Fimco 60 gal. 3-Point Hitch Mounted Sprayer with 7 Boomless Boom, Deluxe Handgun, LG-60-3PT-WP-309-BL-TSC

SKU: 215225199
Fimco 60 gal. 3-Point Hitch Mounted Sprayer with 7 Boomless Boom, Deluxe Handgun, LG-60-3PT-WP-309-BL-TSC
Enter Zip Code for price More Info
Product price

Online Only Price
Save Up To
See price at checkout More Info
Product Rating is 4.2


TSC of sedalia #1469
3901 west broadway blvd
sedalia, MO 65301
(660) 827-0600
TSC of sedalia #1469
3901 west broadway blvd
sedalia, MO 65301
(660) 827-0600
Check Availability at Other Stores
Standard Delivery Not Available to
This item will ship within 0 days.
Change Delivery Location

Item Information

60 Gallon 3-Point Hitch Sprayer With Boomless Boom.

  • 6 Roller Pump & Coupler Included
  • Pistol Grip Handgun With Adjustable Pattern Spray Tip Sprays Up To 45' Horizontal & 30' Vertical
  • EPDM Chemical Resistant 25 Feet Of 3/8" Hose
  • 3-Nozzle Boomless Boom Delivers 30' Of Spray Coverage
  • Mounts On Category 1 - 3 Point Hitch - Easily Adaptable To Category 2

Specification Description
CountryofOrigin: Made in USA
Maximum Flow Rate: N/A
Product Length: 44 in.
Connection Type: Bolt
Swath: 30 ft.
Hose Length: 25 ft.
Voltage: N/A
Product Width: 40 in.
Product Height: 39 in.
Boom Material: Steel
Hose Diameter: 3/8 in.
Number of Nozzles: 3
Special Feature(s): None
Maximum Operating Pressure: N/A
Additional Item(s) Included: None
Maximum Horizontal Throw: 45 ft.
Application/Use: Spraying
Boom Width: 3 ft.
Product Weight: 82 lb.
Tank Material: Polyethylene
Part Number: LG-60-3PT-WP-309-BL-TSC
Tank Capacity: 60 gal.
Brand: Fimco
Maximum Vertical Throw: 30 ft.
Recommended Chemicals: N/A
Manufacturer Part Number LG-60-3PT-WP-309-BL-TSC
Fimco 60 gal. 3-Point Hitch Mounted Sprayer with 7 Boomless Boom, Deluxe Handgun, LG-60-3PT-WP-309-BL-TSC is rated 4.1 out of 5 by 31.
Rated 5 out of 5 by from Great Sprayer for the Money We got this sprayer to upgrade from our 25 gallon ATV sprayer, this sprayer with the PTO pump does a much better job for us spraying Tempo and 24D and Fertilizers. Easy to put on and take off.
Date published: 2019-07-28
Rated 4 out of 5 by from Pretty happy with purchase Manual leaves a lot to be desired but it's not too hard to figure out. One nozzle valve was cracked and the center nozzle is leaking at the body. Took all the fittings apart and wrapped threads with tape before use and didn't have any other fitting leaks when we turned it on for the first time. Seems solid and sprays very well, we are getting the 30' coverage from the 3 nozzles and the handgun has good pressure and volume.
Date published: 2019-07-06
Rated 5 out of 5 by from Great Little Sprayer This sprayer did a really nice job. The boom less design did a nice job putting out a even spray. Water rate chart was quite accurate.
Date published: 2019-06-12
Rated 5 out of 5 by from Exactly What I had hoped for. I bought this early this year, to spray liquid fertilizer, pre-emergent weed killer, and post emergent selective herbicides on my 4 acre yard. I did not want one with an electric pump, as my John Deere 3320 has a cab. This product makes taking care of my yard a breeze. The boomless model will cover a large swath with each pass. It has a pressure valve to help control flow of material, each nozzle can be shut off for directional spraying, and the hand held sprayer has a long hose. To address a couple of issue mentioned, I can reach the shut off handle through my rear glass when opened, but on a larger tractor I guess that could be an issue. Since the pump is driven by the rear PTO, I start and stop the flow of material by simply turning off/on the PTO... problem solved. The only time I use the shut off handle, is when I am mixing the chemical with water. When the shut off valve is off, and the PTO is engaged, the pump recirculates the water/material into the tank, providing an excellent mixing process. The only issue some might have, is the pump is cast iron, and is not approved for round-up. You can buy a stainless Steele pump that would solve that issue for you, but if they put that pump on all these sprayers, it would significantly increase the price per unit. I personally don’t use a non-specific herbicide in the same equipment I spray my yard with, so for me that has not been an issue. As far as replacement parts for the nozzles, etc., TS May not keep them in stock, but our local Farmers Co Op has a ton of them, as apparently the different brands of sprayers use the same supplier for these parts. Take the broken part with you to a Co Op amd I bet you can find the part. They are much more reasonably priced than trying to buy the part online.
Date published: 2019-06-01
  • y_2019, m_8, d_5, h_16
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_4, tr_27
  • loc_en_US, sid_215225199, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 6ms

Can this be used to spray liquid with the same viscosity as diesel fuel?

Asked by: Treywood
Yes. From a viscosity standpoint, it will work. Just keep in mind that rate and performance tables are based on water and actual performance will vary.
Answered by: Fimco Industries
Date published: 2019-05-10

Can you spray Calcium Chloride through this sprayer?

Asked by: Shreklives
The standard cast iron roller pump will not handle the calcium chloride solution. You will need t purchase a Silver Series pump to handle calcium chloride.
Answered by: Fimco Industries
Date published: 2019-01-20

Could you direct me to replacement nozzles and a plug so I can stop off 1 side of mine?

Asked by: DeerGrower
Shut of caps are available to replace the tips and caps on each nozzle. You can special order through you local TSC store. item number is 5046186. Order one for each nozzle you want to turn off.
Answered by: Fimco Industries
Date published: 2019-05-03

The pump is not able to use Round Up, but can it be used with other weed killers? Also is there a PTO pump that can be bought to use round up?

Asked by: Olivia7326
Hypro's Silver Series pumps are made from an alloy that is resistant to Roundup. For your sprayer, use model 6500XL.
Answered by: Fimco Industries
Date published: 2018-06-12

Are items 5301805/2152243 and 5301806/2152251 the same units except spray mechanism - boom and boomless? 05 has a coverage of 140" - correct? 06 has coverage of 30' - correct? Are either of these adjustable to a shorter span?

Asked by: Dobb
They are the same sprayer except for the spray mechanism. The 5301806 has 3 nozzles that can be turned on and off individually, to spray left, right or center or any combination.
Answered by: Fimco Industries
Date published: 2018-08-16

Are there valves to allow spraying on one side only?

Asked by: Larry77
Answered by: DanielB
Date published: 2017-07-07

what is the distance the boomless sprayer will cover

Asked by: rebb
The boom-less model covers up to 30'.
Answered by: DanielB
Date published: 2019-06-17

On the Fimco 7 Boomless sprayer--What is the total width that it will cover when spraying ?

Asked by: Ben Stoltzfus
The boom covers a 140 inch swath.
Answered by: DanielB
Date published: 2019-06-17
