DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit
$379.99
DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit
DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit
Item # 3194002
Stocked & Ready
$379.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit
Item # 3194002
Stocked & Ready
$379.99
or
or
$64/mo.† suggested payments with 6 Months Financing or earn $18 in Rewards+ on this purchase.
Shopping at
Grassland (franklin) TN
Delivery to
Pickup Nearby at FRANKLIN TN(6.7) miles Free
Ship to store at Grassland (franklin) TN
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The DuraVent DuraPlus 6 in. Triple Wall Pipe Through-the-Roof Stove Chimney Kit is designed to stay cool on the outside and to provide a hot draft on the inside. This easy-to-use kit boosts stove efficiency, and provides for a fire-safe design that protects both the chimney and the building. Our all-in-one chimney kit has everything you need except the necessary lengths of a chimney pipe and connector pipe to save time and guesswork. This high-quality kit includes DVL and DuraBlack chimney adapter, snap-lock adapter with trim, 23 in. square ceiling support box with trim, adjustable flashing 0/12-6/12 pitch (larger pitch sizes are available and sold separately), chimney cap, storm collar and ceiling support box insulation collar.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- DuraVent Through-the-Roof Stove Chimney Kit is designed to stay cool on the outside and provides a hot draft on the inside
- Easy-to-use chimney kit boosts stove efficiency, and provides for a fire-safe design that protects both the chimney and the building
- High-quality kit includes DVL and DuraBlack chimney adapter, snap-lock adapter with trim, 23 in. square ceiling support box with trim, adjustable flashing 0/12-6/12 pitch, chimney cap, storm collar and a ceiling support box insulation collar
| Brand | DuraVent |
|---|---|
| Country of Origin | Made in USA |
| Burner System | N/A |
| Cabinet or Housing Material | Stainless steel |
| Coverage Area | 0 N/A |
| Features | 0N/A |
| Finish | Stainless-steel |
| Fuel Flow Rate | 0 N/A |
| Fuel Type | None |
| Heater Control | None |
| Heating Unit Type | N/A |
| Ignition Type | None |
| Indoor/Outdoor | Indoor and Outdoor |
| Intended Use Grade | Standard |
| Maximum BTU Heat Output | N/A |
| Mounting Location | Other |
| Number Of Heat Settings | N/A |
| Primary Material | Stainless Steel |
| Product Height | 37 in. |
| Product Length | 18 in. |
| Product Weight | 31.8 lb. |
| Product Width | 24 in. |
| Run Time | 0N/A |
| Manufacturer Part Number | 6DP-KTUP |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 102 Questions
Newest questions
Q: Is this approved for venting a natural gas boiler? Also is it approved to replace a brick chimney that’s been removed to the roof line?
2 months ago1 Answer
- A: Howdy neighbor! While this DuraPlus triple-wall kit is UL-listed for all-fuel residential appliances, its safety depends entirely on your specific setup, so you must consult a licensed HVAC professional and review your boiler's manual to ensure it is approved for your equipment's specific efficiency category and local building codes. If compatible, the kit can safely vent an approved boiler and replace a removed chimney section provided you construct a proper code-compliant support frame and maintain the required 2-inch clearance to all combustible materials.2 months agoHelpful?
Q: Does the kit come with pipe to run from stove, or is that purchased separately?
5 months ago1 Answer
- A: No, according to the product page, this high-quality kit includes DVL and DuraBlack chimney adapter, snap-lock adapter with trim, 23 in. square ceiling support box with trim, adjustable flashing 0/12-6/12 pitch (larger pitch sizes are available and sold separately), chimney cap, storm collar, and ceiling support box insulation collar.5 months agoHelpful?
Q: Does this work for DuraVent 6" double wall pipe
6 months ago1 Answer
- A: Hello, thank you for your question. It is designed for triple‑wall pipe only and will not directly connect to 6″ double‑wall stove pipe.6 months agoHelpful?
Q: What is the measurement of the ceiling box
6 months ago1 Answer
- A: For the DuraVent DuraPlus 6 in. Chimney Kit (6DP-KTUP), the ceiling support box included is typically 23 inches tall, which is significantly larger than the standard 11-inch version. Measurements for 6DP-KTUP: Height: 23 inches. Width & Depth: Approximately 14.25 inches to 14.5 inches square. Support Capacity: Rated to support up to 35 feet of DuraPlus chimney pipe.6 months agoHelpful?
Q: Many reviews state this requires 8" triple wall pipe instead of 6". Please clarify.
6 months ago1 Answer
- A: The confusion regarding the DuraVent DuraPlus 6 in. Chimney Kit typically stems from the difference between the Inner Diameter (ID) and the Outer Diameter (OD) of triple-wall pipe. The kit requires 6-inch pipe: All DuraPlus components are categorized by their Inner Diameter. If your stove has a 6-inch flue, you must use the 6-inch DuraPlus kit and 6-inch DuraPlus pipe.6 months agoHelpful?
Q: Is the 23 inch dimension of the box a height?
7 months ago1 Answer
- A: Hello, thank you for your question. Yes, that is the height of the box.7 months agoHelpful?
Q: Is there a kit for an 10/12 roof pitch?
8 months ago1 Answer
- A: There is no specific all-in-one kit for a 10/12 roof pitch for the DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit. The standard kits typically include flashing for a lower pitch range of 0/12 to 6/12. However, you can purchase the appropriate roof flashing for a 10/12 pitch separately and combine it with the rest of the kit's components.8 months agoHelpful?
Q: Does the kit include the fresh air intake?
8 months ago1 Answer
- A: No, the DuraVent Stove Chimney Kit does not include a fresh air intake. The kit is designed to vent exhaust gases through the roof and includes only the necessary components for that purpose.8 months agoHelpful?
Q: Can you attach the triple wall DuraVent to the inside of roof bracket
8 months ago1 Answer
- A: No, you do not attach the DuraVent DuraPlus 6 in. Triple Wall Pipe to the inside of the roof bracket. The roof bracket is designed to support and stabilize the chimney pipe from the outside, not to attach to the interior. The pipe is installed first, and the bracket is then secured to the exterior of the pipe.8 months agoHelpful?
Q: Can i use this on a flat roof?
9 months ago1 Answer
- A: Yes, you can use the DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit on a flat roof, provided you use specific components designed for flat roof installation.9 months agoHelpful?
1 - 10 of 102 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 102 Questions
Newest questions
Q: Is this approved for venting a natural gas boiler? Also is it approved to replace a brick chimney that’s been removed to the roof line?
2 months ago1 Answer
- A: Howdy neighbor! While this DuraPlus triple-wall kit is UL-listed for all-fuel residential appliances, its safety depends entirely on your specific setup, so you must consult a licensed HVAC professional and review your boiler's manual to ensure it is approved for your equipment's specific efficiency category and local building codes. If compatible, the kit can safely vent an approved boiler and replace a removed chimney section provided you construct a proper code-compliant support frame and maintain the required 2-inch clearance to all combustible materials.2 months agoHelpful?
Q: Does the kit come with pipe to run from stove, or is that purchased separately?
5 months ago1 Answer
- A: No, according to the product page, this high-quality kit includes DVL and DuraBlack chimney adapter, snap-lock adapter with trim, 23 in. square ceiling support box with trim, adjustable flashing 0/12-6/12 pitch (larger pitch sizes are available and sold separately), chimney cap, storm collar, and ceiling support box insulation collar.5 months agoHelpful?
Q: Does this work for DuraVent 6" double wall pipe
6 months ago1 Answer
- A: Hello, thank you for your question. It is designed for triple‑wall pipe only and will not directly connect to 6″ double‑wall stove pipe.6 months agoHelpful?
Q: What is the measurement of the ceiling box
6 months ago1 Answer
- A: For the DuraVent DuraPlus 6 in. Chimney Kit (6DP-KTUP), the ceiling support box included is typically 23 inches tall, which is significantly larger than the standard 11-inch version. Measurements for 6DP-KTUP: Height: 23 inches. Width & Depth: Approximately 14.25 inches to 14.5 inches square. Support Capacity: Rated to support up to 35 feet of DuraPlus chimney pipe.6 months agoHelpful?
Q: Many reviews state this requires 8" triple wall pipe instead of 6". Please clarify.
6 months ago1 Answer
- A: The confusion regarding the DuraVent DuraPlus 6 in. Chimney Kit typically stems from the difference between the Inner Diameter (ID) and the Outer Diameter (OD) of triple-wall pipe. The kit requires 6-inch pipe: All DuraPlus components are categorized by their Inner Diameter. If your stove has a 6-inch flue, you must use the 6-inch DuraPlus kit and 6-inch DuraPlus pipe.6 months agoHelpful?
Q: Is the 23 inch dimension of the box a height?
7 months ago1 Answer
- A: Hello, thank you for your question. Yes, that is the height of the box.7 months agoHelpful?
Q: Is there a kit for an 10/12 roof pitch?
8 months ago1 Answer
- A: There is no specific all-in-one kit for a 10/12 roof pitch for the DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit. The standard kits typically include flashing for a lower pitch range of 0/12 to 6/12. However, you can purchase the appropriate roof flashing for a 10/12 pitch separately and combine it with the rest of the kit's components.8 months agoHelpful?
Q: Does the kit include the fresh air intake?
8 months ago1 Answer
- A: No, the DuraVent Stove Chimney Kit does not include a fresh air intake. The kit is designed to vent exhaust gases through the roof and includes only the necessary components for that purpose.8 months agoHelpful?
Q: Can you attach the triple wall DuraVent to the inside of roof bracket
8 months ago1 Answer
- A: No, you do not attach the DuraVent DuraPlus 6 in. Triple Wall Pipe to the inside of the roof bracket. The roof bracket is designed to support and stabilize the chimney pipe from the outside, not to attach to the interior. The pipe is installed first, and the bracket is then secured to the exterior of the pipe.8 months agoHelpful?
Q: Can i use this on a flat roof?
9 months ago1 Answer
- A: Yes, you can use the DuraVent DuraPlus 6 in. Triple Wall Pipe Thru-the-Roof Stove Chimney Kit on a flat roof, provided you use specific components designed for flat roof installation.9 months agoHelpful?
1 - 10 of 102 Questions
Similar Items
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
-
-
-
-
Top Rated
-
Reviews
- purchase
- installation
- price
- satisfaction
- instructions
- wood
- quality
- fit
1 to 4 of 338 Reviews .
1 – 4 of 338 Reviews
Most Recent
Review 1
5 out of 5 stars.
The final pieces
3 months ago
It is so good to know our stove is installed correctly with quality parts!
SweepstakesYes
Pulaski virginia
Review 1
1 out of 5 stars.
Misleading, horrible description
a year ago
You have to have 10” outside diameter triple wall pipe to use this kit. They should state this in the description. Also it doesn’t come with a pitched roof flashing it came with a flat roof flashing piece.
No, I do not recommend this product.
sierra foothills California
Reviews 3
5 out of 5 stars.
All in one
a year ago
Comes with all misc pieces to complete chimney installation, except nails and ceiling framing. The most difficult task was securing the ceiling support box to the framing as this needed to be done from the top of the support box some 2 feet deep and, in my case as the roof was less than 1 foot from the top of the box, from the roof itself at the extreme limit of my reach.
SweepstakesYes
Maple Falls, WA
Review 1
2 out of 5 stars.
Flashing misleading
a year ago
The pictures shows flashing to accommodate a pitched roof but the flashing included is for a flat roof. Who has a flat roof??
No, I do not recommend this product.
