CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder, 1.25 in. Rod Diameter, 2,500 PSI
$399.99
CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder, 1.25 in. Rod Diameter, 2,500 PSI
Exclusive
CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder, 1.25 in. Rod Diameter, 2,500 PSI
Item # 126563399
Stocked & Ready
$399.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
Exclusive
CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder, 1.25 in. Rod Diameter, 2,500 PSI
Item # 126563399
Stocked & Ready
$399.99
or
or
$34/mo.† suggested payments with 12 Months Financing or earn $19 in Rewards+ on this purchase.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder is designed for rugged agricultural applications, making the hydraulic cylinder well suited to perform in demanding applications in any industry. This tie rod hydraulic cylinder provides value pricing without sacrificing quality.
- Hydraulic cylinder has a 2,500 PSI operating range
- 3 in. bore x 12 in. stroke
- Used for agricultural applications
- Tie rod hydraulic cylinder exceeds industry standards
- 1.25 in. rod diameter
| Brand | CountyLine |
|---|---|
| Country of Origin | Imported |
| Bore Diameter | 3 in. |
| Brand Compatibility | Universal |
| Compatibility | Unknown |
| Extended Length | 34.25 in. |
| Maximum Operating Pressure | 2,500 PSI |
| Maximum Weight Capacity | 17,670 lb. |
| Model Compatibility | Universal |
| Package Quantity | 1 |
| Pin Diameter | 1 in. |
| Port Size | 12 NPT |
| Primary Material | Steel |
| Product Height | 0 N/A |
| Product Length | 22.25 in. |
| Product Weight | 32 lb. |
| Product Width | 0 N/A |
| Retracted Length | 22.25 in. |
| Rod Diameter | 1.25 in. |
| Stroke Distance | 12 in. |
| Manufacturer Part Number | 318337 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 11 Questions
Newest questions
Q: Are parts available for 1265633? Need base end Clevis.
6 months ago1 Answer
- A: No parts available.5 months agoHelpful?
Q: Is this cylinder dual acting ?
6 months ago1 Answer
- A: Yes, this is a double acting cylinder.6 months agoHelpful?
Q: Can I buy a seal kit for CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder, 1.25 in. Rod Diameter, 2,500 PSI 4.7 57 Reviews Item # 126563399
a year ago1 Answer
- A: Seal kit - Bailey #204503 - $18.95 each - In stock.a year agoHelpful?
Q: What is the clevis size?
2 years ago1 Answer
- A: Please check you email for requested information.2 years agoHelpful?
Q: Are these cylinders phasing/rephrasing cylinders?
3 years ago1 Answer
- A: This is a standard tie-rod. Not a rephasing type.3 years agoHelpful?
Q: How do you know what size hydraulic cylinder you need for your bush hog. I need one for the center of my John Deere cutter
3 years ago1 Answer
- A: Refer to John Deere for that information.3 years agoHelpful?
Q: does the cyclinder come with the pins
3 years ago1 Answer
- A: Yes. This cylinder does come with the pins.3 years agoHelpful?
Q: What is Clevis pin size for ends of ram
3 years ago1 Answer
- A: Both ends have 1" pins.3 years agoHelpful?
Q: How do you plumb it for 1 way action for a batwing bushhog
4 years ago1 Answer
- A: Vendor suggestions are if you unsure about how to plumb the cylinder, find a local hydraulic shop that could help.4 years agoHelpful?
Q: Does it use o ring or pipe thread fittings
4 years ago1 Answer
- A: - Uses ½” NPT (pipe thread) fittings4 years agoHelpful?
1 - 10 of 11 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 11 Questions
Newest questions
Q: Are parts available for 1265633? Need base end Clevis.
6 months ago1 Answer
- A: No parts available.5 months agoHelpful?
Q: Is this cylinder dual acting ?
6 months ago1 Answer
- A: Yes, this is a double acting cylinder.6 months agoHelpful?
Q: Can I buy a seal kit for CountyLine 3 in. Bore x 12 in. Stroke Tie Rod Hydraulic Cylinder, 1.25 in. Rod Diameter, 2,500 PSI 4.7 57 Reviews Item # 126563399
a year ago1 Answer
- A: Seal kit - Bailey #204503 - $18.95 each - In stock.a year agoHelpful?
Q: What is the clevis size?
2 years ago1 Answer
- A: Please check you email for requested information.2 years agoHelpful?
Q: Are these cylinders phasing/rephrasing cylinders?
3 years ago1 Answer
- A: This is a standard tie-rod. Not a rephasing type.3 years agoHelpful?
Q: How do you know what size hydraulic cylinder you need for your bush hog. I need one for the center of my John Deere cutter
3 years ago1 Answer
- A: Refer to John Deere for that information.3 years agoHelpful?
Q: does the cyclinder come with the pins
3 years ago1 Answer
- A: Yes. This cylinder does come with the pins.3 years agoHelpful?
Q: What is Clevis pin size for ends of ram
3 years ago1 Answer
- A: Both ends have 1" pins.3 years agoHelpful?
Q: How do you plumb it for 1 way action for a batwing bushhog
4 years ago1 Answer
- A: Vendor suggestions are if you unsure about how to plumb the cylinder, find a local hydraulic shop that could help.4 years agoHelpful?
Q: Does it use o ring or pipe thread fittings
4 years ago1 Answer
- A: - Uses ½” NPT (pipe thread) fittings4 years agoHelpful?
1 - 10 of 11 Questions
Similar Items
Items You May Like
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
Reviews
- purchase
- quality
1 to 4 of 58 Reviews .
1 – 4 of 58 Reviews
Most Recent
Review 1
5 out of 5 stars.
Great quality
6 months ago
Excellent product, great quality
SweepstakesYes
Yes, I recommend this product.
Review 1
5 out of 5 stars.
Great product, sub-par assistance
a year ago
The product is excellent. I use it for heavy duty tree work on my 50 horse power tractor. However, I must say the sales associates at every location I've visited in central Florida know absolutely nothing about tractors and hydraulics. I encourage the company to train their employees about tractors. Its in the company name and, at this point, i find it a bit deceiving.
SweepstakesYes
Yes, I recommend this product.
SE Tennessee
Review 1
5 out of 5 stars.
Good looking quality.
2 years ago
Exactly what I needed to replace an older blown out cylinder. Fit perfect and work great.
SweepstakesYes
Yes, I recommend this product.
Wisconsin
Reviews 6
5 out of 5 stars.
Hydraulic ram
2 years ago
Very good quality
Yes, I recommend this product.
