Chief 2.5 in. Bore x 30 in. Stroke WT Welded Cylinder, 1.5 in. Rod Diameter

Shop all Chief

Item # 130744399

$269.99

Neighbor’s Club Members earn points with purchases.

Shop all Chief

Chief 2.5 in. Bore x 30 in. Stroke WT Welded Cylinder, 1.5 in. Rod Diameter

Item # 130744399

$269.99

$45/mo.^† suggested payments with 6 Months Financing or earn $13 in Rewards⁺ on this purchase.

This item is available online only

Delivery to

Free standard delivery on online footwear & Clothing purchases of $49 and over.

Neighbor’s Club Members earn points with purchases.

The Chief 2.5 in. Bore x 30 in. Stroke WT Welded Cylinder is a high-quality welded hydraulic cylinder designed for heavier loads. The rod and base ends of the hydraulic cylinder are welded cross-tubes with grease zerks. Designed for performance, it has a heavy-duty piston as well as a piston stem complete with wear rings to reduce friction.

For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.

Welded hydraulic cylinder is intended to be used in double-acting applications
Piston: ductile iron with wear ring(s)
Gland: ductile iron, screw-in design with wear ring
Tube: precision-honed steel
Rod: ground and polished chromed steel, minimum 75,000 PSI yield
Butt plate: steel
End mounts: steel cross-tubes with grease zerk
Spacer tube: steel on 48 in. stroke and above
Gland seal: polyurethane U-cup
Wiper: polyurethane
Piston seal: 755 Hallite with wear ring(s)
All other seals on the hydraulic cylinder are selected and designed for maximum life
Measures 38 in. retracted and 68 in. extended
Pin diameter of 1 in. and rod diameter of 1.5 in.
Column load: 11,690 lb.

Brand	Chief
Country of Origin	Imported
Bore Diameter	2.5 in.
Brand Compatibility	Universal
Compatibility	Most applications
Extended Length	30 in.
Hydraulic Cylinder Type	Welded
Maximum Operating Pressure	3,000 PSI
Maximum Weight Capacity	14,720 lb.
Model Compatibility	Most applications
Package Quantity	1
Pin Diameter	0-3/4 in.
Port Size	SAE 8
Primary Material	Steel
Product Height	0 N/A
Product Length	0 N/A
Product Weight	38.58 lb.
Product Width	0 N/A
Retracted Length	38 in.
Rod Diameter	1-1/2 in.
Single/Double Acting	Double acting
Stroke Distance	30 in.
Warranty	3 Year
Manufacturer Part Number	212697

Q&As

1 - 1 of 1 Question

Q: in the description this says it has a 1 1/2 inch shaft with a pin diameter of 1 inch but in the specifications it says the shaft in 1 3/8 inch and the pin is 3/4 inch. Can you please tell me correct dimensions for this cylinder and cylinder #130766599

3 years ago

1 Answer

A: 212697 is Bore 2.5 in Stroke 30 in PSI 3000 Retracted 38 in Pin Diameter 1 in Rod Diameter 1.5 in Extended 68 in Column Load 11690 lbs Port Size SAE 8 287239 is Bore 2.5 in Stroke 32 in PSI 3000 Retracted 40 in Pin Diameter .75 in Rod Diameter 1.375 in Extended 72 in Column Load 7460 lbs Port Size SAE 8
3 years ago
