Shop Fox W1666-2 HP Dust Collector

4.1

(15 Reviews)

|

Item # 229421499

$725.00
See Price at Checkout

Shop Fox W1666-2 HP Dust Collector

4.115 Reviews

Item # 229421499

Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
$725.00
See Price at Checkout

Neighbor's Club logo
Neighbor’s Club Members earn points with purchases.

Sign in or Join Now

Shop Fox W1666-2 HP Dust Collector

4.115 Reviews

Item # 229421499

Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
Image showing  W1666-2 HP Dust Collector
$725.00
See Price at Checkout

This item is available online only

Delivering to

37027


Neighbor's Club logo
Neighbor’s Club Members earn points with purchases.

Sign in or Join Now

A powerful dust collector from Shop Fox. This dust collector has air suction capacity of 1550 CFM and has a max static pressure of 12.3 inches. Static pressure is produced by the 12" balanced steel, radial fin impeller to move the wood chips into the collector. This unit features filters that capture chips and dust as small as 2.5 microns. Perfect for keeping your shop clean! The W1666 manual was written by our U.S. based Technical Documentation Department and is packed with useful information. The complete and easy-to-read manual provides full instructions on how to assemble and maintain your dust collector.The upper 2.5 mic bag (D4572) and lower plastic bags (D4573-5-pack) can be purchased separately for any collectors that do not include them.

  • Made in an ISO 9001 factory
  • Motor Size: 2 HP, 220V, single-phase,12A
  • Portable Base Size: 21-1/2" x 33-1/2"
  • Bag Volume: 5.4 Cubic Feet
  • Height (With bags inflated): 78"
  • Bag Size (Dia. x depth): 19" x 33" (2)
  • Impeller: 12" Balanced Steel, Radial Fin
  • Air Suction Capacity: 1550 CFM
  • Static Pressure: 12.3"
  • Standard Bag Filtration: 2.5-Micron
  • Approximately Shipping Weight: 107 lbs.
  • Has a 6" inlet with a removable "Y" fitting with two 4" openings

Similar Items

Items You May Like

Customers Also Bought

Reviews

Rating Snapshot

Select a row below to filter reviews.
9 reviews with 5 stars.
2 reviews with 4 stars.
2 reviews with 3 stars.
1 review with 2 stars.
1 review with 1 star.

Overall Rating

4.1
0 out of 1 (0%) reviewers recommend this product

Review this Product

Select to rate the item with 1 star. This action will open submission form.
Select to rate the item with 2 stars. This action will open submission form.
Select to rate the item with 3 stars. This action will open submission form.
Select to rate the item with 4 stars. This action will open submission form.
Select to rate the item with 5 stars. This action will open submission form.
Adding a review will require a valid email for verification
    • purchase
    • setup
    • instructions
    • quality
    • packaging
    • performance
    • returns
    • satisfaction
    1 to 4 of 15 Reviews
    1 – 4 of 15 Reviews
    Ma
    Review 1

    Less power

    2 years ago
    Power doesn't compare with the Grizzly dust collector of this size

    No, I do not recommend this product.

    Originally posted on grizzly.com

    Response from grizzly.com:
    2 years ago
    Customer Experience Team
    We noticed your comments were left blank when you posted the review. Your feedback is important to us, and we would like to learn more about what happened. We value your business and look forward to hearing from you soon.
    Review 1

    Specs'manual are not up to date

    4 years ago
    The unit works well, but it is packaged horribly for freight shipping. Like other reviewers, mine arrived with a large hole in the box, owing to the parts box being left in a wide open cavity without any padding. What you receive is a motor wired with a cord, but no plug (contrary to the spec sheet). The instructions call for several sizes of bolt, but the shipping contents and threading use only one size (I think it was an M8).

    Originally posted on grizzly.com

    Review 1

    Dust collector

    5 years ago
    This is a good dust collector. While the box was damaged during transit all was undamaged inside. It went together easily and the directions were clear. I was disappointed that the bottom bag was plastic. While it is convenient to see how full the bag is, the band that holds the bag in place isn't designed to hold it. All in all this machine works well and is quieter than my old one.

    Originally posted on grizzly.com

    Review 1

    Bad quality control. Not happy.

    6 years ago
    So first of all I was excited because the shipping box had no damage! Very surprised! But then I unbox everything and there are a ton of quality flaws. Dents, dings, sharp pieces sticking out and holes not lined up. The lower bag assembly is a joke. The only way I was able to get the bag on was to ducktape the bag to the machine then put the clamp on. The 6" to two 4" connector was so loose I had to duck tape it or else it wouldn't seal. There is no plug on the cord so I cant even see if it runs until I get that done. That was not in the description when I purchased this unit. The tube that came with it had a hole so more tape till I can replace that. I wasnt given enough bolts so I had to buy more to assemble it. The poles holding the bags up are flimsy and I will need to install a handle connected to the base if I want to move it around the shop. I am VERY disappointed with this unit. Everyone said to try shopfox because they are the best. I now beg to differ and am unhappy that I purchased this unit. That may change when I can actually power it up. If it does, I'll update this. BUT if I dont. You'll know how that went too.

    Originally posted on grizzly.com
