1.pdf ~~ Westbrook Trailers Team11 months agoHelpful?
1 - 10 of 109 Questions
Reviews
Summary of Reviews
The product is a well-constructed trailer with easy assembly, though some customers experienced issues with missing or damaged parts and difficulty with the assembly process due to misaligned holes. Despite these drawbacks, the trailer is generally considered a good value with satisfactory quality a...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
5 out of 5 stars.
Nice Easy To build Trailer Kit
4 years ago
I bought this trailer to make a boat trailer for my Inflatable boat, I did an axle flip so i could lower the fenders to be even with the trailer and make it sit a little higher. Also changed the coupler to 2 inch and added a tongue jack. Happy with the way it is going, now I am starting on the bunks for the boat. My boat weighs around 200 pounds without motor and gear so this trailer is just right for my needs.
12 people found this helpful
Show Reviews:
Most Helpful Critical Review
2 out of 5 stars.
Tires to small
3 years ago
The instructions were lacking on clear pictures. I found the online video which helped out. Once done those little tires leave 6 “ clearance. You slightly tilt and it’s dragging. There is absolutely no room for a license plate to be added since LP is 6”. LP drags on ground. The tire upgrade tire pricing is ridiculous . The trailer itself is great, tires are way to small
7 people found this helpful
Show Reviews:
Customer Images and Videos
- instructions
- setup
- price
- purchase
- size
- light
- weight
- satisfaction
1 to 4 of 151 Reviews .
1 – 4 of 151 Reviews
Most Recent
Review 1
5 out of 5 stars.
Easy assembly.
2 days ago
Fairly easy assembly. Assembling the frame off the ground, about knee height, makes tightening the bolts easier.
SweepstakesYes
Yes, I recommend this product.
Response from Stirling Trailers:
a day ago
Stirling Trailers
Mike,
Thank you for the 5-star review! We're glad to hear the assembly process went smoothly and appreciate you sharing your helpful tip about assembling the frame off the ground. Thank you for choosing Stirling, and we hope you enjoy your trailer for years to come.
Thank you for the 5-star review! We're glad to hear the assembly process went smoothly and appreciate you sharing your helpful tip about assembling the frame off the ground. Thank you for choosing Stirling, and we hope you enjoy your trailer for years to come.
Anonymous
Lodi, CA
Review 1
4 out of 5 stars.
4x8 trailer
7 days ago
The trailer will work for me well. I was not aware I had to put it together, but I did and it will work well for what I need.
SweepstakesYes
Response from Stirling Trailers:
3 days ago
Stirling Trailers
Hi Bill, Thank you for your review! We're glad to hear your Stirling 4' x 8' Kit Trailer will work well for your needs. We're sorry to hear the kit assembly came as a surprise. We appreciate your feedback and will share it with our team as we continue looking for ways to make the product information as clear as possible. Thank you for choosing Stirling Trailers, and we wish you many years of reliable service. ~~ Westbrook Trailers Team
Anonymous
Review 1
3 out of 5 stars.
Very difficult
4 months ago
Missing bolts. Took extra time to go get more hardware. Instructions are horrible. Said i needed a 3 inch bolts and none came with it. The lights listed wrong color wire. Axle Instructions were terrible.
SweepstakesYes
Yes, I recommend this product.
Response from Stirling Trailers:
4 months ago
Stirling Trailers
Hi Dan,
Thank you for taking the time to share your feedback. We’re very sorry to hear about the difficulties you experienced during assembly and understand how frustrating missing hardware or unclear instructions can be. We sincerely apologize for the inconvenience this may have caused.
Based on customer feedback, we have recently updated our assembly instructions to make the process clearer and easier to follow. If possible, could you please let us know which version of the instructions you were using? We would be happy to provide you with the most up-to-date version.
Our revised instruction manual also includes a QR code that links to a full step-by-step assembly video, which many customers have found very helpful. Please let us know if you had the opportunity to review the video prior to assembly, or if you would like us to send the link directly.
Please also note that all of our trailers are backed by a 1-year manufacturer’s warranty. If any parts or hardware were missing, we would be more than happy to replace them. Should you need any assistance, please feel free to contact us directly at support@westbrooktrailers.com
— our team is always happy to help and ensure everything is resolved for you.-- Westbrook Trailers Team
Thank you for taking the time to share your feedback. We’re very sorry to hear about the difficulties you experienced during assembly and understand how frustrating missing hardware or unclear instructions can be. We sincerely apologize for the inconvenience this may have caused.
Based on customer feedback, we have recently updated our assembly instructions to make the process clearer and easier to follow. If possible, could you please let us know which version of the instructions you were using? We would be happy to provide you with the most up-to-date version.
Our revised instruction manual also includes a QR code that links to a full step-by-step assembly video, which many customers have found very helpful. Please let us know if you had the opportunity to review the video prior to assembly, or if you would like us to send the link directly.
Please also note that all of our trailers are backed by a 1-year manufacturer’s warranty. If any parts or hardware were missing, we would be more than happy to replace them. Should you need any assistance, please feel free to contact us directly at support@westbrooktrailers.com
— our team is always happy to help and ensure everything is resolved for you.-- Westbrook Trailers Team
Review 1
3 out of 5 stars.
Product fine, promotion deceptive
5 months ago
Trailer is fine, delivery charge a deception.
Response from Stirling Trailers:
5 months ago
Stirling Trailers
Hi Barney, Thank you for the review we appreciate it. Sorry to hear about your unexpected delivery charges. If you have any questions or inquiries please reach out at support@westbrooktrailers.com. ~~ Westbrook Trailers Team
