TravellerX 20.55 in. LED Offroad Single Row Light Bar, Blackout with Amber Light Function
TravellerX 20.55 in. LED Offroad Single Row Light Bar, Blackout with Amber Light Function
TravellerX 20.55 in. LED Offroad Single Row Light Bar, Blackout with Amber Light Function
Item # 235310699
Neighbor’s Club Members earn points with purchases.
TravellerX 20.55 in. LED Offroad Single Row Light Bar, Blackout with Amber Light Function
Item # 235310699
The TravellerX 20.55 in. Offroad LED Single Row Light Bar can handle extreme wet and severe conditions with no problem. The powder-coat aluminum housing paired with the impact-resistant lens creates a rugged design that offroaders can rely on. This light bar is also equipped with high-intensity white LEDs and low-intensity amber LEDs for clear viewing and can be installed on trucks, service vehicles and boats.
Looking for more information on car and truck lighting? Check out our guide on lighting types in the product documents section.
- 21 cool white and 21 amber long-lasting LEDs per light
- LEDs have a lifetime rating of up to 50,000 hours
- 4,000 effective lumens
- 12,600 raw lumens
- 2,375 ft. beam distance
- Ideal driving light for trucks, boats and service vehicles
- Heavy-duty, extruded aluminum powder-coat housing with IP68 waterproofing withstands extreme weather conditions
- Impact-resistant lenses deliver rugged reliability
- Offroad light is abuse tested for extended life
- Power rating: 105W, 9-36VDC
- Adjustable mounting system; mounting hardware and wiring harness with switch included
- Assembled dimensions of the offroad light bar: 20.55 in. L x 2.14 in. W x 1.86 in. H
- Made in China
- 3-year warranty
| Brand | TravellerX |
|---|---|
| Country of Origin | Imported |
| Battery Size | 9-36V |
| Bulb Count | 21 cool white and 21 amber |
| Bulb Type | LED |
| Compatibility | N/A |
| Coverage Area | 1,020,860 sq ft |
| Features | IP68 |
| Finish | Powder-Coated |
| Housing Color | Gray |
| Indoor/Outdoor | Outdoor |
| Light Type | Bar Lights |
| Lumen Rating | 4,000 lm |
| Package Quantity | 1 |
| Power Type | Battery |
| Primary Material | Aluminum |
| Product Height | 1.86 in. |
| Product Length | 20.55 in. |
| Product Weight | 4.84 lb. |
| Product Width | 2.14 in. |
| Voltage | 9-36V |
| Wattage | 105W |
| Manufacturer Part Number | TB7105P |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 15 Questions
Newest questions
Q: What lumans do the amber lights put out
5 months ago1 Answer
- A: Lumen rating is 4,000 effective lumens,12,600 raw lumens, 2,375 ft. beam distance5 months agoHelpful?
Q: Can I see a wiring diagram
6 months ago2 Answers
- A: Please refer to page 9 on the manual as attached in your email.6 months agoHelpful?
Q: Is there a wiring diagram for the switch? My amber light function isnt workinf.
7 months ago1 Answer
- A: Please check your email for the requested information.6 months agoHelpful?
Q: Do they sell a bracket to mount the rocker switch to the inside of the cab? If not, what are the dimensions of the rocker switch so I can make one
7 months ago1 Answer
- A: No, TSC does not sell bracket.7 months agoHelpful?
Q: The wiring harness is not long enough for the switch to reach inside the cab of my truck what’s the best way to extended it if I don’t have to box or receipt to return it
10 months ago1 Answer
- A: no, TSC doesn’t sell harness for extension purpose.10 months agoHelpful?
Q: Wiring is to short to go to cab of truck. Very dissatisfying. Is there a harness to add on to wiring ?
10 months ago1 Answer
- A: No, TSC doesn’t sell harness for extension purpose10 months agoHelpful?
Q: does it need a relay installed
a year ago1 Answer
- A: This light contains relay inside. The light will work when connecting to 12V DC directly. It’s no need for customer to connect an extra relay.a year agoHelpful?
Q: How many candelas is this light?
a year ago1 Answer
- A: Lumen rating is 4,000 effective lumens,12,600 raw lumens, 2,375 ft. beam distancea year agoHelpful?
Q: How do I switch from white light to amber
a year ago1 Answer
- A: The wiring harness with switch comes with the light bar. Customer can follow the manual to turn the switch from “=” to “–”, the light will switch from white to ambera year agoHelpful?
Q: Does the amber light go towards the bottom or the top of the light bar?
a year ago1 Answer
- A: The amber light is on the bottom of the light bar.a year agoHelpful?
1 - 10 of 15 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 15 Questions
Newest questions
Q: What lumans do the amber lights put out
5 months ago1 Answer
- A: Lumen rating is 4,000 effective lumens,12,600 raw lumens, 2,375 ft. beam distance5 months agoHelpful?
Q: Can I see a wiring diagram
6 months ago2 Answers
- A: Please refer to page 9 on the manual as attached in your email.6 months agoHelpful?
Q: Is there a wiring diagram for the switch? My amber light function isnt workinf.
7 months ago1 Answer
- A: Please check your email for the requested information.6 months agoHelpful?
Q: Do they sell a bracket to mount the rocker switch to the inside of the cab? If not, what are the dimensions of the rocker switch so I can make one
7 months ago1 Answer
- A: No, TSC does not sell bracket.7 months agoHelpful?
Q: The wiring harness is not long enough for the switch to reach inside the cab of my truck what’s the best way to extended it if I don’t have to box or receipt to return it
10 months ago1 Answer
- A: no, TSC doesn’t sell harness for extension purpose.10 months agoHelpful?
Q: Wiring is to short to go to cab of truck. Very dissatisfying. Is there a harness to add on to wiring ?
10 months ago1 Answer
- A: No, TSC doesn’t sell harness for extension purpose10 months agoHelpful?
Q: does it need a relay installed
a year ago1 Answer
- A: This light contains relay inside. The light will work when connecting to 12V DC directly. It’s no need for customer to connect an extra relay.a year agoHelpful?
Q: How many candelas is this light?
a year ago1 Answer
- A: Lumen rating is 4,000 effective lumens,12,600 raw lumens, 2,375 ft. beam distancea year agoHelpful?
Q: How do I switch from white light to amber
a year ago1 Answer
- A: The wiring harness with switch comes with the light bar. Customer can follow the manual to turn the switch from “=” to “–”, the light will switch from white to ambera year agoHelpful?
Q: Does the amber light go towards the bottom or the top of the light bar?
a year ago1 Answer
- A: The amber light is on the bottom of the light bar.a year agoHelpful?
1 - 10 of 15 Questions
Similar Items
Items You May Like
-
-
-
-
Top Rated
-
-
Top Rated
-
-
-
-
-
Top Rated
-
Customers Also Bought
-
-
-
-
-
-
-
-
-
-
-
-
Top Rated
Reviews
1 to 4 of 10 Reviews .
1 – 4 of 10 Reviews
Most Recent
Review 1
1 out of 5 stars.
Not recommended
a day ago
Look the looks and the duel amber/white lighting but the wires are way too short and instead of using a relay like most other lights use, all the wiring comes back to the switch in the dash making it hard to hookup. You will have to cut the wires going to the lights, but that's normal. What isn't normal is i almost had to splice in more wire for the power taps, just did fit. Not recommended especially at the price.
Denver, NC
Review 1
5 out of 5 stars.
Very durable great product
2 months ago
Works great absolutely love it Buy it if you need it or want it
Yes, I recommend this product.
Anonymous
Buckeye Arizona
Review 1
5 out of 5 stars.
Travellers dual type light bar.
a year ago
Great quality lights.
SweepstakesYes
No, I do not recommend this product.
Review 1
1 out of 5 stars.
Wiring with switch not long enough.
a year ago
This lightbar does not work if mounting on front bumpers. I have a Jeep Wrangler which is shorter in the front and the wire with the switch would not reach the inside of my dash. This is more suited for a 4-wheeler.
