Marathon Motors 6 HP 230V Electric Air Compressor Motor, 3,450 RPM
$709.99
Marathon Motors 6 HP 230V Electric Air Compressor Motor, 3,450 RPM
Marathon Motors 6 HP 230V Electric Air Compressor Motor, 3,450 RPM
Item # 324100399
$709.99
or
or
Neighbor’s Club Members earn points with purchases.
Marathon Motors 6 HP 230V Electric Air Compressor Motor, 3,450 RPM
Item # 324100399
$709.99
or
or
$60/mo.† suggested payments with 12 Months Financing or earn $35 in Rewards+ on this purchase.
Out of stock at
Grassland (franklin) TN
Delivery to
Pickup Nearby at ASHLAND CITY TN(23) miles FREE
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
The Marathon Motors 6 HP Electric Air Compressor Motor is made to get the job done right. This air compressor motor can be used for commercial and residential air compressors, fans, dairy and poultry equipment and table saws. The capacitor start/capacitor run design of the air compressor motor reduces the amperage needed. The electric air compressor motor has manual reset thermal protection and a rigid base. Made in the USA, this compressor motor features carbon steel construction for durability and strength.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Backed by a 1-year limited warranty
- Power of air compressor motor: 6 HP
- Speed of air compressor motor: 3,450 RPM
- 230V
- Fl amps: 23
- 56Hz frame size
- Shaft size: 7/8 in.
- Drip-proof electric air compressor motor
- Applications of the air compressor motor include: Commercial and residential air compressors, fans, dairy and poultry equipment and table saws
- Manual reset thermal protection
- Ball bearings
- Heavy-duty start/run capacitors
- Bi-directional rotation
| Brand | Marathon Motors |
|---|---|
| Country of Origin | Made in USA |
| Amperage | 23A |
| Compatibility | NONE |
| Hertz | 60 Hz |
| Horsepower | 6 HP |
| Maximum RPM | 3,450 RPM |
| Minimum RPM | 3,450 rpm |
| Frame Type | 56Hz |
| Phase | Single |
| Primary Material | Carbon Steel |
| Product Height | 9.34 HEIGTH |
| Product Length | 10.58 LENGTH |
| Product Weight | 54 lb. |
| Product Width | 8.75 WIDTH |
| Shank Diameter | 9/14 in. x 1-6/7 in. |
| Stage Type | N/A |
| Voltage | 230V |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | GEX36531 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 9 of 9 Questions
Newest questions
Q: My compressor has a Ingersoll Rand motor model # 47669474001 . Will this motor work as a replacement
3 years ago1 Answer
- A: This motor has a 5/8 shaft on a 56 frame. If the Ingersoll Rand motor has the same specs, this could replace it. We recommend reaching out to the manufacturer for additional assistance: 715-675-33113 years agoHelpful?
Q: I am looking for a wiring diagram for this motor.
3 years ago1 Answer
- A: For technical support, please contact 888.4GEXPRO.3 years agoHelpful?
Q: What size key way does this motor need on the shaft?
3 years ago1 Answer
- A: 1/2 or .5 height per the manual.3 years agoHelpful?
Q: Why is this electric motor slow
4 years ago1 Answer
- A: For technical support, please contact 888.4GEXPRO.4 years agoHelpful?
Q: How do I wire this motor
Anonymous4 years ago1 Answer
- A: Please check your email for necessary documents.4 years agoHelpful?
Q: Can u control speed on this motor ? Can u put a speed control switch on it.
4 years ago1 Answer
- A: No, the speed can not be controlled. For additional product support, please contact Sales@Marathon-Motors.com.4 years agoHelpful?
Q: The wires are all white only three are marked with colored collars red blue and black there’s no kind of marking on the other 3 white wires except the voltage no t-1 or p-1 on any of the wires wut wire needs to go where
6 years ago1 Answer
- A: Please contact Motor Customer Service at 715-675-3311.6 years agoHelpful?
Q: Will this replace the motor on a Ingersoll Rand 80 (sku# 349612999)
8 years ago1 Answer
- A: This motor has a 5/8 shaft on a 56 frame. If the Ingersoll Rand motor has the same specs, this could replace it.8 years agoHelpful?
Q: what size braker in the electric box do you use
9 years ago1 Answer
- A: The GEX36531 6 hp motor has full load amps of 23 Amps. A lot has to do with how far from panel is the wire being run to the outlet. 12 gauge wire is good for 20 amps. This motor pulls 23 amps, so best bet is to use 10 gauge wire with a 2 pole 30 amp breaker. 10 gauge wire with a 2 pole 30 amp breaker will give you plenty of room for inrush current on start up.9 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 9 of 9 Questions
Newest questions
Q: My compressor has a Ingersoll Rand motor model # 47669474001 . Will this motor work as a replacement
3 years ago1 Answer
- A: This motor has a 5/8 shaft on a 56 frame. If the Ingersoll Rand motor has the same specs, this could replace it. We recommend reaching out to the manufacturer for additional assistance: 715-675-33113 years agoHelpful?
Q: I am looking for a wiring diagram for this motor.
3 years ago1 Answer
- A: For technical support, please contact 888.4GEXPRO.3 years agoHelpful?
Q: What size key way does this motor need on the shaft?
3 years ago1 Answer
- A: 1/2 or .5 height per the manual.3 years agoHelpful?
Q: Why is this electric motor slow
4 years ago1 Answer
- A: For technical support, please contact 888.4GEXPRO.4 years agoHelpful?
Q: How do I wire this motor
Anonymous4 years ago1 Answer
- A: Please check your email for necessary documents.4 years agoHelpful?
Q: Can u control speed on this motor ? Can u put a speed control switch on it.
4 years ago1 Answer
- A: No, the speed can not be controlled. For additional product support, please contact Sales@Marathon-Motors.com.4 years agoHelpful?
Q: The wires are all white only three are marked with colored collars red blue and black there’s no kind of marking on the other 3 white wires except the voltage no t-1 or p-1 on any of the wires wut wire needs to go where
6 years ago1 Answer
- A: Please contact Motor Customer Service at 715-675-3311.6 years agoHelpful?
Q: Will this replace the motor on a Ingersoll Rand 80 (sku# 349612999)
8 years ago1 Answer
- A: This motor has a 5/8 shaft on a 56 frame. If the Ingersoll Rand motor has the same specs, this could replace it.8 years agoHelpful?
Q: what size braker in the electric box do you use
9 years ago1 Answer
- A: The GEX36531 6 hp motor has full load amps of 23 Amps. A lot has to do with how far from panel is the wire being run to the outlet. 12 gauge wire is good for 20 amps. This motor pulls 23 amps, so best bet is to use 10 gauge wire with a 2 pole 30 amp breaker. 10 gauge wire with a 2 pole 30 amp breaker will give you plenty of room for inrush current on start up.9 years agoHelpful?
