Carry-On Trailer 1,000 lb. Capacity Bolt-On Jack
$70.99
Carry-On Trailer 1,000 lb. Capacity Bolt-On Jack
Carry-On Trailer 1,000 lb. Capacity Bolt-On Jack
Item # 116167199
$70.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
$70.99
Shopping at
Grassland (franklin) TN
Delivery to
Pickup Nearby at TRIUNE TN(16.3) miles Free
Pickup Later at Franklin TN
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Carry-On Trailer 1,000 lb. Capacity Bolt-On Jack is made to help you get back on track any time. Featuring the bolt-on hardware you'll need for installation, this jack is ideal for mounting to trailer frames from 2 x 2 to 3 x 5. Keep this bolt-on jack in your workshop or garage so your trailer is always ready for the long haul.
Looking for more information on truck accessories? Check out our guide on truck accessories in the product documents section.
- 1,000 lb. lift and support capacity
- Large, grooved handle for comfortable jack operation
- Durable clear zinc finish with 2-1/8 outer tube construction
- 6 poly caster wheel for smooth maneuverability
- 24 bolt-on jack height when fully retracted
- Large 1/2 pull pin for easy swivel mechanism activation
- Bolt-through design with a large washer for improved side load support
- Bolt-on hardware included for mounting to trailer frames from 2 x 2 to 3 x 5
- 10 travel distance for versatile height adjustment
- Marine jack is ideal for use with boat, sport craft, snowmobile or other recreational trailers
| Brand | Carry-On Trailer |
|---|---|
| Country of Origin | Imported |
| Base Type | 6 poly caster wheel |
| Compatibility | Marine jack is ideal for use with boat, sport craft, snowmobile or other recreational trailers |
| Crank Type | Side Wind |
| Extended Height | 24 in. |
| Features | Zinc finish |
| Handle Length | 6 in. |
| Hoist Lift Height | 10 in |
| Hoist Weight Capacity | 1000 lb |
| Lift Capacity | 1,000 lb. |
| Mechanism Type | Mechanical |
| Mounting Type | Bolt-On |
| Power Type | None |
| Primary Material | Zinc |
| Product Height | 12 in. |
| Product Length | 12 in. |
| Product Weight | 12 lb. |
| Product Width | 2 in. |
| Retracted Height | 14 in. |
| Jack Style | Swivel |
| Tube Width | 3 in. |
| Manufacturer Part Number | 980T |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 32 Questions
Newest questions
Q: Instruction manual?
5 months ago2 Answers
- A: The manual is available on the product webpage under Product Documents. If you click on the 980T, you’ll see Product Documents listed just below the image of the jack. Click there to access the PDF manual with installation instructions.5 months agoHelpful?
Q: What bolts are recommended for bolt on?
2 years ago1 Answer
- A: grade 8 bolts2 years agoHelpful?
Q: Are replacement wheels available??
2 years ago1 Answer
- A: Hi, Replacement parts and accessories can be ordered directly from Carry-On Trailers. Using the information below. *****CARRY-ON TRAILERS***** Phone: (706) 356-5379 Fax: (706) 356-4431 E-mail: customer.service@carry-ontrailer.com Website: www.carry-ontrailer.com2 years agoHelpful?
Q: what is the shortest distance from trailer tongue to bottom of wheel ?
2 years ago1 Answer
- A: It is 13-1/2" if you have any more questions, you can email us at cs@cotrlr.com or contact us at 706-356-5379 ext. 19152 years agoHelpful?
Q: what is the distance between center of mounting plate to bottom of jack
2 years ago1 Answer
- A: Hello! I will send you a picture to your email so you can view it with the dimensions. Thank you!2 years agoHelpful?
Q: what is the lift range?
2 years ago1 Answer
- A: LIFT RANGE IS 10"2 years agoHelpful?
Q: What size frame will this fit ? How much room does it require at the top of the frame …. I have 4” between propane cover and bens in frame ?
3 years ago1 Answer
- A: Hey Ala2716, Thank you for your great questions! To make sure you get the most accurate answer, please reach out to Carry-on at Phone: (706) 356-5379 Fax: (706) 356-44313 years agoHelpful?
Q: does it come with the back bracket and bolts to secure it on the frame?
4 years ago1 Answer
- A: Hi Smul, Yes it does.3 years agoHelpful?
Q: Does this jack swing up when not in use?
4 years ago1 Answer
- A: For additional product support, please contact Carry-On at (706) 356-5379.4 years agoHelpful?
Q: What is the distance between the bottom of the mounting plate and the bottom of the wheel when fully retracted?
4 years ago1 Answer
- A: For additional product support, please contact (706) 356-5379.4 years agoHelpful?
1 - 10 of 32 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 32 Questions
Newest questions
Q: Instruction manual?
5 months ago2 Answers
- A: The manual is available on the product webpage under Product Documents. If you click on the 980T, you’ll see Product Documents listed just below the image of the jack. Click there to access the PDF manual with installation instructions.5 months agoHelpful?
Q: What bolts are recommended for bolt on?
2 years ago1 Answer
- A: grade 8 bolts2 years agoHelpful?
Q: Are replacement wheels available??
2 years ago1 Answer
- A: Hi, Replacement parts and accessories can be ordered directly from Carry-On Trailers. Using the information below. *****CARRY-ON TRAILERS***** Phone: (706) 356-5379 Fax: (706) 356-4431 E-mail: customer.service@carry-ontrailer.com Website: www.carry-ontrailer.com2 years agoHelpful?
Q: what is the shortest distance from trailer tongue to bottom of wheel ?
2 years ago1 Answer
- A: It is 13-1/2" if you have any more questions, you can email us at cs@cotrlr.com or contact us at 706-356-5379 ext. 19152 years agoHelpful?
Q: what is the distance between center of mounting plate to bottom of jack
2 years ago1 Answer
- A: Hello! I will send you a picture to your email so you can view it with the dimensions. Thank you!2 years agoHelpful?
Q: what is the lift range?
2 years ago1 Answer
- A: LIFT RANGE IS 10"2 years agoHelpful?
Q: What size frame will this fit ? How much room does it require at the top of the frame …. I have 4” between propane cover and bens in frame ?
3 years ago1 Answer
- A: Hey Ala2716, Thank you for your great questions! To make sure you get the most accurate answer, please reach out to Carry-on at Phone: (706) 356-5379 Fax: (706) 356-44313 years agoHelpful?
Q: does it come with the back bracket and bolts to secure it on the frame?
4 years ago1 Answer
- A: Hi Smul, Yes it does.3 years agoHelpful?
Q: Does this jack swing up when not in use?
4 years ago1 Answer
- A: For additional product support, please contact Carry-On at (706) 356-5379.4 years agoHelpful?
Q: What is the distance between the bottom of the mounting plate and the bottom of the wheel when fully retracted?
4 years ago1 Answer
- A: For additional product support, please contact (706) 356-5379.4 years agoHelpful?
1 - 10 of 32 Questions
Similar Items
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
-
-
-
-
-
Items You May Like
-
-
Top Rated
-
-
-
-
-
Top Rated
-
-
-
Top Rated
-
-
Top Rated
Customers Also Bought
-
-
Top Rated
-
-
-
Top Rated
-
-
-
Top Rated
-
-
-
-
Top Rated
Reviews
Summary of Reviews
This trailer jack is generally well-received, with customers praising its solid construction, easy installation, and ability to make moving and positioning trailers more convenient. Many describe the ...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
4 out of 5 stars.
Worthwhile
15 years ago
While similar to many other simple tongue jacks, this one has one feature not found on most others -a grease fitting to lube the gears. This may seem minor, but others I have seen (and used) have a hole, or slot, or something like that, and it allows sand/water/dirt/etc into it. This one seals it, but still allows for lubing.
As far as installation, couldn't be much simpler: Pick your spot, and clamp on.
I plan on getting another one for one of my other trailers soon.
33 people found this helpful
Show Reviews:
Most Helpful Critical Review
1 out of 5 stars.
Not usable with a cargo trailer
5 years ago
I bought this wheeled jack 3 weeks ago and noticed that the "clamp" system was weak at best. After readjusting multiple times I decided to try and swing the trailer tail around and the jack collapsed with little effort almost taking toes off of two of us.
7 people found this helpful
Show Reviews:
Customer Images and Videos
- installation
- purchase
- price
- quality
- satisfaction
- sturdy
- weight
- functional
1 to 4 of 156 Reviews .
1 – 4 of 156 Reviews
Most Recent
Reviews 2
5 out of 5 stars.
Trailer jack
18 days ago
Igreat trailer jack
Response from Carry-On Trailer Customer Service:
16 days ago
Carry-On Trailer Customer Service
Your positive review means a lot to us. We work hard to provide quality trailer parts and accessories and it is great to know we met your expectations.
Review 1
5 out of 5 stars.
2 months ago
Fit perfect on our Power King tow behind wood chipper.
Reviews 2
2 out of 5 stars.
Trailer jack Failure
5 months ago
It didn't seem to fit the 5 x 8 trailer that Tractor Suppy sod me. It buckled first try. Readjusted and it kinda worked.
SweepstakesYes
No, I do not recommend this product.
Response from Carry-On Trailer Customer Service:
5 months ago
Carry-On Trailer Customer Service
We are sorry to hear that your experience did not meet expectations. Your feedback is important, and we would appreciate the opportunity to make things right. Please reach out to cs@carry-ontrailer.com..
Review 1
1 out of 5 stars.
Weak Product
6 months ago
It is very weak, you should be able to unhitch trailer from truck with golf cart on it but jack bends and so I'd never let anyone on it while using this jack.
