Carry-On Trailer 5 x 8ft. Mesh Floor Utility Trailer, 1,600 lb. Max Capacity
$1,199.99
Carry-On Trailer 5 x 8ft. Mesh Floor Utility Trailer, 1,600 lb. Max Capacity
Exclusive
Carry-On Trailer 5 x 8ft. Mesh Floor Utility Trailer, 1,600 lb. Max Capacity
Item # 109020299
$1,199.99
or
or
Important
- Trailer must be picked up by registered owner.
- Additional paperwork may be required at the time of pickup.
- Sunday pickup may be prohibited by local or state laws.
- Please check your local and state code regulations for specific details.
- This custom-built trailer may take up to 21 days to ship this item.
Notice:
This Item cannot be shipped to CA, CO, ID, KS, LA, MD, NV, PA, UT.
Neighbor’s Club Members earn points with purchases.
Exclusive
Carry-On Trailer 5 x 8ft. Mesh Floor Utility Trailer, 1,600 lb. Max Capacity
Item # 109020299
$1,199.99
or
or
$92/mo.† suggested payments with 12 Months Financing or earn $54 in Rewards+ on this purchase.
Out of stock at or near
Grassland (franklin) TN
Important
- Trailer must be picked up by registered owner.
- Additional paperwork may be required at the time of pickup.
- Sunday pickup may be prohibited by local or state laws.
- Please check your local and state code regulations for specific details.
- This custom-built trailer may take up to 21 days to ship this item.
Notice:
This Item cannot be shipped to CA, CO, ID, KS, LA, MD, NV, PA, UT.Neighbor’s Club Members earn points with purchases.
Built for enduring performance and flexibility, the Carry-On Trailer 5 ft. x 8 ft. Mesh Floor Utility Trailer is designed to tackle diverse hauling demands effortlessly. Featuring fully welded steel construction, the streamlined design ensures reliable functionality for a multitude of tasks. Equipped with 13in. tires for enhanced stability and smoother rides. From gear to materials, this trailer delivers the essential versatility you require for a wide range of jobs. The E-Z lube axle simplifies maintenance by allowing easy lubrication of both inner and outer bearings without disassembly, saving time and effort while also resulting in smoother operation.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on trailer? Check out our tips for buying a trailer in the product documents section.
- STEEL MESH FLOOR: Lighter than solid wood floors, increasing payload capacity, the steel mesh provides great traction for items being transported, and loose debris can be swept through the mesh pattern for easy cleanup.
- VERSATILE GATE DESIGN: The gate folds down to serve as a ramp for easy loading/unloading, or it folds into the trailer bed when needed to accommodate various cargo and reduce wind resistance during transport.
- E-Z LUBE AXLE: Simplifies maintenance by allowing easy lubrication of both inner and outer bearings without disassembly, saving time and effort while also resulting in smoother operation.
- STRAIGHT TONGUE: The straight tongue design offers enhanced maneuverability for easy navigation in tight spaces while maximizing space efficiency for convenient storage when not in use.
| Brand | Carry-On Trailer |
|---|---|
| Country of Origin | Made in USA |
| Approximate Trailer Size (W x L) ft. | 5 x 8 |
| Axle Size | 71 in. hub face , 58.5 in. spring centers |
| Coupler Size | 2 in. Straight |
| Empty Weight | 400 lb |
| Floor Material | Steel Mesh |
| Frame Material | Steel |
| Gate Length | 49 in |
| Gate Width | 57 in. |
| Gross Vehicle Weight Rating | 2,000 lb. |
| Hitch Type | Not Specified |
| Trailer Load Capacity lb. | 0 - 1999 |
| Number of Axles | 1 |
| Number Of Ramps | 1 |
| Ramp Type | Back |
| Rear Door Style | Ramp |
| Tire Size | 13 in. |
| Tongue Length | 37.5 in. from front rail |
| Tongue Type | Straight |
| Trailer Bed Length | 8 ft |
| Trailer Bed Width | 5 ft |
| Trailer Features | Steel Floor, Ramp Included |
| Trailer Max Load Capacity lb. (Carrying Capacity) | 1600 |
| Warranty | 1-Year Limited |
| Manufacturer Part Number | 5X8SP |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 673 Questions
Newest questions
Q: What is the height of the top of the hitch with the trailer level
8 days ago1 Answer
- A: The top of the hitch is 14".7 days agoHelpful?
Q: What is the bolt pattern for the wheels to purchase a spare wheel/tire?
12 days ago1 Answer
- A: The bolt pattern is 5 bolts on 4 1/2" centers.11 days agoHelpful?
Q: Can it accommodate a golf cart
20 days ago1 Answer
- A: The deck dimensions are 60" wide by 96" long. The maximum load capacity for the trailer is 1600 lbs. and the maximum load for the ramp gate is 800 lbs..19 days agoHelpful?
Q: Bolt pattern and dimensions
23 days ago1 Answer
- A: The Bolt pattern is 5 bolts on 4 1/2" centers.20 days agoHelpful?
Q: How many "D" tie downs are on the trailer?
27 days ago1 Answer
- A: There are (4) 1 1/2" x 1 1/2" x 1/8" angle tie downs.20 days agoHelpful?
Q: what is the bearing size for this trailer?
28 days ago1 Answer
- A: The bearing size is 1 1/16"28 days agoHelpful?
Q: What replacement axel do I buy?
2 months ago1 Answer
- A: Hi, to best assist you with this inquiry, please reach out to Tractor Supply Customer Solutions at 877-718-6750.2 months agoHelpful?
Q: Is the gate Ramp removable? And what type of wire harness pull will I need for the tail lights ?
2 months ago1 Answer
- A: You will need a 4 Way Flat wiring Harness.2 months agoHelpful?
Q: Are brake and turn signal lights installed
3 months ago1 Answer
- A: Yes the brake lights, the turn signal lights and the running lights are all installed on the trailer. The lighting meets all Department Of Transportation requirements.3 months agoHelpful?
Q: Will the mesh ramp hold strong enough and able to hold up when a 42" zero turn mower is loaded onto and off without bending the mesh ramp?
4 months ago1 Answer
- A: If your 42" zero turn mower's wheels do not line up with the trailer ramps structural cross members you will have the steel mesh stretching at some point in time. You can offset this issue with a piece of plywood to use when loading and unloading.4 months agoHelpful?
1 - 10 of 673 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 673 Questions
Newest questions
Q: What is the height of the top of the hitch with the trailer level
8 days ago1 Answer
- A: The top of the hitch is 14".7 days agoHelpful?
Q: What is the bolt pattern for the wheels to purchase a spare wheel/tire?
12 days ago1 Answer
- A: The bolt pattern is 5 bolts on 4 1/2" centers.11 days agoHelpful?
Q: Can it accommodate a golf cart
20 days ago1 Answer
- A: The deck dimensions are 60" wide by 96" long. The maximum load capacity for the trailer is 1600 lbs. and the maximum load for the ramp gate is 800 lbs..19 days agoHelpful?
Q: Bolt pattern and dimensions
23 days ago1 Answer
- A: The Bolt pattern is 5 bolts on 4 1/2" centers.20 days agoHelpful?
Q: How many "D" tie downs are on the trailer?
27 days ago1 Answer
- A: There are (4) 1 1/2" x 1 1/2" x 1/8" angle tie downs.20 days agoHelpful?
Q: what is the bearing size for this trailer?
28 days ago1 Answer
- A: The bearing size is 1 1/16"28 days agoHelpful?
Q: What replacement axel do I buy?
2 months ago1 Answer
- A: Hi, to best assist you with this inquiry, please reach out to Tractor Supply Customer Solutions at 877-718-6750.2 months agoHelpful?
Q: Is the gate Ramp removable? And what type of wire harness pull will I need for the tail lights ?
2 months ago1 Answer
- A: You will need a 4 Way Flat wiring Harness.2 months agoHelpful?
Q: Are brake and turn signal lights installed
3 months ago1 Answer
- A: Yes the brake lights, the turn signal lights and the running lights are all installed on the trailer. The lighting meets all Department Of Transportation requirements.3 months agoHelpful?
Q: Will the mesh ramp hold strong enough and able to hold up when a 42" zero turn mower is loaded onto and off without bending the mesh ramp?
4 months ago1 Answer
- A: If your 42" zero turn mower's wheels do not line up with the trailer ramps structural cross members you will have the steel mesh stretching at some point in time. You can offset this issue with a piece of plywood to use when loading and unloading.4 months agoHelpful?
1 - 10 of 673 Questions
Similar Items
Items You May Like
Reviews
Summary of Reviews
The utility trailer is generally well-received for its lightweight yet sturdy construction, large tires, and convenient features like the fold-down ramp. Key strengths include easy maneuverability and suitability for transporting small equipment. However, some common criticisms include the flimsy me...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
4 out of 5 stars.
Great little trailer for the $
10 years ago
This will be my third summer using this little guy to haul my mowers around for my side business and it works perfect. HOWEVER, after about a year, I decided to haul my Harley from Pa. to Tenn and thought I'd check the wheel bearings first and to my surprise one side was bad. After a quick trip to TSC, I quickly replaced the both bearings and seal on the one side. As an after thought, I reported it to Carry-on who in turn had me contact the axle company. They were SUPER! They sent me a whole new set of heavier hubs and all new bearings free of charge. Great service. Needless to say, the trip was a success. Trailers at highway speeds like a dream.
98 people found this helpful
Show Reviews:
Most Helpful Critical Review
2 out of 5 stars.
DEFINATELY NOT LONG LASTING
9 years ago
I HAVE NOTICED THAT MOST ALL REVIEWS ARE BASED ON SHORT TERM OWNING. Allow me to provide long term use to this review. I have had this now going on 4yrs. I have had to replace the latches because welds had cracked that hold the gate up. I used barn door latches bought and attached them to the trailer by drilling 2 1/4" holes and using stainless bolts. By using barn latches, I can now use a lock on the latch to secure the lift gate. I cut 6" off the lift gate finding it was longer than what was needed for reasonable service. After doing so, I then put 90deg. aluminum angle iron on the end where I shortened the lift gate. I suspect that traveling at spds (70) the wind load on the lift gate added in the latches breaking.The bolt that secures the trailer beam to the trainer frequently loosens up. I sprayed the floor mesh with epoxy black and then placed 1/2" plywood down as a floor placing 1/4" bolts through the mesh and using fender washers top and bottom to secure the plywood. None of these changes were costly and greatly improved this trailer. The barn door type latches were the greatest improvement. It gave me the ability to place 2 small locks which resist the lowering of the lift gate when not attended. I may modify this review at a later date and provide a few photos. I base my recommendation on long lasting and long term use. Research all trailers before making your final decission.
63 people found this helpful
Show Reviews:
- purchase
- price
- satisfaction
- quality
- light
- weight
- size
- small
1 to 4 of 2431 Reviews .
1 – 4 of 2431 Reviews
Most Recent
Review 1
5 out of 5 stars.
Haul your tractor
a month ago
Noce and lightweighy
SweepstakesYes
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
a month ago
Carry-On Trailer Customer Service
We appreciate your great feedback and high rating. It is always rewarding to hear from a satisfied customer. Wishing you many successful miles ahead!
Saint johns
Review 1
5 out of 5 stars.
Utility trailer
a month ago
Great trailer. Great price
SweepstakesYes
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
a month ago
Carry-On Trailer Customer Service
Thank you for your fantastic review and high rating. We are thrilled to hear you are happy with your trailer.
Review 1
5 out of 5 stars.
Trailer
3 months ago
Just bought this 5x8 trailer and I'm very satisfied with my purchase
SweepstakesYes
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
3 months ago
Carry-On Trailer Customer Service
Your positive review means a lot to us. We work hard to provide quality trailer tires and it is great to know we met your expectations.
Review 1
3 out of 5 stars.
Good size
5 months ago
I have just purchased this trailer used. It is a good size for me and seems to be in good condition. However, when pulling it, I hear a noise that sounds like bearing noise, but after pulling about 12 miles at highway speeds, the bearings were not hot at all. I’m wondering if this is a normal noise for this trailer. Also, I see no grease fittings to be able to pump more grease into the bearings.
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
5 months ago
Carry-On Trailer Customer Service
Yes Sir the bearings would be hot if they were going out. I would not think the bearings are making the noise. If the axle is an EZ (easy lube) there would be a rubber plug in the dust cap. Pull the plug out and there would be a grease zerk behind it. The only normal trailer noise I am aware of would be the safety chains.
