CountyLine 15 gal. 2 Nozzle ATV Sprayer
CountyLine 15 gal. 2 Nozzle ATV Sprayer
Item # 233603699
$299.99
or
or
Get everything you need
Neighbor’s Club Members earn points with purchases.
$299.99
or
or
$50/mo.† suggested payments with 6 Months Financing or earn $14 in Rewards+ on this purchase.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The CountyLine 15 gal. 2-Nozzle ATV Sprayer makes it easy to maintain your landscaping. Great for lawns, ball fields, parks, acreages and small pastures, this spot sprayer makes it easy to apply pest control, weed killer, fertilizer, water and more. The sprayer is made with a blow-molded polymer tank, complete with UV stabilizers, and has a lever-grip spray wand for ease of use. TeeJet tips deliver 7 ft. of total spray coverage, while the FloodJet tips offer less wind drift and no drip check valves. The spot sprayer uses a 1.2 GPM pump and a 15 ft. hose for ample reach and power. Satisfaction guaranteed.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on sprayers? Check out our guide on agricultural and lawn sprayers in the product documents section.
- Ideal spot sprayer for lawns, ball fields, parks, acreages and small pastures
- Designed for weed control, pest control, fungus control, fertilizing, watering and other similar applications
- 15 gal. size blow-molded polymer tank with a 5 in. tethered tank lid for easy-access refills
- Tank has UV stabilizers for durability and a convenient molded drain port
- Lever-grip spray wand complete with an aluminum lance and an adjustable polymer nozzle
- 2-nozzle, rigid steel boom design with 7 ft. of coverage
- TeeJet tips deliver 7 ft. of total spray coverage; FloodJet tips offer less wind drift and no drip check valves
- 1.2 GPM 12V internally fan-cooled pump with a max pressure of 60 PSI
- Made with chemical-resistant valves and diaphragms to ensure lasting quality
- 15 ft. x 3/8 in. hose can reach tight areas, around buildings and other obstacles
- Fuse-protected 8 ft. lead wire
- Garden hose threaded 'Y' manifold
| Brand | CountyLine |
|---|---|
| Country of Origin | Made in USA |
| Boom Maximum Spray Width | 7 ft |
| Boom Nozzle Count | 2 |
| Boom Style | Fixed Boom |
| Chemical Compatibility | Herbicide, Pesticide, Weed Killer, Fertilizer, Repellent, Insecticide, Fungicide |
| Features | 2 nozzle boom with Lever Grip Spray Wand |
| Hose Diameter | 0.38 in. |
| Hose Length | 15 ft. |
| Maximum Flow Rate | 1.25 GPM |
| Maximum Operating Pressure | 60 PSI |
| Mounting Type | Straps |
| Power Type | 12 Volt |
| Product Height | 16 in. |
| Product Length | 42 in. |
| Product Weight | 26 lb. |
| Product Width | 23 in. |
| Pump Type | Diaphragm |
| Boom Width | 3.5 ft |
| Tank Capacity | 15 gal. |
| Spray Method | Spot Spraying |
| Tank Material | Polyethylene |
| Warranty | 1 Year Sprayer; 2 Year Pump |
| Manufacturer Part Number | 5303011 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 13 Questions
Newest questions
Q: Can I put this on the back of my ford ranger instead of a tractor or quad and still operate it
7 months ago2 Answers
- A: This sprayer is designed for the back of an ATV. The sprayer has an approximate weight of 160 lbs. when totally full.7 months agoHelpful?
Q: Can you share photo of being attached tp ATV?
9 months ago1 Answer
- A: I do not have a picture of this sprayer on an ATV. Basically you would set it on your rack or back end and strap it down using some tie down straps. Then the sprayer pump would connect to your ATV battery with the lead wire that is included with the sprayer.9 months agoHelpful?
Q: What size hose does this come with? I need to replace my leaky y valve and im not at home to measure it.
a year ago1 Answer
- A: For parts contact Fimco at 800-831-0027.a year agoHelpful?
Q: are other size nozzles available
a year ago1 Answer
- A: you would probably have to change out the pump to a larger pump to accommodate different tips. then also, depending on the type of tips you might change to, you may have to also change the caps, as the caps will only hold certain tips that it's designed for.a year agoHelpful?
Q: Are the nozzles on the boom interchangeable?
a year ago1 Answer
- A: Ryan, yes they are interchangeable. They're the exact same tip.a year agoHelpful?
Q: OK with Roundup?
a year ago1 Answer
- A: This spot sprayer makes it easy to apply pest control, weed killer, fertilizer, water and morea year agoHelpful?
Q: How How hard is it to mount on a Gator bed
a year ago1 Answer
- A: This is an ATV sprayer. If the customer wants to set in the back of a UTV, he'll have to make sure to strap it down securely to keep it from sliding. If the tailgate is removeable, that would be best, as to not put so much weight of a filled sprayer on a tailgate. He would need to check his UTV manual as to weight restrictions. We're not ATV or UTV experts and wouldn't be able to give him an answer on the weight vs the vehicle, that would need to be determined from their vehicle manual.a year agoHelpful?
Q: Do I need a battery for the motor?
a year ago1 Answer
- A: As with any 12V pump, it needs to be connected to a 12-volt battery. They can either connect to their ATV/UTV battery or they can use a stand-alone battery.a year agoHelpful?
Q: Need a replacement hose section from pump to the splitter. 3 month old sprayer and it's already cracked all over the hose.
a year ago1 Answer
- A: For parts contact Fimco at 800-831-0027.a year agoHelpful?
Q: Can you adjust the spray width on the boom?
a year ago1 Answer
- A: No, you can’t adjust the spray width on the boom. This boom will give approximately an 80” spray swath. However, if you install 3/8” two-way ball valves in line on each side, you could shut one side off and cut the spraying swath to approximately half, by spraying with only one nozzle.a year agoHelpful?
1 - 10 of 13 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 13 Questions
Newest questions
Q: Can I put this on the back of my ford ranger instead of a tractor or quad and still operate it
7 months ago2 Answers
- A: This sprayer is designed for the back of an ATV. The sprayer has an approximate weight of 160 lbs. when totally full.7 months agoHelpful?
Q: Can you share photo of being attached tp ATV?
9 months ago1 Answer
- A: I do not have a picture of this sprayer on an ATV. Basically you would set it on your rack or back end and strap it down using some tie down straps. Then the sprayer pump would connect to your ATV battery with the lead wire that is included with the sprayer.9 months agoHelpful?
Q: What size hose does this come with? I need to replace my leaky y valve and im not at home to measure it.
a year ago1 Answer
- A: For parts contact Fimco at 800-831-0027.a year agoHelpful?
Q: are other size nozzles available
a year ago1 Answer
- A: you would probably have to change out the pump to a larger pump to accommodate different tips. then also, depending on the type of tips you might change to, you may have to also change the caps, as the caps will only hold certain tips that it's designed for.a year agoHelpful?
Q: Are the nozzles on the boom interchangeable?
a year ago1 Answer
- A: Ryan, yes they are interchangeable. They're the exact same tip.a year agoHelpful?
Q: OK with Roundup?
a year ago1 Answer
- A: This spot sprayer makes it easy to apply pest control, weed killer, fertilizer, water and morea year agoHelpful?
Q: How How hard is it to mount on a Gator bed
a year ago1 Answer
- A: This is an ATV sprayer. If the customer wants to set in the back of a UTV, he'll have to make sure to strap it down securely to keep it from sliding. If the tailgate is removeable, that would be best, as to not put so much weight of a filled sprayer on a tailgate. He would need to check his UTV manual as to weight restrictions. We're not ATV or UTV experts and wouldn't be able to give him an answer on the weight vs the vehicle, that would need to be determined from their vehicle manual.a year agoHelpful?
Q: Do I need a battery for the motor?
a year ago1 Answer
- A: As with any 12V pump, it needs to be connected to a 12-volt battery. They can either connect to their ATV/UTV battery or they can use a stand-alone battery.a year agoHelpful?
Q: Need a replacement hose section from pump to the splitter. 3 month old sprayer and it's already cracked all over the hose.
a year ago1 Answer
- A: For parts contact Fimco at 800-831-0027.a year agoHelpful?
Q: Can you adjust the spray width on the boom?
a year ago1 Answer
- A: No, you can’t adjust the spray width on the boom. This boom will give approximately an 80” spray swath. However, if you install 3/8” two-way ball valves in line on each side, you could shut one side off and cut the spraying swath to approximately half, by spraying with only one nozzle.a year agoHelpful?
1 - 10 of 13 Questions
Similar Items
-
-
-
-
Top Rated
-
-
-
-
-
-
-
-
Items You May Like
-
-
-
-
-
Top Rated
-
-
-
-
-
-
-
Customers Also Bought
-
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
Top Rated
-
-
-
-
Top Rated
-
Reviews
- purchase
- quality
- price
- durability
- instructions
- material
- product features
- setup
1 to 4 of 80 Reviews .
1 – 4 of 80 Reviews
Most Recent
Review 1
3 out of 5 stars.
quality
a month ago
I like the way it works but I am having trouble with the connections leaking under pressure. This started after my 3rd 15 gal. usage.
Review 1
1 out of 5 stars.
disappointed
8 months ago
handle cracked and leaks everywhere. For the price the materials should be a little more durable.
Response from Fimco Industries:
8 months ago
Fimco Industries
Sorry, you had that issue. Please contact our customer service team at 800-831-0027 and they'll be happy to assist you with a replacement wand.
Weiser, Idaho
Review 1
1 out of 5 stars.
Bad pump
a year ago
Pump went out within 20 days of purchase. only got to use it 3 times on less than 2 acres and now its garbage.
No, I do not recommend this product.
Review 1
1 out of 5 stars.
Poor quality
a year ago
Do not buy. The pump is cheap and loses prime easily. I pulled it off to use with another tank for hand spraying. I used it 3 times and ordered another pump thinking it would fix the problem. Same issue. It is a disappointing product.
No, I do not recommend this product.
Response from Fimco Industries:
a year ago
Fimco Industries
Sorry you had this issue with this sprayer. Please contact our customer service team at 800-831-0027 to troubleshoot the issue. The fact that the pump was replaced and still having the same issue, it's a possibility it may be something else.
