Carry-On Trailer 1,250 lb. 5-Bolt Trailer Wheel Hub Assembly
$69.99
Carry-On Trailer 1,250 lb. 5-Bolt Trailer Wheel Hub Assembly
Carry-On Trailer 1,250 lb. 5-Bolt Trailer Wheel Hub Assembly
Item # 190279
Stocked & Ready
$69.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
Carry-On Trailer 1,250 lb. 5-Bolt Trailer Wheel Hub Assembly
Item # 190279
Stocked & Ready
$69.99
New Cardmembers earn a $20 Reward‡ with qualifying purchase of $20 or more plus earn 5% in Rewards+ on this purchase. Valid through 8/9/26.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Carry-On Trailer Hub Assembly is the right part when you want to get back to work quickly. This hub assembly includes 1-1/16 in. bearings, a hub, lug nuts, cotter pin for castle nut, and a small dust cap. The 5-bolt hub assembly has a maximum weight capacity of 1,250 lb. The outer bearing size of the hub assembly is 1-1/16 in.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Includes One 5-Lug Hub, Five 1/2" Lug Nuts, One Dust Cap; Hub Contains Two 1/16" Bearings
- Five Lug Studs On 4-1/2" Pattern
- Weight capacity of the 5-bolt hub assembly: 1,250 lb.
- Fits 1-1/16" Spindles
| Brand | Carry-On Trailer |
|---|---|
| Country of Origin | Imported |
| Compatibility | Trailers |
| Maximum Weight Capacity | 1,250 lb. |
| Mounting Type | Bolt-On |
| Package Quantity | 1 |
| Primary Material | Steel |
| Product Height | 8.5 in. |
| Product Length | 11 in. |
| Product Weight | 6.95 lb. |
| Product Width | 16 in. |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | 155T |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 44 Questions
Newest questions
Q: Will this fit a 1" straight spindle?
a month ago1 Answer
- A: This trailer hub fits a 1 1/16" straight spindle.a month agoHelpful?
Q: Will this fit 1inch spindle
2 months ago1 Answer
- A: No it will not. It will fit a 1 1/16" spindle.2 months agoHelpful?
Q: Will this fit carryon 5x8 trailers
5 months ago1 Answer
- A: This wheel hub fits a 2,000 lb axle with a 1 1/16" spindle. The bolt pattern is 5 bolts on 4 1/2" centers. Yes it will fit a Carry-On 5x8 trailer with a 2,000 lb. GVWR.5 months agoHelpful?
Q: Are these hubs able to handle larger tires ex. 33in tire with 15 inch rim 5x4.5 pattern?
a year ago2 Answers
- A: Yes the 15" rim with a bolt pattern of 5 bolts on 4 1/2" centers are compatible.a year agoHelpful?
Q: What size is the dust cap bore, is it 1.98”?
a year ago1 Answer
- A: Hello, thank you for your question. Yes, the dust cap in this package is 1.988".a year agoHelpful?
Q: What is the center hole size?
a year ago2 Answers
- A: 3 1/8" dia.a year agoHelpful?
Q: Will this work for boat trailers in that go into lake water not salt water
a year ago2 Answers
- A: This trailer does not have sealed hubs (Marine Grade). If the hubs get under water you should repack the bearings.a year agoHelpful?
Q: Does this kit come with a grease seal installed in rear of hub
2 years ago1 Answer
- A: Hi, Yes, the axle manufacturer installs the bearings, races, rear seal and Lithium complex automotive bearing grease. Carry-On Trailer Customer Service2 years agoHelpful?
Q: Will this fit a 7x12’ utility trailer- single axle
2 years ago1 Answer
- A: No hub for 1250 lbs is for the 2,000 lb axle. The 7x12utility trailer needs the 545T hub rated at 1750 lbs.. for the 3500 lb axle.2 years agoHelpful?
Q: This is a 5 bolt. What is the official measurement between bolts? 4.5 inches? This is a very important piece of information that is missing. Are the bearings installed and loaded with grease? What grease - you should not miss greases'.
2 years ago1 Answer
- A: Measure from the center of one bolt, skip a bolt and measure to the outside of the third bolt. This will be 4 1/2". The axle manufacturer installs the bearings, races, rear seal and Lithium complex automotive bearing grease,2 years agoHelpful?
1 - 10 of 44 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 44 Questions
Newest questions
Q: Will this fit a 1" straight spindle?
a month ago1 Answer
- A: This trailer hub fits a 1 1/16" straight spindle.a month agoHelpful?
Q: Will this fit 1inch spindle
2 months ago1 Answer
- A: No it will not. It will fit a 1 1/16" spindle.2 months agoHelpful?
Q: Will this fit carryon 5x8 trailers
5 months ago1 Answer
- A: This wheel hub fits a 2,000 lb axle with a 1 1/16" spindle. The bolt pattern is 5 bolts on 4 1/2" centers. Yes it will fit a Carry-On 5x8 trailer with a 2,000 lb. GVWR.5 months agoHelpful?
Q: Are these hubs able to handle larger tires ex. 33in tire with 15 inch rim 5x4.5 pattern?
a year ago2 Answers
- A: Yes the 15" rim with a bolt pattern of 5 bolts on 4 1/2" centers are compatible.a year agoHelpful?
Q: What size is the dust cap bore, is it 1.98”?
a year ago1 Answer
- A: Hello, thank you for your question. Yes, the dust cap in this package is 1.988".a year agoHelpful?
Q: What is the center hole size?
a year ago2 Answers
- A: 3 1/8" dia.a year agoHelpful?
Q: Will this work for boat trailers in that go into lake water not salt water
a year ago2 Answers
- A: This trailer does not have sealed hubs (Marine Grade). If the hubs get under water you should repack the bearings.a year agoHelpful?
Q: Does this kit come with a grease seal installed in rear of hub
2 years ago1 Answer
- A: Hi, Yes, the axle manufacturer installs the bearings, races, rear seal and Lithium complex automotive bearing grease. Carry-On Trailer Customer Service2 years agoHelpful?
Q: Will this fit a 7x12’ utility trailer- single axle
2 years ago1 Answer
- A: No hub for 1250 lbs is for the 2,000 lb axle. The 7x12utility trailer needs the 545T hub rated at 1750 lbs.. for the 3500 lb axle.2 years agoHelpful?
Q: This is a 5 bolt. What is the official measurement between bolts? 4.5 inches? This is a very important piece of information that is missing. Are the bearings installed and loaded with grease? What grease - you should not miss greases'.
2 years ago1 Answer
- A: Measure from the center of one bolt, skip a bolt and measure to the outside of the third bolt. This will be 4 1/2". The axle manufacturer installs the bearings, races, rear seal and Lithium complex automotive bearing grease,2 years agoHelpful?
1 - 10 of 44 Questions
Similar Items
-
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
-
-
Items You May Like
Reviews
Summary of Reviews
The trailer hubs were generally well-received, with customers reporting they were easy to install and worked effectively. Many noted the hubs came pre-assembled and pre-greased, simplifying the installation process. However, some customers experienced issues with missing parts or improper fit for th...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
- purchase
- installation
- price
- setup
- quality
- removal
- returns
- measuring
1 to 4 of 195 Reviews .
1 – 4 of 195 Reviews
Most Recent
Washington State
Reviews 3
5 out of 5 stars.
Exact fit
6 months ago
Parts arrived undamaged and ready to install. Exact fit for my needs and I am very satisfied with the quality of the hub and other parts.
SweepstakesYes
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
6 months ago
Carry-On Trailer Customer Service
Thanks for yout kind words and high rating. We are committed to delivering durable, dependable trailer parts and accessories.
Review 1
5 out of 5 stars.
Great hub
8 months ago
Great hub so far
SweepstakesYes
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
8 months ago
Carry-On Trailer Customer Service
Thanks for your kind words and high rating. We are committed to delivering durable, dependable trailer parts.
Pine Grove, PA
Review 1
5 out of 5 stars.
Great replacement
a year ago
Great replacement that I was able to grab right off the shelf in my local TSC to take right home and install to get my trailer back in order the same day so I could haul firewood.
SweepstakesYes
Yes, I recommend this product.
Reviews 2
5 out of 5 stars.
Great fit!
a year ago
Went on easy. Was greased well and fit perfectly
SweepstakesYes
Yes, I recommend this product.
