Marathon Motors 2 HP 115/230V Electric Air Compressor Motor, 3,600 RPM
Limited Time Deal
Marathon Motors 2 HP 115/230V Electric Air Compressor Motor, 3,600 RPM
Item # 324117699
$349.99
Sale
Was$479.99
Save $130.00
or
or
Neighbor’s Club Members earn points with purchases.
Limited Time Deal
Marathon Motors 2 HP 115/230V Electric Air Compressor Motor, 3,600 RPM
Item # 324117699
$349.99
Sale
Was$479.99
Save $130.00
or
or
$59/mo.† suggested payments with 6 Months Financing or earn $17 in Rewards+ on this purchase.
Out of stock at
Grassland (franklin) TN
Delivery to
Pickup Nearby at FRANKLIN TN(6.7) miles FREE
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
The Marathon Motors 2 HP Electric Air Compressor Motor is made to get the job done right. This air compressor motor can be used for commercial and residential air compressors, fans, dairy and poultry equipment and table saws. The capacitor start/capacitor run design of the air compressor motor reduces the amperage needed. The electric air compressor motor has manual reset thermal protection and a rigid base. Made with carbon steel, this compressor motor is designed for durability and strength.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Power: 2 HP
- Speed: 3,600 RPM
- Backed by a 1-year limited warranty
- 115/230V
- Fl amps: 17/8.5
- 56 frame
- Shaft size: 5/8 in.
- Drip-proof electric air compressor motor
- Rigid base air compressor motor
- Ball bearings
- Manual reset thermal protection
- Capacitor start/capacitor run design for reduced amperage
- Single phase footed air compressor motor
- Single direction (clockwise rotation only)
- Applications of the air compressor motor include: Commercial and residential air compressors, fans, dairy and poultry equipment and table saws
- General-purpose air compressor motor
| Brand | Marathon Motors |
|---|---|
| Country of Origin | Imported |
| Amperage | 17/8.5A |
| Compatibility | NONE |
| Hertz | 60 Hz |
| Horsepower | 2 HP |
| Maximum RPM | 3,600 RPM |
| Minimum RPM | 3,450 rpm |
| Frame Type | 56 |
| Phase | Single |
| Primary Material | Carbon Steel |
| Product Height | 8.4 HEIGTH |
| Product Length | 12.76 LENGTH |
| Product Weight | 51 lb. |
| Product Width | 6.54 WIDTH |
| Shank Diameter | 9/14 in. x 1-6/7 in. |
| Stage Type | N/A |
| Voltage | 115V/230V |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | GEX09035 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 6 of 6 Questions
Newest questions
Q: what are the spec's on the starting and run capacitors?
2 years ago1 Answer
- A: Please view the manual at the following link: https://media.tractorsupply.com/is/content/TractorSupplyCompany/tsc/product/3/24/11/76/3241176_Man1.pdf Or you can contact the manufacturer at Phone: (715) 675-3311 or online at www.marathonelectric.com2 years agoHelpful?
Q: My compressor calls for a large frame motor, is this?
5 years ago1 Answer
- A: We cannot say for sure what is needed for your compressor, please Contact Motor Customer Service at: Phone: (715) 675-3311 www.marathonelectric.com5 years agoHelpful?
Q: How many watts does it use?
7 years ago1 Answer
- A: 2000 watts or 2 kW7 years agoHelpful?
Q: is this a 3 phase?
7 years ago1 Answer
- A: No, it is a 1 phase.7 years agoHelpful?
Q: Motor description states CW (clockwise) rotation. Viewed from which direction? I have seen motor rotation direction referenced looking from eirther direction, shaft end or back end...
8 years ago1 Answer
- A: Rotation is measured from rear of motor over to shaft.8 years agoHelpful?
Q: Will this motor work for a Porter Cable Single Stage Oillube Compressor model CPLC7060V-1
8 years ago1 Answer
- A: The GEX09035 should work fine on the Porter Cable compressor as long as it is same spec motor on compressor as the Marathon GEX9035 replacement. We do not have any specs on a Porter Cable part number.8 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 6 of 6 Questions
Newest questions
Q: what are the spec's on the starting and run capacitors?
2 years ago1 Answer
- A: Please view the manual at the following link: https://media.tractorsupply.com/is/content/TractorSupplyCompany/tsc/product/3/24/11/76/3241176_Man1.pdf Or you can contact the manufacturer at Phone: (715) 675-3311 or online at www.marathonelectric.com2 years agoHelpful?
Q: My compressor calls for a large frame motor, is this?
5 years ago1 Answer
- A: We cannot say for sure what is needed for your compressor, please Contact Motor Customer Service at: Phone: (715) 675-3311 www.marathonelectric.com5 years agoHelpful?
Q: How many watts does it use?
7 years ago1 Answer
- A: 2000 watts or 2 kW7 years agoHelpful?
Q: is this a 3 phase?
7 years ago1 Answer
- A: No, it is a 1 phase.7 years agoHelpful?
Q: Motor description states CW (clockwise) rotation. Viewed from which direction? I have seen motor rotation direction referenced looking from eirther direction, shaft end or back end...
8 years ago1 Answer
- A: Rotation is measured from rear of motor over to shaft.8 years agoHelpful?
Q: Will this motor work for a Porter Cable Single Stage Oillube Compressor model CPLC7060V-1
8 years ago1 Answer
- A: The GEX09035 should work fine on the Porter Cable compressor as long as it is same spec motor on compressor as the Marathon GEX9035 replacement. We do not have any specs on a Porter Cable part number.8 years agoHelpful?
