Martin Wheel 5 Bolt Pressed Stud Hub Repair Kit for 1-1/16 in. Axle, H56-C-PB-B

SKU: 112828699
Martin Wheel 5 Bolt Pressed Stud Hub Repair Kit for 1-1/16 in. Axle, H56-C-PB-B
Enter Zip Code for price More Info
Product price

Save Up To
See price at checkout More Info
Product Rating is 4.7


6501 black horse pike
egg harbor township, NJ 08234
(609) 646-2222
Check Availability at Other Stores
Standard Delivery Not Available to
Notice: This item will ship within 8 days.
This product may require up to 8 additional days for order processing prior to shipping.
Change Delivery Location

Item Information

For nearly 70 years Martin Wheel has provided quality products at a competitive price. We'll keep you rolling whether you're at work or play!
Our hub kits are designed to be quality, long-lasting products to provide you with the greatest amount of performance and satisfaction at a great value.

  • Get back up in running condition with our complete trailer axle hub rebuild kit. Includes hub, lug nuts, bearing cups and cones, grease seal and cap
  • Use: Highway Rated Trailers
  • Designed for highway service
  • 5 Bolt, 4.5 inch bolt circle. Pressed Stud
  • Fits 1-1/16-inch Axle

Specification Description
With or Without Rim: Without Rim
CountryofOrigin: Imported
Outer Bearing Size (ID): 1-1/16 in.
Seal Size (ID): 1-1/16 in.
Compatible Rim Size: N/A
Part Number: H56-C-PB-B
Wheel Type: N/A
Bolt Circle Pattern: 4-1/2 in.
Weight Capacity: 1,350 lb.
Center Hole Size: 1-3/4 in.
Special Feature(s): N/A
Number of Studs: 5
Spindle Diameter: 1-1/16 in.
Material: Steel
Inner Bearing Size (ID): 1-1/16 in.
Compatible Vehicle: Trailer
Maximum Load Capacity: See product description
Brand: Martin Wheel
Warranty: 90-Day Limited Warranty
Tread Depth: N/A
Product Weight: 4.5
Valve Type: N/A
Spindle Length: 4-1/8 in.
Product Width: 7
Ply: N/A
Maximum Operating Pressure: N/A
Speed Rating: 62 MPH
Package Quantity: 1
Manufacturer Part Number H56-C-PB-B
Martin Wheel 5 Bolt Pressed Stud Hub Repair Kit for 1-1/16 in. Axle, H56-C-PB-B is rated 4.7 out of 5 by 19.
Rated 5 out of 5 by from Nice hub! Paint was very shiny! It’s a hub. I don’t really know what else to say. Seems fine went together with no problems.
Date published: 2019-12-16
Rated 5 out of 5 by from A Wheel by Another Name I purchased this hub to build a Roll Out Wheel for welding. This hub combined with the 1/16 axial was the perfect combo. They did not have a repair kit for a 4 bolt hub, so I used the 5 bolt, which doesn’t align as nicely, but still does the job. This hub is good quality, runs very true, and with combined bearings, cup and grease seal is the most cost effective way to build a roll out wheel. It will never reach highway speeds, but does get a lot of radial loading…so far, it’s worked great!
Date published: 2019-08-19
Rated 5 out of 5 by from Hunting Rack Seat Using this for a seat to go on a varmint hunting rack! It was easy to put together and spinning my chair is sooo nice now!!!
Date published: 2019-05-23
Rated 5 out of 5 by from Great hubs. Great price Purchased these due to having bad wheel bearings on my pop up camper. These worked great and are highly recommended.
Date published: 2019-04-26
  • y_2020, m_7, d_6, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.10
  • cp_1, bvpage1
  • co_hasreviews, tv_8, tr_11
  • loc_en_US, sid_112828699, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 3ms

my spindle measures 1 1/16" x 3 1/2" including threads. do you have a hub that will fit?

Asked by: DJZM
The manufacturer advised that they do not carry any hub kit which will fit spindles with a 3-1/2" length. Their hubs are suited for trailers with 4-1/8" spindles . We advise that you work with your dealer to locate a proper size replacement.
Answered by: MatthewL
Date published: 2019-09-16

What is the max weight it will hold

Asked by: Tazz71891
1250 lbs
Answered by: MatthewL
Date published: 2019-09-19

What do I need to measure for this? The spindle or the inside of the bearing? Thanks.

Asked by: Hunter419
Measure the inside diameter of the bearing.
Answered by: DanielB
Date published: 2019-07-17

is this an 88545 hub and L-44649 bearings?

Asked by: VWYZ
We have no reference for the #88545, however the H56-C-PB-B is set up with an L44649 bearing.
Answered by: DanielB
Date published: 2017-05-26

Can you tell me which bearing buddy to order with this so it will fit?

Asked by: FisherDon
This kit is supposed be set up for use with the 1-1/6” shaft diameter bearing. It includes the bearings (cone/race), grease seal & grease cap. Usually when someone refers to a bearing buddy, they’re talking about the grease cap that has a zerk installed in it. In that case the back side of the cap is set up with a 2”OD. This cap does not have a zerk fitting installed.
Answered by: DanielB
Date published: 2018-07-13

Will this hub fit Tractor Supply Co. trailer, model #5x8G, with a 1 1/16 spindle?

Asked by: Ron26
Yes, it will fit the 1-1/16 axle.
Answered by: DanielB
Date published: 2017-07-24

Is this hub for a 3500lb axle? I'm not sure what diameter mine is...

Asked by: Ford 60
Weight Capacity: 1,350 lb.
Answered by: NRoberts
Date published: 2019-11-20

When you say the axle is 1 1/16" what part of the axle is it, the outside race or inside race measurement?

Asked by: hay you
The 1-1/6” diameter is the inside diameter of the cone bearing, or take a caliper & measure the actual shaft that the bearing rides on. The inside diameter of the race would fit into the outside diameter of the cone bearing.
Answered by: CodyP
Date published: 2018-07-20
