Delavan PowerFLO 5800 Series Diaphragm Pump, 5850-201C-SB

Enter Zip Code for price More Info

Sale Save Up To

See price at checkout

Financing Available Learn More

Protect your purchase with Power Plus

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it.

Learn More

The Delavan 5850-201C-SB 5800 Series Diaphragm Pump is a universal replacement for 12V sprayer pumps. The most powerful diaphragm pumps on the market, engineered with a high torque motor to provide superior flow at pressure. The Delavan 5-Chamber 5.0 GPM Pump is ideal for use as a weed sprayer pump or fluid transfer pump.

  • 100% factory tested for quality and safety assurance
  • Self-priming to 10 ft. for a better reach
  • Can be run dry without worry of damage
  • 1/2" FNPT ports to fit your equipment
  • This 12V sprayer pump has a maximum pressure of 45 PSI and 5.0 GPM for your spraying needs
  • 2-Year manufacturer warranty
  • This weed sprayer pump is engineered with a high torque motor to provide superior flow at pressure
  • Dimensions: 9.4" L x 5" W x 4.7" H

Additional Product Information
The quantity requested exceeds available inventory.
Store:  Change Store
Please lower quantity or check availability at nearby stores
Check availability at nearby stores
Call Store for availability or check availability at nearby stores

Curbside / Pickup In Store

  Change Store Item is currently not available for Pickup at this store. Check availability at nearby stores

Standard Delivery

Item is not eligible for Standard Delivery.

Standard Delivery

Item is currently not available for Standard Delivery. Check other delivery options.
Curbside / Pickup and Delivery Information Click here for more details...
Add to list

Product Details

The Delavan 5850-201C-SB 5800 Series Diaphragm Pump is a universal replacement for 12V sprayer pumps. The most powerful diaphragm pumps on the market, engineered with a high torque motor to provide superior flow at pressure. The Delavan 5-Chamber 5.0 GPM Pump is ideal for use as a weed sprayer pump or fluid transfer pump.

  • 100% factory tested for quality and safety assurance
  • Self-priming to 10 ft. for a better reach
  • Can be run dry without worry of damage
  • 1/2" FNPT ports to fit your equipment
  • This 12V sprayer pump has a maximum pressure of 45 PSI and 5.0 GPM for your spraying needs
  • 2-Year manufacturer warranty
  • This weed sprayer pump is engineered with a high torque motor to provide superior flow at pressure
  • Dimensions: 9.4" L x 5" W x 4.7" H

Specifications

Specification Description
Hose Diameter N/A
Valve Inlet Type 1/2 in. FNPT
Housing Material Polypropylene
Special Feature(s) None
Motor Type 12VDC
Country of Origin Made in USA
Power Type 12 Volt
Package Quantity 1
Material Polypropylene
Compatibility 1/2" FNPT port
Engine Displacement N/A
Inlet Diameter 1/2 in. FNPT
Product Weight 6.0 lb.
Outlet Diameter 1/2 in. FNPT
Product Length 9.4 in.
Discharge Port 1/2 in. FNPT
Maximum Operating Pressure 45 PSI
Product Width 5 in.
Product Height 4.7 in.
Power Cord Length 12 in.
Valve Outlet Diameter 1/2 in. FNPT
Application/Use Sprayer Pump
Warranty 2 Years
Maximum Flow Rate 5.0 GPM
Compatible Pipe Material All
Valve Inlet Diameter 1/2 in. FNPT
Voltage 12VDC
Operating Temperature Range 140*F MAX
Suction Port 1/2 in. FNPT
Valve Outlet Type 1/2 in. FNPT
Brand Delavan
Type Pump
Engine Brand N/A
Part Number 5850-201C-SB
Minimum Operating Pressure 0 PSI
Manufacturer Part Number 5850-201C-SB

Reviews

Delavan PowerFLO 5800 Series Diaphragm Pump, 5850-201C-SB is rated 4.4 out of 5 by 11.
Rated 4 out of 5 by from Might Need upgraded harness - Fuse I bought mine for a water supply when I burn brush. It worked great the first two times I used it, then stopped working when needed the third time. I had already returned it when I realized the problem might have been the wiring harness fuse's amp and not the pump. The 12V County Line harness TSC sells comes with a 7amp fuse - this pump recommends a 20amp to support motor startup spike.
Date published: 2020-06-11
Rated 4 out of 5 by from Works great Works excellent for Boom sprayer. Very easy to operate and spray with.
Date published: 2019-04-09
Rated 5 out of 5 by from Excellent Pump I bought this pump a couple of weeks ago to transfer oil and it has been working extremely well I usually run it at least two to three hours at a time and it doesn’t get hot or give up best little pump out there.
Date published: 2019-04-04
Rated 5 out of 5 by from Pump review This pump works great, easy to install. This pump started first try, no priming needed.
Date published: 2019-03-18
  • y_2020, m_9, d_24, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_3, tr_8
  • loc_en_US, sid_211038099, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 2ms
  • REVIEWS, PRODUCT

Questions & Answers

Will this pump shut its self off when not spraying or does it run continuous?

Asked by: Big Dummy
Yes this product will automatically shut off at 45 psi.
Answered by: CodyP
Date published: 2018-08-13

will the 5800 series replace the 5950-201c on a county line 25 gal sprayer

Asked by: ernie22
This could work as a replacement. However, the 5950 has quick attachments and the 5850 does not. With the 5850 some additional parts would be needed to be a correct replacement.
Answered by: AmandaW
Date published: 2018-06-19

will this pump delver the same volumn as a 6 roller pto pump?

Asked by: cmmh53
No, this will under perform a 6 roller pto pump.
Answered by: DanielB
Date published: 2017-03-21

Will this pump fit a workhorse 25 gallon sprayer

Asked by: dmcmanus
We recommend SKU 2110372 for this sprayer.
Answered by: JasmineH
Date published: 2018-05-22
