We've taken our ever popular and highly regarded G0514 and made another Extreme Machine. Cast-iron wheels, double-row ball-bearing blade guides, and a 3 HP motor help make this a wood devouring saw. Also, the extra-large tilting table and Grizzly patent-pending Re-saw Fence make controlling the cut easy. You'll really appreciate the extra features like two 4 in. dust ports, a tracking window, quick-release blade tension device, and blade tension scale. Both blade guide height and blade tension are handwheel controlled, and the wheel covers are hinged for convenience.

For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.

Looking for more information on tools? Check out our guide on essential woodworking power tools in the product documents section.

Motor: 3 HP, 220-Volt, single-phase, TEFC capacitor start induction, 60 Hz, 12 Amp, 1725 RPM
Table size: 26-3/4 in. x 19 in. x 1-1/2 in. thick
Floor to table height: 37-1/2 in.
Cutting capacity/throat: 18-1/4 in.
Maximum cutting height: 12 in.
Blade size: 143 in. L

Brand	Grizzly
Country of Origin	Imported
Amperage	0 N/A
Blade Change Type	Keyless
Cord Length	6 ft.
Cut Through	Wood
Dust Collection Method	4 in. dust port
Features	Dust Collection
Horsepower	3 HP
Housing Material	Steel
Maximum Blade Length	143 in.
Maximum Blade Width	1.25 in.
Maximum Cutting Width	18.25 in.
Maximum Speed	3500 FMP
Minimum Blade Length	141.5 in.
Minimum Blade Width	0.125 in.
Minimum Speed	1700 FMP
Number of Speeds	2
Portable or Stationary	Stationary
Power Type	Electric
Product Height	76 in.
Product Length	32 in.
Product Weight	383 lb.
Product Width	36 in.
Rectangle Length Capacity	18.25 in.
Rectangle Width Capacity	18.25 in.
Round Capacity	18.25 in.
Table Height From Floor	37.5 in.
Table Length	26.75 in.
Table Tilt Range	5 deg. left, 45 deg.right
Table Width	19 in.
Variable Speed	Variable Speed
Voltage	220 V
Warranty	1
